Volvo S80 II D5 Momentum Aut Specs

(2013 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 6.1 litres/100km - 46 mpg UK - 39 mpg US (Average), 0 to 100 km/h (62mph) in 7.8 seconds, a maximum top speed of 140 mph (225 km/h), a curb weight of 3814 lbs (1730 kgs), the S80 II D5 Momentum Aut has a turbocharged Inline 5 cylinder engine, Diesel motor.
This engine produces a maximum power of 215 PS (212 bhp - 158 kW) at 4000 rpm and a maximum torque of 440 Nm (324 lb.ft) at 1500-3000 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 6 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the S80 II has McPherson struts. Coil springs. front suspension and Coil springs. rear suspension. Stock tire sizes are 225 / 50 on 17 inch rims at the front, and 225 / 50 on 17 inch rims at the rear. For stopping power, the S80 II D5 Momentum Aut braking system includes Vented Discs at the front and Discs at the rear.
The S80 II model is a Turismo car manufactured by Volvo, with 4 doors and 5 seats, sold new from year 2013.

Volvo S80 II D5 Momentum Aut Body, Model and Production details

Generation :	2nd Generation

Body :	Turismo

Num. of Doors :	4 doors


Volvo S80 II D5 Momentum Aut Engine Technical Data

Engine type - Number of cylinders :	Inline 5

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine size - Displacement - Engine capacity :	146.5 cu-in / 2401 cm3

Bore x Stroke :	3.19 x 3.67 inches 81.0 x 93.2 mm

Number of valves :	20 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	16.5

Maximum power - Output - Horsepower :	212 HP / 215 PS / 158 kW @ 4000 rpm

Maximum torque :	324 lb-ft / 440 Nm @ 1500-3000 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Automatic Transmission Relations 1st Gear Ratio: 9.1 2nd Gear Ratio: 15.8 3rd Gear Ratio: 24.1 4th Gear Ratio: 32.5 5th Gear Ratio: 43.7 6th Gear Ratio: 54.8 Reverse Gear Ratio: 11.1

Clutch Type :	Torque Converter


Volvo S80 II D5 Momentum Aut Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	39 MPG 6.1 L/100 Km 46 MPG UK

Range :	713 miles / 1147 Km

Fuel Tank Capacity :	18.5 gallons 70 L 15.4 UK gallons

CO2 emissions :	159 g/Km (Volvo)

Emission standard :	Euro V

Volvo S80 II D5 Momentum Aut Safety Ratings

Euro NCAP	Volvo S80 II D5 Momentum Aut Euro NCAP Safety Rating Adult: Pedestrian: Child: Safety Assist: 88 % 43 % 84 % 71 % Tested on: 2 / 2009

Volvo S80 II D5 Momentum Aut Performance

Top Speed :	140 Mph / 225 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	7.8 s


Volvo S80 II D5 Momentum Aut Size, Dimensions, Aerodynamics and Weight

Wheelbase :	111.61 inches / 283.5 cm

Length :	191.1 inches / 485.4 cm

Width :	73.27 inches / 186.1 cm

Height :	58.78 inches / 149.3 cm

Front Axle :	62.52 inches / 158.8 cm

Rear Axle :	62.4 inches / 158.5 cm

Aerodynamic drag coefficient - Cx :	0.29

Curb Weight :	3814 lbs / 1730 Kg

Weight-Power Output Ratio :	8 kg/hp


Volvo S80 II D5 Momentum Aut Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	17 cu-ft / 480 L

Trunk / Boot Second Row :	17 cu-ft / 480 L


Volvo S80 II D5 Momentum Aut Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	225/50 R17

Rear Tyres - Rims dimensions :	225/50 R17

Front Wheels Width :	7,0"

Rear Wheels Width :	7,0"

Steering :	Rack and pinion Electric

Steering wheel lock-to-lock :	2.8 turns

Steering ratio :	16.0

Front Suspension :	McPherson struts. Coil springs.

Rear Suspension :	Coil springs.

What engine is in Volvo S80 II D5 Momentum Aut?
The Volvo S80 II D5 Momentum Aut has a Inline 5, Diesel engine with 2401 cm3 / 146.5 cu-in capacity.

How many horsepower (hp) does a 2013 Volvo S80 II D5 Momentum Aut have?
The 2013 Volvo S80 II D5 Momentum Aut has 215 PS / 212 bhp / 158 kW.

How much does a Volvo S80 II D5 Momentum Aut weighs?
The Volvo S80 II D5 Momentum Aut weighs 1730 Kg / 3814 lbs.

What is the top speed of a Volvo S80 II D5 Momentum Aut?
The Volvo S80 II D5 Momentum Aut top speed is 225 Km/h / 140 mph.

Is Volvo S80 II D5 Momentum Aut All Wheel Drive (AWD)?
No, the Volvo S80 II D5 Momentum Aut is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
