Toyota Voltz Z Specs

(2002 - ) Technical Specifications

Key Specs

Petrol

109.6 cu-in
1796 cm³

Inline 4

187 HP
190 PS / 140 kW

132 lb-ft
180 Nm

Compare with another car

More pictures

Toyota Voltz Z Body, Model and Production details

Body :	Hatchback

Num. of Doors :	5 doors


Toyota Voltz Z Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	2ZZ-GE

Fuel type :	Petrol

Fuel System :	EFI

Engine Alignment :	Transverse

Engine displacement :	109.6 cu-in / 1796 cm³

Bore x Stroke :	3.23 x 3.35 inches 82.00 x 85.00 mm

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	11.50

Horsepower :	187 HP / 190 PS / 140 kW @ 7600 rpm

Maximum torque :	132 lb-ft / 180 Nm @ 7600 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Toyota Voltz Z Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	13.2 gallons 50 L 11 UK gallons

Catalytic converter :	Y

Toyota Voltz Z Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Toyota Voltz Z Size, Dimensions, Aerodynamics and Weight

Wheelbase :	102.36 inches / 260 cm

Length :	171.85 inches / 436.5 cm

Width :	69.88 inches / 177.5 cm

Height :	63.19 inches / 160.5 cm

Front Axle :	59.25 inches / 150.5 cm

Rear Axle :	58.46 inches / 148.5 cm

Ground clearance :	6.69 inches / 17.0 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2800 lbs / 1270 kg

Weight/Power Output Ratio :	6.7 kg/hp


Toyota Voltz Z Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	-/- R-

Rear Tyres - Rims dimensions :	-/- R-

Steering :	Rack and pinion. -

What engine is in Toyota Voltz Z?
The Toyota Voltz Z has a Inline 4, Petrol engine with 1796 cm³ / 109.6 cu-in capacity.

How many horsepower (hp) does a 2002 Toyota Voltz Z have?
The 2002 Toyota Voltz Z has 190 PS / 187 bhp / 140 kW.

How much does a Toyota Voltz Z weighs?
The Toyota Voltz Z weighs 1270 Kg / 2800 lbs.

Is Toyota Voltz Z All Wheel Drive (AWD)?
No, the Toyota Voltz Z is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
