Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Body, Model and Production details
|
|
| Generation : | Master 4 Phase 1 - 2025 New Model |
| Body : | Van |
| Num. of Doors : | 4 doors |
Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Engine Technical Data
|
|
| Engine type - Number of cylinders : | Inline 4 |
| Engine Code : | M9R H6 |
| Fuel type : | Diesel |
| Fuel System : | Common Rail |
| Lubrication : |
See oil information  Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Oil Specifications - Engine oil All Weather: 5W30 OEM: Renault RN17 Engine oil capacity (with filter): 7.5 L |
| Engine Alignment : | Transverse |
| Engine Position : | Front |
| Engine displacement : | 121.9 cu-in / 1997 cm3 |
| Bore x Stroke : |
3.35 x 3.46 inches 85 x 88 mm |
| Number of valves : | 16 Valves |
| Aspiration : | Turbo Intercooler |
| Compression Ratio : | 16.0 |
| Horsepower : |
168 HP / 170 PS / 125 kW @ 3500 rpm |
| Maximum torque : |
280 lb-ft / 380 Nm @ 1500 rpm |
| Drive wheels - Traction - Drivetrain : | FWD |
| Transmission Gearbox - Number of speeds : |
9 speed Automatic
|
Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Fuel Consumption (Economy), Emissions and Range
|
|
| Fuel Consumption - Economy - Low WLTP: |
27 MPG 8.7 L/100 km 32 MPG UK |
| Fuel Consumption - Economy - Medium WLTP: |
34 MPG 7 L/100 km 40 MPG UK |
| Fuel Consumption - Economy - High WLTP: |
36 MPG 6.5 L/100 km 43 MPG UK |
| Fuel Consumption - Economy - Extra high WLTP: |
38 MPG 6.2 L/100 km 46 MPG UK |
| Fuel Consumption - Economy - Combined WLTP: |
34 MPG 7 L/100 km 40 MPG UK |
| Range (WLTP): | 710 miles / 1142 km |
| Fuel Tank Capacity : |
21.1 gallons 80 L 17.6 UK gallons |
| AdBlue Tank : |
5.8 gallons 22 L 4.8 UK gallons |
| CO2 emissions WLTP : | 183 g/km (Renault) |
| Catalytic converter : | Particle Filter (with SCR cat.) |
Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Performance
|
|
| Top Speed : | 108 Mph / 173 km/h |
| Acceleration 0 to 100 km/h (0 to 62 mph) : | - s |
Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Size, Dimensions, Aerodynamics and Weight
|
|
| Wheelbase : | 165.94 inches / 421.5 cm |
| Length : | 248.62 inches / 631.5 cm |
| Width : | 81.89 inches / 208.0 cm |
| Width with mirrors : | 97.09 inches / 246.6 cm |
| Height : | 98.35 inches / 249.8 cm |
| Front Axle : | 69.29 inches / 176.0 cm |
| Rear Axle : | 68.11 inches / 173.0 cm |
| Cargo box inside length : | 151.77 inches / 385.5 cm |
| Cargo box inside height : | 74.21 inches / 188.5 cm |
| Cargo width : | 70.43 inches / 178.9 cm |
| Max. width at wheelhouse : | 54.33 inches / 138.0 cm |
| Loading height : | 22.4 inches / 56.9 cm |
| Rear door width : | 60.51 inches / 153.7 cm |
| Rear door height : | 69.06 inches / 175.4 cm |
| Side door width : | 51.65 inches / 131.2 cm |
| Side door height : | 69.09 inches / 175.5 cm |
| Max. Towing Capacity Weight : | 5512 lbs / 2500 kg |
| Aerodynamic drag coefficient - Cx : | - |
| Curb Weight : | 4850 lbs / 2200 kg |
| Weight/Power Output Ratio : | 12.9 kg/hp |
Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Interior size, Dimensions
|
|
| Num. of Seats : | 3 seats |
| Trunk / Boot capacity : | 459.1 cu-ft / 13000 L |
| Trunk / Boot First Row : | 459.1 cu-ft / 13000 L |
Renault Master 2025 L3H2 Van 3.5t Blue dCi 170 Auto Brakes, Tires, Steering and Suspension
|
|||
| Front Brakes - Disc dimensions : |
Vented Discs (12.01 inches / 305 mm) |
||
| Rear Brakes - Disc dimensions : |
Discs (11.81 inches / 300 mm) |
||
| Front Tyres - Rims dimensions : | 205/75 R16 | ||
| Rear Tyres - Rims dimensions : | 205/75 R16 | ||
| Turning circle : | 47.9 feet / 14.6 m | ||
| Front Suspension : | Coil Springs. | ||
| Rear Suspension : | Leaf Springs. | ||
