Toyota Avanza 1.3 Specs

(2006 - ) Technical Specifications

Key Specs

Petrol

79.2 cu-in
1298 cm³

Inline 4

93 HP
94 PS / 69 kW

88 lb-ft
120 Nm

Compare with another car

More pictures

Toyota Avanza 1.3 Body, Model and Production details

Body :	MPV

Num. of Doors :	5 doors


Toyota Avanza 1.3 Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	K3-VE

Fuel type :	Petrol

Fuel System :	EFi

Engine Alignment :	Transverse

Engine displacement :	79.2 cu-in / 1298 cm³

Bore x Stroke :	2.83 x 3.14 inches 72.00 x 79.70 mm

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Horsepower :	93 HP / 94 PS / 69 kW @ 6000 rpm

Maximum torque :	88 lb-ft / 120 Nm @ 6000 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	5 speed Manual Transmission Relations Final Drive Ratio: 5.13


Toyota Avanza 1.3 Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	11.9 gallons 45 L 9.9 UK gallons

Catalytic converter :	Y

Toyota Avanza 1.3 Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Toyota Avanza 1.3 Size, Dimensions, Aerodynamics and Weight

Wheelbase :	104.53 inches / 265.5 cm

Length :	162.2 inches / 412 cm

Width :	64.17 inches / 163 cm

Height :	66.73 inches / 169.5 cm

Front Axle :	55.31 inches / 140.5 cm

Rear Axle :	55.71 inches / 141.5 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2304 lbs / 1045 kg

Weight/Power Output Ratio :	11.1 kg/hp


Toyota Avanza 1.3 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Drums (- inches / - mm)

Front Tyres - Rims dimensions :	185/70 R14

Rear Tyres - Rims dimensions :	185/70 R14

Front Suspension :	MacPherson struts. Coil springs. Anti-roll bar.

Rear Suspension :	Coil Springs.

What engine is in Toyota Avanza 1.3?
The Toyota Avanza 1.3 has a Inline 4, Petrol engine with 1298 cm³ / 79.2 cu-in capacity.

How many horsepower (hp) does a 2006 Toyota Avanza 1.3 have?
The 2006 Toyota Avanza 1.3 has 94 PS / 93 bhp / 69 kW.

How much does a Toyota Avanza 1.3 weighs?
The Toyota Avanza 1.3 weighs 1045 Kg / 2304 lbs.

Is Toyota Avanza 1.3 All Wheel Drive (AWD)?
No, the Toyota Avanza 1.3 is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
