Volkswagen Transporter T5.2 LWB 2.0 TSI 204HP DSG 7-speed Body, Model and Production details
|
|
| Generation : | Transporter T5.2 - 2010 Facelift |
| Body : | Van |
| Num. of Doors : | 4 doors |
Volkswagen Transporter T5.2 LWB 2.0 TSI 204HP DSG 7-speed Engine Technical Data
|
|
| Engine type - Number of cylinders : | Inline 4 |
| Engine Code : | VW EA888 CJKA |
| Fuel type : | Petrol |
| Fuel System : | Direct Injection |
| Engine Alignment : | Transverse |
| Engine Position : | Front |
| Engine displacement : | 121.1 cu-in / 1984 cm3 |
| Bore x Stroke : |
3.25 x 3.65 inches 82.5 x 92.8 mm |
| Number of valves : | 16 Valves |
| Aspiration : | Turbo Intercooler |
| Compression Ratio : | 9.6 |
| Horsepower : |
201 HP / 204 PS / 150 kW @ 4200-6000 rpm |
| Maximum torque : |
258 lb-ft / 350 Nm @ 1500-4000 rpm |
| Drive wheels - Traction - Drivetrain : | FWD |
| Transmission Gearbox - Number of speeds : |
7 speed Dualclutch Automatic
|
Volkswagen Transporter T5.2 LWB 2.0 TSI 204HP DSG 7-speed Fuel Consumption (Economy), Emissions and Range
|
|
| Fuel Consumption - Economy - City NEDC : |
18 MPG 13.2 L/100 km 21 MPG UK |
| Fuel Consumption - Economy - Open road NEDC : |
30 MPG 7.8 L/100 km 36 MPG UK |
| Fuel Consumption - Economy - Combined NEDC : |
24 MPG 9.8 L/100 km 29 MPG UK |
| Range : | 507 miles / 816 km |
| Fuel Tank Capacity : |
21.1 gallons 80 L 17.6 UK gallons |
| CO2 emissions : | 228 g/km (Volkswagen) |
| Catalytic converter : | Y |
Volkswagen Transporter T5.2 LWB 2.0 TSI 204HP DSG 7-speed Performance
|
|
| Top Speed : | 124 Mph / 200 km/h |
| Acceleration 0 to 100 km/h (0 to 62 mph) : | 8.4 s |
Volkswagen Transporter T5.2 LWB 2.0 TSI 204HP DSG 7-speed Size, Dimensions, Aerodynamics and Weight
|
|
| Wheelbase : | 133.86 inches / 340.0 cm |
| Length : | 208.35 inches / 529.2 cm |
| Width : | 74.96 inches / 190.4 cm |
| Width with mirrors : | 89.88 inches / 228.3 cm |
| Height : | 78.35 inches / 199.0 cm |
| Front Axle : | 64.09 inches / 162.8 cm |
| Rear Axle : | 64.09 inches / 162.8 cm |
| Ground clearance : | 7.91 inches / 20.1 cm |
| Cargo box inside length : | 116.93 inches / 297.0 cm |
| Cargo box inside height : | 55.51 inches / 141.0 cm |
| Cargo width : | 66.61 inches / 169.2 cm |
| Max. width at wheelhouse : | 48.98 inches / 124.4 cm |
| Loading height : | 22.48 inches / 57.1 cm |
| Rear door width : | 58.5 inches / 148.6 cm |
| Rear door height : | 51.38 inches / 130.5 cm |
| Side door width : | 40.16 inches / 102.0 cm |
| Side door height : | 50.55 inches / 128.4 cm |
| Max. Towing Capacity Weight : | 5512 lbs / 2500 kg |
| Aerodynamic drag coefficient - Cx : | - |
| Curb Weight : | 4160 lbs / 1887 kg |
| Weight/Power Output Ratio : | 9.3 kg/hp |
Volkswagen Transporter T5.2 LWB 2.0 TSI 204HP DSG 7-speed Interior size, Dimensions
|
|
| Num. of Seats : | 3 seats |
| Trunk / Boot capacity : | 236.6 cu-ft / 6700 L |
| Trunk / Boot First Row : | 236.6 cu-ft / 6700 L |
Volkswagen Transporter T5.2 LWB 2.0 TSI 204HP DSG 7-speed Brakes, Tires, Steering and Suspension
|
|||
| Front Brakes - Disc dimensions : |
Vented Discs (15.67 inches / 398 mm) |
||
| Rear Brakes - Disc dimensions : |
Vented Discs (11.57 inches / 294 mm) |
||
| Front Tyres - Rims dimensions : | 215/65 R16 | ||
| Rear Tyres - Rims dimensions : | 215/65 R16 | ||
| Turning circle : | 43.3 feet / 13.2 m | ||
| Front Suspension : | Independent. MacPherson. Coil Springs. Anti-roll bar. | ||
| Rear Suspension : | Semi-trailing arms. Coil Springs. Anti-Roll Bar. | ||
