Honda Odyssey 1 (RA1-RA5) 2.2i Specs

(1994 - 1996) - Technical Specifications for Years 1994, 1995, 1996

Show more Images

Compare with another car

With a maximum top speed of - mph ( km/h), a curb weight of 3483 lbs (1580 kgs), the Odyssey 1 (RA1-RA5) 2.2i has a naturally-aspirated Inline 4 cylinder engine, Petrol motor, with the engine code Honda F22B-series.
This engine produces a maximum power of 142 PS (140 bhp - 104 kW) at 5600 rpm and a maximum torque of 197 Nm (145 lb.ft) at 4500 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 4 speed Automatic gearbox.
About chassis details responsible for road holding, handling behaviour and ride confort, the Odyssey 1 (RA1-RA5) has Double Wishbone front suspension and Double Wishbone rear suspension. Stock tire sizes are 205 / 65 on 15 inch rims at the front, and 205 / 65 on 15 inch rims at the rear. For stopping power, the Odyssey 1 (RA1-RA5) 2.2i braking system includes Vented Discs at the front and Discs at the rear.
The Odyssey 1 (RA1-RA5) model is a MPV car manufactured by Honda, sold new from year 1994 to 1996, and available after that as a used car.

Honda Odyssey 1 (RA1-RA5) 2.2i Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	Honda F22B-series

Fuel type :	Petrol

Fuel System :	Multipoint Indirect Injection

Engine Alignment :	Transverse

Engine Position :	Front

Engine size - Displacement - Engine capacity :	2156 cm3 or 131.6 cu-in

Bore x Stroke :	85 x 95 mm 3.35 x 3.74 inches

Number of valves :	16 Valves

Aspiration :	N/A

Compression Ratio :	8.8

Maximum power - Output - Horsepower :	142 PS or 140 bhp or 104 kW @ 5600 rpm

Maximum torque :	197 Nm or 145 lb.ft @ 4500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	4 speed Automatic Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: Reverse Gear Ratio: Final Drive Ratio:


Honda Odyssey 1 (RA1-RA5) 2.2i Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	65 L 14.3 UK gallons 17.2 US gallons

CO2 emissions :

Honda Odyssey 1 (RA1-RA5) 2.2i Performance

Top Speed :	- km/h or - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s

Honda Odyssey 1 (RA1-RA5) 2.2i Size, Dimensions, Aerodynamics and Weight

Body :	MPV

Num. of Doors :	5

Wheelbase :	283 cm or 111.42 inches

Length :	475.5 cm or 187.2 inches

Width :	179.3 cm or 70.59 inches

Height :	164.1 cm or 64.61 inches

Max. Towing Capacity Weight :	0 Kg or 0 lbs

Aerodynamic drag coefficient - Cx :	0.39

Front Brakes - Disc dimensions :	Vented Discs (- mm)

Rear Brakes - Dics dimensions :	Discs (- mm)

Front Tyres - Rims dimensions :	205/65 R15

Rear Tyres - Rims dimensions :	205/65 R15

Curb Weight :	1580 kg OR 3483 lbs

Trunk / Boot capacity :	277-1300 L

Front Suspension :	Double Wishbone

Rear Suspension :	Double Wishbone

What engine is in Honda Odyssey 1 (RA1-RA5) 2.2i?
The Honda Odyssey 1 (RA1-RA5) 2.2i has a Inline 4, Petrol engine with 2156 cm3 / 131.6 cu-in capacity.

How much horsepower (hp) does a 1994 Honda Odyssey 1 (RA1-RA5) 2.2i have?
The 1994 Honda Odyssey 1 (RA1-RA5) 2.2i has 142 PS / 140 bhp / 104 kW horsepower.

How much does a Honda Odyssey 1 (RA1-RA5) 2.2i weighs?
The Honda Odyssey 1 (RA1-RA5) 2.2i weighs 1580 Kg / 3483 lbs.

Is Honda Odyssey 1 (RA1-RA5) 2.2i All Wheel Drive (AWD)?
No, the Honda Odyssey 1 (RA1-RA5) 2.2i is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
