Volvo XC70 II Restyling D4 AWD Momentum Auto Specs

(2014 - 2015) - Technical Specifications for Years 2014, 2015

Compare with another car

More pictures

With a fuel consumption of 6.4 litres/100km - 44 mpg UK - 37 mpg US (Average), 0 to 100 km/h (62mph) in 9.5 seconds, a maximum top speed of 124 mph (200 km/h), a curb weight of 4257 lbs (1931 kgs), the XC70 II Restyling D4 AWD Momentum Auto has a turbocharged Inline 5 cylinder engine, Diesel motor.
This engine produces a maximum power of 181 PS (179 bhp - 133 kW) at 4000 rpm and a maximum torque of 420 Nm (309 lb.ft) at 1500-2500 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 6 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the XC70 II Restyling has McPherson struts. Coil springs. front suspension and Coil springs. rear suspension. Stock tire sizes are 235 / 55 on 17 inch rims at the front, and 235 / 55 on 17 inch rims at the rear. For stopping power, the XC70 II Restyling D4 AWD Momentum Auto braking system includes Vented Discs at the front and Discs at the rear.
The XC70 II Restyling model is a Estate car manufactured by Volvo, with 5 doors and 5 seats, sold new from year 2014 until 2015, and available after that as a used car.

Volvo XC70 II Restyling D4 AWD Momentum Auto Body, Model and Production details

Generation :	2nd Generation

Body :	Estate

Num. of Doors :	5 doors


Volvo XC70 II Restyling D4 AWD Momentum Auto Engine Technical Data

Engine type - Number of cylinders :	Inline 5

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine size - Displacement - Engine capacity :	146.5 cu-in / 2401 cm3

Bore x Stroke :	3.19 x 3.67 inches 81.0 x 93.2 mm

Number of valves :	20 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	16.5

Maximum power - Output - Horsepower :	179 HP / 181 PS / 133 kW @ 4000 rpm

Maximum torque :	309 lb-ft / 420 Nm @ 1500-2500 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	6 speed Automatic Transmission Relations 1st Gear Ratio: 8.5 2nd Gear Ratio: 14.8 3rd Gear Ratio: 22.5 4th Gear Ratio: 30.3 5th Gear Ratio: 40.8 6th Gear Ratio: 51.1 Reverse Gear Ratio: 10.3

Clutch Type :	Torque Converter


Volvo XC70 II Restyling D4 AWD Momentum Auto Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	37 MPG 6.4 L/100 Km 44 MPG UK

Range :	679 miles / 1093 Km

Fuel Tank Capacity :	18.5 gallons 70 L 15.4 UK gallons

CO2 emissions :	169 g/Km (Volvo)

Emission standard :	Euro V

Volvo XC70 II Restyling D4 AWD Momentum Auto Performance

Top Speed :	124 Mph / 200 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	9.5 s


Volvo XC70 II Restyling D4 AWD Momentum Auto Size, Dimensions, Aerodynamics and Weight

Wheelbase :	110.83 inches / 281.5 cm

Length :	190.47 inches / 483.8 cm

Width :	73.86 inches / 187.6 cm

Height :	63.15 inches / 160.4 cm

Front Axle :	63.15 inches / 160.4 cm

Rear Axle :	61.81 inches / 157.0 cm

Aerodynamic drag coefficient - Cx :	0.35

Curb Weight :	4257 lbs / 1931 Kg

Weight-Power Output Ratio :	10.7 kg/hp


Volvo XC70 II Restyling D4 AWD Momentum Auto Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	20.3 cu-ft / 575 L

Trunk / Boot First Row :	56.5 cu-ft / 1600 L

Trunk / Boot Second Row :	20.3 cu-ft / 575 L


Volvo XC70 II Restyling D4 AWD Momentum Auto Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (12.44 inches / 316 mm)

Rear Brakes - Dics dimensions :	Discs (11.89 inches / 302 mm)

Front Tyres - Rims dimensions :	235/55 R17

Rear Tyres - Rims dimensions :	235/55 R17

Front Wheels Width :	7,5"

Rear Wheels Width :	7,5"

Steering :	Rack and pinion Hydraulic

Steering wheel lock-to-lock :	2.8 turns

Steering ratio :	16.0

Front Suspension :	McPherson struts. Coil springs.

Rear Suspension :	Coil springs.

What engine is in Volvo XC70 II Restyling D4 AWD Momentum Auto?
The Volvo XC70 II Restyling D4 AWD Momentum Auto has a Inline 5, Diesel engine with 2401 cm3 / 146.5 cu-in capacity.

How many horsepower (hp) does a 2014 Volvo XC70 II Restyling D4 AWD Momentum Auto have?
The 2014 Volvo XC70 II Restyling D4 AWD Momentum Auto has 181 PS / 179 bhp / 133 kW.

How much does a Volvo XC70 II Restyling D4 AWD Momentum Auto weighs?
The Volvo XC70 II Restyling D4 AWD Momentum Auto weighs 1931 Kg / 4257 lbs.

What is the top speed of a Volvo XC70 II Restyling D4 AWD Momentum Auto?
The Volvo XC70 II Restyling D4 AWD Momentum Auto top speed is 200 Km/h / 124 mph.

Is Volvo XC70 II Restyling D4 AWD Momentum Auto All Wheel Drive (AWD)?
Yes, the Volvo XC70 II Restyling D4 AWD Momentum Auto is All Wheel Drive (AWD).
