Toyota Supra IV 3.0i Turbo Specs

(1993 - 1997) - Technical Specifications for Years 1993, 1994, 1995, 1996, 1997
Toyota Supra IV image
With a fuel consumption of 11 litres/100km - 26 mpg UK - 21 mpg US (Average), 0 to 100 km/h (62mph) in 5.1 seconds, a maximum top speed of 155 mph (250 km/h), a curb weight of 3560 lbs (1615 kgs), the Supra IV 3.0i Turbo has a turbocharged Inline 6 cylinder engine, Petrol motor, with the engine code 2JZ-GTE.
This engine produces a maximum power of 330 PS (326 bhp - 243 kW) at 5600 rpm and a maximum torque of 441 Nm (325 lb.ft) at 4800 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 6 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Supra IV has Independent. Double Wishbones. coil springs. anti-roll bar front suspension and Multilink. Coil springs. anti-roll bar rear suspension. Stock tire sizes are 235 / 45 on 17 inch rims at the front, and 255 / 40 on 17 inch rims at the rear. For stopping power, the Supra IV 3.0i Turbo braking system includes Vented Discs at the front and Vented Discs at the rear.
The Supra IV model is a Coupé car manufactured by Toyota, with 3 doors and 4 seats, sold new from year 1993 until 1997, and available after that as a used car.

Toyota Supra IV 3.0i Turbo Body, Model and Production details Toyota Supra IV 3.0i Turbo Body, Model and Production details

Generation : Supra A80
Body : Coupé
Num. of Doors : 3 doors

Toyota Supra IV 3.0i Turbo Engine Technical Data Toyota Supra IV 3.0i Turbo Engine Technical Data

Engine type - Number of cylinders : Inline 6
Engine Code : 2JZ-GTE
Fuel type : Petrol
Fuel System : MPI - Toyota TCCS
Lubrication :
Engine Alignment : Longitudinal
Engine Position : Front
Engine size - Displacement - Engine capacity : 182.9 cu-in / 2997 cm3
Bore x Stroke : 3.39 x 3.39 inches
86.0 x 86.0 mm
Number of valves : 24 Valves
Aspiration : Twin-Turbo (CT20A) + Intercooler
Compression Ratio : 8.5
Maximum power - Output - Horsepower : 326 HP / 330 PS / 243 kW
@ 5600 rpm
Maximum torque : 325 lb-ft / 441 Nm
@ 4800 rpm
Drive wheels - Traction - Drivetrain : RWD
Transmission Gearbox - Number of speeds :

Toyota Supra IV 3.0i Turbo Fuel Consumption (Economy), Emissions and Range Toyota Supra IV 3.0i Turbo Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 21 MPG
11 L/100 Km
26 MPG UK
Fuel Consumption - Economy - Open road: 30 MPG
7.8 L/100 Km
36 MPG UK
Fuel Consumption - Economy - Highway: 23 MPG
10.3 L/100 Km
27 MPG UK
Fuel Consumption - Economy - City: 16 MPG
15.1 L/100 Km
19 MPG UK
Range : 452 miles / 727 Km
Fuel Tank Capacity : 21.1 gallons
80 L
17.6 UK gallons
CO2 emissions : 263 g/Km (estimate)
Catalytic converter : Y

Toyota Supra IV 3.0i Turbo Performance Toyota Supra IV 3.0i Turbo Performance

Top Speed : 155 Mph / 250 Km/h
Acceleration 0 to 60 mph (0 to 96 Km/h) : 4.8 s
Acceleration 0 to 100 km/h (0 to 62 mph) : 5.1 s

Toyota Supra IV 3.0i Turbo Size, Dimensions, Aerodynamics and Weight Toyota Supra IV 3.0i Turbo Size, Dimensions, Aerodynamics and Weight

Wheelbase : 100.39 inches / 255.0 cm
Length : 177.76 inches / 451.5 cm
Width : 71.26 inches / 181.0 cm
Height : 50.2 inches / 127.5 cm
Front Axle : 59.84 inches / 152.0 cm
Rear Axle : 60.04 inches / 152.5 cm
Ground clearance : 5.12 inches / 13.0 cm
Aerodynamic drag coefficient - Cx : 0.33
Curb Weight : 3560 lbs / 1615 Kg
Weight-Power Output Ratio : 4.9 kg/hp

Toyota Supra IV 3.0i Turbo Interior size, Dimensions Toyota Supra IV 3.0i Turbo Interior size, Dimensions

Num. of Seats : 4 seats
Seat distribution : 2+2
Trunk / Boot capacity : from 6.5 cu-ft / 185 L

Toyota Supra IV 3.0i Turbo Brakes, Tires, Steering and Suspension Toyota Supra IV 3.0i Turbo Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(12.72 inches / 323 mm)
Rear Brakes - Dics dimensions : Vented Discs
(12.76 inches / 324 mm)
Front Tyres - Rims dimensions : 235/45 R17
Rear Tyres - Rims dimensions : 255/40 R17
Front Wheels Width : 8.0"
Rear Wheels Width : 9.5"
Steering : Rack and pinion. PAS
Turning circle : 35.4 feet / 10.8 m
Steering wheel lock-to-lock : 3.0 turns
Front Suspension : Independent. Double Wishbones. coil springs. anti-roll bar
Rear Suspension : Multilink. Coil springs. anti-roll bar
If you found an error in these specifications submit your correction here
What engine is in Toyota Supra IV 3.0i Turbo?
The Toyota Supra IV 3.0i Turbo has a Inline 6, Petrol engine with 2997 cm3 / 182.9 cu-in capacity.

How many horsepower (hp) does a 1993 Toyota Supra IV 3.0i Turbo have?
The 1993 Toyota Supra IV 3.0i Turbo has 330 PS / 326 bhp / 243 kW.

How much does a Toyota Supra IV 3.0i Turbo weighs?
The Toyota Supra IV 3.0i Turbo weighs 1615 Kg / 3560 lbs.

What is the top speed of a Toyota Supra IV 3.0i Turbo?
The Toyota Supra IV 3.0i Turbo top speed is 250 Km/h / 155 mph.

Is Toyota Supra IV 3.0i Turbo All Wheel Drive (AWD)?
No, the Toyota Supra IV 3.0i Turbo is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
