Mercedes Benz W222 Class S 500 4MATIC L Specs

(2016 - 2017) - Technical Specifications for Years 2016, 2017
Mercedes Benz W222 Class S image
With a fuel consumption of 8.9 litres/100km - 32 mpg UK - 26 mpg US (Average), 0 to 100 km/h (62mph) in 4.8 seconds, a maximum top speed of 155 mph (250 km/h), a curb weight of 4564 lbs (2070 kgs), the W222 Class S 500 4MATIC L has a turbocharged V 8 cylinder engine, Petrol motor.
This engine produces a maximum power of 455 PS (449 bhp - 335 kW) at 5250-5500 rpm and a maximum torque of 700 Nm (516 lb.ft) at 1800-4000 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 9 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the W222 Class S has Pneumatic. front suspension and Pneumatic. rear suspension. Stock tire sizes are 245 / 45 on 19 inch rims at the front, and 275 / 40 on 19 inch rims at the rear. For stopping power, the W222 Class S 500 4MATIC L braking system includes Vented Discs at the front and Vented Discs at the rear.
The W222 Class S model is a Turismo car manufactured by Mercedes Benz, with 4 doors and 5 seats, sold new from year 2016 until 2017, and available after that as a used car.

Mercedes Benz W222 Class S 500 4MATIC L Body, Model and Production details Mercedes Benz W222 Class S 500 4MATIC L Body, Model and Production details

Generation : W222
Body : Turismo
Num. of Doors : 4 doors

Mercedes Benz W222 Class S 500 4MATIC L Engine Technical Data Mercedes Benz W222 Class S 500 4MATIC L Engine Technical Data

Engine type - Number of cylinders : V 8
Engine Code : -
Fuel type : Petrol
Fuel System : Direct Injection.
Engine Alignment : Longitudinal
Engine Position : Front
Engine size - Displacement - Engine capacity : 284.6 cu-in / 4663 cm3
Bore x Stroke : 3.66 x 3.39 inches
92.9 x 86.0 mm
Number of valves : 32 Valves
Aspiration : Turbo + Intercooler
Compression Ratio : 10.5
Maximum power - Output - Horsepower : 449 HP / 455 PS / 335 kW
@ 5250-5500 rpm
Maximum torque : 516 lb-ft / 700 Nm
@ 1800-4000 rpm
Drive wheels - Traction - Drivetrain : AWD
Transmission Gearbox - Number of speeds :
Clutch Type : Torque Converter

Mercedes Benz W222 Class S 500 4MATIC L Fuel Consumption (Economy), Emissions and Range Mercedes Benz W222 Class S 500 4MATIC L Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 26 MPG
8.9 L/100 Km
32 MPG UK
Fuel Consumption - Economy - Open road: 33 MPG
7.1 L/100 Km
40 MPG UK
Fuel Consumption - Economy - City: 19 MPG
12.1 L/100 Km
23 MPG UK
Range : 558 miles / 898 Km
Fuel Tank Capacity : 21.1 gallons
80 L
17.6 UK gallons
CO2 emissions : 207 g/Km (Mercedes Benz)
Emission standard : Euro VI

Mercedes Benz W222 Class S 500 4MATIC L Performance Mercedes Benz W222 Class S 500 4MATIC L Performance

Top Speed : 155 Mph / 250 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 4.8 s

Mercedes Benz W222 Class S 500 4MATIC L Size, Dimensions, Aerodynamics and Weight Mercedes Benz W222 Class S 500 4MATIC L Size, Dimensions, Aerodynamics and Weight

Wheelbase : 124.61 inches / 316.5 cm
Length : 206.54 inches / 524.6 cm
Width : 74.76 inches / 189.9 cm
Height : 58.82 inches / 149.4 cm
Front Axle : 63.94 inches / 162.4 cm
Rear Axle : 64.45 inches / 163.7 cm
Aerodynamic drag coefficient - Cx : -
Curb Weight : 4564 lbs / 2070 Kg
Weight-Power Output Ratio : 4.5 kg/hp

Mercedes Benz W222 Class S 500 4MATIC L Interior size, Dimensions Mercedes Benz W222 Class S 500 4MATIC L Interior size, Dimensions

Num. of Seats : 5 seats
Seat distribution : 2+3
Trunk / Boot capacity : 18.7 cu-ft / 530 L
Trunk / Boot Second Row : 18.7 cu-ft / 530 L

Mercedes Benz W222 Class S 500 4MATIC L Brakes, Tires, Steering and Suspension Mercedes Benz W222 Class S 500 4MATIC L Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(- inches / - mm)
Rear Brakes - Dics dimensions : Vented Discs
(- inches / - mm)
Front Tyres - Rims dimensions : 245/45 R19
Rear Tyres - Rims dimensions : 275/40 R19
Steering : Rack and pinion Electric
Front Suspension : Pneumatic.
Rear Suspension : Pneumatic.
If you found an error in these specifications submit your correction here
What engine is in Mercedes Benz W222 Class S 500 4MATIC L?
The Mercedes Benz W222 Class S 500 4MATIC L has a V 8, Petrol engine with 4663 cm3 / 284.6 cu-in capacity.

How many horsepower (hp) does a 2016 Mercedes Benz W222 Class S 500 4MATIC L have?
The 2016 Mercedes Benz W222 Class S 500 4MATIC L has 455 PS / 449 bhp / 335 kW.

How much does a Mercedes Benz W222 Class S 500 4MATIC L weighs?
The Mercedes Benz W222 Class S 500 4MATIC L weighs 2070 Kg / 4564 lbs.

What is the top speed of a Mercedes Benz W222 Class S 500 4MATIC L?
The Mercedes Benz W222 Class S 500 4MATIC L top speed is 250 Km/h / 155 mph.

Is Mercedes Benz W222 Class S 500 4MATIC L All Wheel Drive (AWD)?
Yes, the Mercedes Benz W222 Class S 500 4MATIC L is All Wheel Drive (AWD).
