Make

Master 3 Phase 3 Combi Versions

Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Specs

(2023 - 2024) - Technical Specifications for Years 2023, 2024

Key Specs

Diesel

2299 cm³
140.3 cu-in

Inline 4

165 PS
163 HP / 121 kW

380 Nm
280 lb-ft

160 km/h
99 Mph

10.7 L/100 km
26 MPG UK
22 MPG US

Compare with another car

More pictures

Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Body, Model and Production details

Generation :	Master 3rd Gen. - 2010 New Model

Body :	Van

Num. of Doors :	4 doors


Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	M9T D7

Fuel type :	Diesel

Fuel System :	Common Rail

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2299 cm³ / 140.3 cu-in

Bore x Stroke :	85.0 x 101.3 mm 3.35 x 3.99 inches

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	15.4

Horsepower :	165 PS / 163 HP / 121 kW @ 3500 rpm

Maximum torque :	380 Nm / 280 lb-ft @ 1500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Low WLTP:	10.4 L/100 km 27 MPG UK 23 MPG US

Fuel Consumption - Economy - Medium WLTP:	9 L/100 km 31 MPG UK 26 MPG US

Fuel Consumption - Economy - High WLTP:	8.9 L/100 km 32 MPG UK 26 MPG US

Fuel Consumption - Economy - Extra high WLTP:	13.3 L/100 km 21 MPG UK 18 MPG US

Fuel Consumption - Economy - Combined WLTP:	10.7 L/100 km 26 MPG UK 22 MPG US

Range (WLTP):	981 km / 610 miles

Fuel Tank Capacity :	105 L 27.7 US gallons 23.1 UK gallons

AdBlue Tank :	28 L 7.4 US gallons 6.2 UK gallons

CO2 emissions WLTP :	280 g/km (Renault)

Emission standard :	Euro 6e - WLTP

Catalytic converter :	Particle Filter (with SCR cat.)

Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Performance

Top Speed :	160 km/h / 99 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Size, Dimensions, Aerodynamics and Weight

Wheelbase :	368.2 cm / 144.96 inches

Length :	557.5 cm / 219.49 inches

Width :	207.0 cm / 81.5 inches

Width with mirrors :	247.0 cm / 97.24 inches

Height :	248.2 cm / 97.72 inches

Front Axle :	175.0 cm / 68.9 inches

Rear Axle :	173.0 cm / 68.11 inches

Ground clearance :	18.1 cm / 7.13 inches

Max. width at wheelhouse :	138.0 cm / 54.33 inches

Rear door width :	182.0 cm / 71.65 inches

Rear door height :	127.0 cm / 50 inches

Side door width :	178.0 cm / 70.08 inches

Side door height :	178.0 cm / 70.08 inches

Max. Towing Capacity Weight :	2500 kg / 5512 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2361 kg / 5205 lbs

Weight/Power Output Ratio :	14.3 kg/hp


Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Interior size, Dimensions

Num. of Seats :	9 seats

Trunk / Boot capacity :	-

Trunk / Boot First Row :	4840 L / 170.9 cu-ft


Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (302 mm / 11.89 inches)

Rear Brakes - Disc dimensions :	Discs (305 mm / 12.01 inches)

Front Tyres - Rims dimensions :	225/65 R16

Rear Tyres - Rims dimensions :	225/65 R16

Turning circle :	13.6 m / 44.6 feet

Front Suspension :	Coil Springs.

Rear Suspension :	Leaf Springs

What engine is in Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats?
The Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats has a Inline 4, Diesel engine with 2299 cm³ / 140.3 cu-in capacity.

How many horsepower (hp) does a 2023 Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats have?
The 2023 Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats has 165 PS / 163 bhp / 121 kW.

How much does a Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats weighs?
The Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats weighs 2361 Kg / 5205 lbs.

What is the top speed of a Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats?
The Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats top speed is 160 Km/h / 99 mph.

Is Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats All Wheel Drive (AWD)?
No, the Renault Master 3 Phase 3 Combi L2H2 3.3t ENERGY Blue dCi 165 9-seats is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
