Make

Transporter T7 Van SWB Versions

Volkswagen Transporter T7 Van SWB e-Transporter 85kW Specs

(2025 - ) - Technical Specifications for 2025

Electric

114 HP
116 PS / 85 kW

Volkswagen Transporter T7 Van SWB e-Transporter 85kW Body, Model and Production details

Generation :	Transporter T7 - 2025 New Model

Body :	Van

Num. of Doors :	4 doors


Volkswagen Transporter T7 Van SWB e-Transporter 85kW Engine Technical Data

Engine Type :	Electric

Total electric power :	114 HP / 116 PS / 85 kW

Horsepower :	114 HP / 116 PS / 85 kW

Number of electric engines:	1

Electric engine 1 type:	PSM - Permanent Magnet Synchronous Motor

Front Axle Electric Engine Power:	114 HP / 116 PS / 85 kW

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	1 speed Reduction Gear


Volkswagen Transporter T7 Van SWB e-Transporter 85kW Battery Technical Data, Charging and Range

Battery type :	Lithium-ion

Net battery capacity :	63.8 kWh

CO2 emissions WLTP :	0 g/km (Volkswagen)

Volkswagen Transporter T7 Van SWB e-Transporter 85kW Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Volkswagen Transporter T7 Van SWB e-Transporter 85kW Size, Dimensions, Aerodynamics and Weight

Wheelbase :	122.05 inches / 310.0 cm

Length :	198.82 inches / 505.0 cm

Width :	80 inches / 203.2 cm

Width with mirrors :	89.57 inches / 227.5 cm

Height :	77.95 inches / 198.0 cm

Front Axle :	67.91 inches / 172.5 cm

Rear Axle :	67.56 inches / 171.6 cm

Cargo box inside length :	102.44 inches / 260.2 cm

Cargo box inside height :	56.1 inches / 142.5 cm

Max. width at wheelhouse :	54.8 inches / 139.2 cm

Rear door width :	55.12 inches / 140.0 cm

Rear door height :	51.81 inches / 131.6 cm

Side door width :	40.55 inches / 103.0 cm

Side door height :	51.22 inches / 130.1 cm

Aerodynamic drag coefficient - Cx :	-


Volkswagen Transporter T7 Van SWB e-Transporter 85kW Interior size, Dimensions

Num. of Seats :	3 seats

Trunk / Boot capacity :	204.8 cu-ft / 5800 L


Volkswagen Transporter T7 Van SWB e-Transporter 85kW Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (12.13 inches / 308 mm)

Rear Brakes - Disc dimensions :	Discs (11.97 inches / 304 mm)

Front Tyres - Rims dimensions :	215/65 R16

Rear Tyres - Rims dimensions :	215/65 R16

Turning circle :	41 feet / 12.5 m

Front Suspension :	MacPherson struts. Coil springs. Anti-roll bar.

Rear Suspension :	Independent. Coil Springs. Anti-roll bar.
