| Generation : | Sportage 4 (QL) |
| Body : | TT |
| Num. of Doors : | 5 doors |
|
|
| Engine type - Number of cylinders : | Inline 4 |
| Engine Code : | - |
| Fuel type : | Diesel |
| Fuel System : | Direct Injection. |
| Engine Alignment : | Transverse |
| Engine Position : | Front |
| Engine displacement : | 121.7 cu-in / 1995 cm3 |
| Bore x Stroke : |
3.31 x 3.54 inches 84.0 x 90.0 mm |
| Number of valves : | 16 Valves |
| Aspiration : | Turbo (TGV) + Intercooler |
| Compression Ratio : | 16.0 |
| Horsepower : |
182 HP / 185 PS / 136 kW @ 4000 rpm |
| Maximum torque : |
295 lb-ft / 400 Nm @ 1750-2750 rpm |
| Drive wheels - Traction - Drivetrain : | AWD |
| Transmission Gearbox - Number of speeds : |
6 speed Manual
Transmission Relations
1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: 6th Gear Ratio: |
|
|
| Fuel Consumption - Economy - City NEDC : |
33 MPG 7.1 L/100 km 40 MPG UK |
| Fuel Consumption - Economy - Open road NEDC : |
45 MPG 5.2 L/100 km 54 MPG UK |
| Fuel Consumption - Economy - Combined NEDC : |
40 MPG 5.9 L/100 km 48 MPG UK |
| Range : | 653 miles / 1050 km |
| Fuel Tank Capacity : |
16.4 gallons 62 L 13.6 UK gallons |
| CO2 emissions : | 154 g/km (Kia) |
| Emission standard : | Euro VI |
|
|
| Top Speed : | 125 Mph / 201 km/h |
| Acceleration 0 to 100 km/h (0 to 62 mph) : | 9.5 s |
|
|
| Wheelbase : | 105.12 inches / 267.0 cm |
| Length : | 176.38 inches / 448.0 cm |
| Width : | 73.03 inches / 185.5 cm |
| Height : | 64.37 inches / 163.5 cm |
| Front Axle : | 63.35 inches / 160.9 cm |
| Rear Axle : | 63.78 inches / 162.0 cm |
| Ground clearance : | 6.77 inches / 17.2 cm |
| Approach angle (deg) : | 16.7° |
| Breakover (Rampover) angle (deg) : | 18.6° |
| Departure angle (deg) : | 23.9° |
| Aerodynamic drag coefficient - Cx : | - |
| Curb Weight : | 3499 lbs / 1587 kg |
| Weight/Power Output Ratio : | 8.6 kg/hp |
|
|
| Num. of Seats : | 5 seats |
| Seat distribution : | 2+3 |
| Trunk / Boot capacity : | 17.8 cu-ft / 503 L |
| Trunk / Boot First Row : | 52.7 cu-ft / 1492 L |
|
|||
| Front Brakes - Disc dimensions : |
Vented Discs (12.01 inches / 305 mm) |
||
| Rear Brakes - Disc dimensions : |
Discs (11.89 inches / 302 mm) |
||
| Front Tyres - Rims dimensions : | 245/45 R19 | ||
| Rear Tyres - Rims dimensions : | 245/45 R19 | ||
| Front Wheels Width : | 7.5" | ||
| Rear Wheels Width : | 7.5" | ||
| Steering : | Rack and pinion Electric | ||
| Steering wheel lock-to-lock : | 2.7 turns | ||
| Steering ratio : | 14.4 | ||
| Front Suspension : | MacPherson struts. Coil springs. | ||
| Rear Suspension : | Coil Springs. | ||
|
