Make

W223 Class S Versions

Mercedes Benz W223 Class S 350 d 9G-TRONIC Specs

(2024 - ) - Technical Specifications for Years 2024, 2025

Mild Diesel

182.4 cu-in
2989 cm³

Inline 6

331 HP
336 PS / 247 kW

479 lb-ft
650 Nm

155 Mph
250 km/h

40 MPG
5.9 L/100 km
48 MPG UK

Mercedes Benz W223 Class S 350 d 9G-TRONIC Body, Model and Production details

Generation :	W223

Body :	Sedan

Num. of Doors :	4 doors


Mercedes Benz W223 Class S 350 d 9G-TRONIC Engine Technical Data

Engine type - Number of cylinders :	Inline 6

Engine Code :	OM656.830

Fuel type :	Mild Diesel

Fuel System :	Common Rail

Lubrication :	See oil information Mercedes Benz W223 Class S 350 d 9G-TRONIC Oil Specifications - Engine oil All Weather: 5W30 OEM: MB 229.52 Engine oil capacity (with filter): 9.0 L

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	182.4 cu-in / 2989 cm³

Bore x Stroke :	3.23 x 3.64 inches 82.0 x 92.4 mm

Number of valves :	24 Valves

Aspiration :	Bi-Turbo

Compression Ratio :	15.5

Horsepower :	309 HP / 313 PS / 230 kW @ 3600-4800 rpm

Maximum torque :	479 lb-ft / 650 Nm @ 1200-3200 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	9 speed Automatic


Mercedes Benz W223 Class S 350 d 9G-TRONIC Electric Engines Technical Data

Total System Power :	331 HP / 336 PS / 247 kW

Total System Torque :	479 lb-ft / 650 Nm


Mercedes Benz W223 Class S 350 d 9G-TRONIC Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Low WLTP:	24 MPG 9.8 L/100 km 29 MPG UK

Fuel Consumption - Economy - Medium WLTP:	36 MPG 6.6 L/100 km 43 MPG UK

Fuel Consumption - Economy - High WLTP:	50 MPG 4.7 L/100 km 60 MPG UK

Fuel Consumption - Economy - Extra high WLTP:	48 MPG 4.9 L/100 km 58 MPG UK

Fuel Consumption - Economy - Combined WLTP:	40 MPG 5.9 L/100 km 48 MPG UK

Range (WLTP):	684 miles / 1101 km

Fuel Tank Capacity :	17.2 gallons 65 L 14.3 UK gallons

AdBlue Tank :	6.6 gallons 25 L 5.5 UK gallons

CO2 emissions WLTP :	154 g/km (Mercedes Benz)

Emission standard :	Euro 6E

Catalytic converter :	Particle Filter (with SCR cat.)

Mercedes Benz W223 Class S 350 d 9G-TRONIC Performance

Top Speed :	155 Mph / 250 km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	5.6 s


Mercedes Benz W223 Class S 350 d 9G-TRONIC Size, Dimensions, Aerodynamics and Weight

Wheelbase :	122.28 inches / 310.6 cm

Length :	203.9 inches / 517.9 cm

Width :	76.93 inches / 195.4 cm

Width with mirrors :	83.03 inches / 210.9 cm

Height :	59.17 inches / 150.3 cm

Front Axle :	65.16 inches / 165.5 cm

Rear Axle :	66.26 inches / 168.3 cm

Ground clearance :	5.12 inches / 13.0 cm

Max. Towing Capacity Weight :	4630 lbs / 2100 kg

Aerodynamic drag coefficient - Cx :	0.23

Curb Weight :	4608 lbs / 2090 kg

Weight/Power Output Ratio :	6.2 kg/hp


Mercedes Benz W223 Class S 350 d 9G-TRONIC Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	19.1 cu-ft / 540 L


Mercedes Benz W223 Class S 350 d 9G-TRONIC Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Front Tyres - Rims dimensions :	235/55 R18

Rear Tyres - Rims dimensions :	235/55 R18

Turning circle :	40 feet / 12.2 m

Front Suspension :	Multi-link. Pneumatic. Anti-roll bar.

Rear Suspension :	Multi-link. Pneumatic. Anti-roll bar.
