Toyota Avalon (XX40) 3.5 V6 XLE Specs

(2013 - 2015) - Technical Specifications for Years 2013, 2014, 2015

Key Specs

Petrol

210.9 cu-in
3456 cm³

V 6

268 HP
272 PS / 200 kW

247 lb-ft
336 Nm

Compare with another car

More pictures

Toyota Avalon (XX40) 3.5 V6 XLE Body, Model and Production details

Generation :	4th Generation (XX40)

Body :	Sedan

Num. of Doors :	4 doors


Toyota Avalon (XX40) 3.5 V6 XLE Engine Technical Data

Engine type - Number of cylinders :	V 6

Engine Code :	2GR-FE

Fuel type :	Petrol

Fuel System :	EFI

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	210.9 cu-in / 3456 cm³

Bore x Stroke :	3.7 x 3.27 inches 94.0 x 83.1 mm

Number of valves :	24 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	10.8

Horsepower :	268 HP / 272 PS / 200 kW @ 6200 rpm

Maximum torque :	247 lb-ft / 336 Nm @ 4700 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Automatic Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: 6th Gear Ratio: Reverse Gear Ratio: 4.148 Final Drive Ratio: 3.238


Toyota Avalon (XX40) 3.5 V6 XLE Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - EPA Highway (2008 - ):	31 MPG 37 MPG UK 7.6 L/100 km

Fuel Consumption - Economy - EPA City (2008 - ):	21 MPG 25 MPG UK 11.2 L/100 km

Fuel Consumption - Economy - EPA Combined (2008 - ):	25 MPG 30 MPG UK 9.4 L/100 km

Range (EPA):	423 miles / 681 km

Fuel Tank Capacity :	16.9 gallons 64 L 14.1 UK gallons

Emission standard :	ULEV

Catalytic converter :	Y

Toyota Avalon (XX40) 3.5 V6 XLE Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Toyota Avalon (XX40) 3.5 V6 XLE Size, Dimensions, Aerodynamics and Weight

Wheelbase :	110.98 inches / 281.9 cm

Length :	195.31 inches / 496.1 cm

Width :	72.2 inches / 183.4 cm

Height :	57.52 inches / 146.1 cm

Front Axle :	62.6 inches / 159.0 cm

Rear Axle :	62.2 inches / 158.0 cm

Ground clearance :	5.51 inches / 14.0 cm

Max. Towing Capacity Weight :	1001 lbs / 454 kg

Aerodynamic drag coefficient - Cx :	0.28

Curb Weight :	3461 lbs / 1570 kg

Weight/Power Output Ratio :	5.8 kg/hp


Toyota Avalon (XX40) 3.5 V6 XLE Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Front legroom :	42.09 inches / 106.9 cm

Rear seat legroom :	39.21 inches / 99.6 cm

Front shoulder room :	58.19 inches / 147.8 cm

Rear shoulder room :	57.01 inches / 144.8 cm

Front head room :	37.6 inches / 95.5 cm

Rear head room :	37.01 inches / 94.0 cm

Front hip room :	55.12 inches / 140.0 cm

Rear hip room :	54.61 inches / 138.7 cm

Trunk / Boot capacity :	16 cu-ft / 453 L


Toyota Avalon (XX40) 3.5 V6 XLE Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (11.69 inches / 297 mm)

Rear Brakes - Disc dimensions :	Discs (11.1 inches / 282 mm)

Front Tyres - Rims dimensions :	215/55 R17

Rear Tyres - Rims dimensions :	215/55 R17

Front Wheels Width :	7.0"

Rear Wheels Width :	7.0"

Steering :	Rack and pinion. PAS -

Steering wheel lock-to-lock :	3.22 turns

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Independent MacPherson. Coil Springs. Anti-roll bar

What engine is in Toyota Avalon (XX40) 3.5 V6 XLE?
The Toyota Avalon (XX40) 3.5 V6 XLE has a V 6, Petrol engine with 3456 cm³ / 210.9 cu-in capacity.

How many horsepower (hp) does a 2013 Toyota Avalon (XX40) 3.5 V6 XLE have?
The 2013 Toyota Avalon (XX40) 3.5 V6 XLE has 272 PS / 268 bhp / 200 kW.

How much does a Toyota Avalon (XX40) 3.5 V6 XLE weighs?
The Toyota Avalon (XX40) 3.5 V6 XLE weighs 1570 Kg / 3461 lbs.

Is Toyota Avalon (XX40) 3.5 V6 XLE All Wheel Drive (AWD)?
No, the Toyota Avalon (XX40) 3.5 V6 XLE is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
