Ford Fusion 1.6 TDCi 90 Specs

(2005 - ) Technical Specifications
With a fuel consumption of 4.6 litres/100km - 61 mpg UK - 51 mpg US (Average), 0 to 100 km/h (62mph) in 12.9 seconds, a maximum top speed of 109 mph (176 km/h), a curb weight of 2562 lbs (1162 kgs), the Fusion 1.6 TDCi 90 has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 90 PS (89 bhp - 66 kW) at 4000 rpm and a maximum torque of 204 Nm (150 lb.ft) at 1750 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 5 speed Manual gearbox.
About chassis details responsible for road holding, handling behaviour and ride confort, the Fusion Stock tire sizes are 195 / 60 on 15 inch rims at the front, and 195 / 60 on 15 inch rims at the rear. For stopping power, the Fusion 1.6 TDCi 90 braking system includes Vented Discs at the front and Drums at the rear.
The Fusion model is a car manufactured by Ford, sold new from year 2005.

Ford Fusion 1.6 TDCi 90 Engine Technical Data Ford Fusion 1.6 TDCi 90 Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Diesel
Fuel System : Common Rail
Engine Alignment : Transverse
Engine size - Displacement - Engine capacity : 1560 cm3 or 95.2 cu-in
Bore x Stroke : 75 x 88.3 mm
2.95 x 3.46 inches
Number of valves : 16 Valves
Aspiration : Turbo + Intercooler
Maximum power - Output - Horsepower : 90 PS or 89 bhp or 66 kW @ 4000 rpm
Maximum torque : 204 Nm or 150 lb.ft @ 1750 rpm
Drive wheels - Traction - Drivetrain : FWD
Transmission Gearbox - Number of speeds :

Ford Fusion 1.6 TDCi 90 Fuel Consumption (Economy), Emissions and Range Ford Fusion 1.6 TDCi 90 Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 4.6 L/100km
61 mpg UK / 51 mpg US
Fuel Consumption - Economy - Open road: 4.0 L/100km
71 mpg UK / 59 mpg US
Fuel Consumption - Economy - City: 5.5 L/100km
51 mpg UK / 43 mpg US
Range : 978 Km or 608 miles
Fuel Tank Capacity : 45 L
9.9 UK gallons
11.9 US gallons
CO2 emissions : 122 g/Km (Ford)

Ford Fusion 1.6 TDCi 90 Safety Ratings

Euro NCAP

Ford Fusion 1.6 TDCi 90 Performance Ford Fusion 1.6 TDCi 90 Performance

Top Speed : 176 km/h or 109 Mph
Acceleration 0 to 100 km/h (0 to 62 mph) : 12.9 s

Ford Fusion 1.6 TDCi 90 Size, Dimensions, Aerodynamics and Weight Ford Fusion 1.6 TDCi 90 Size, Dimensions, Aerodynamics and Weight

Num. of Doors : 5
Wheelbase : 248.5 cm or 97.83 inches
Length : 402 cm or 158.27 inches
Width : 172.1 cm or 67.76 inches
Height : 153.4 cm or 60.39 inches
Max. Towing Capacity Weight : 0 Kg or 0 lbs
Aerodynamic drag coefficient - Cx : -
Front Brakes - Disc dimensions : Vented Discs (- mm)
Rear Brakes - Dics dimensions : Drums (- mm)
Front Tyres - Rims dimensions : 195/60 R15
Rear Tyres - Rims dimensions : 195/60 R15
Curb Weight : 1162 kg OR 2562 lbs
Weight-Power Output Ratio : 12.9 kg/hp
Trunk / Boot capacity : 337 L
How much horsepower (hp) does a 2005 Ford Fusion 1.6 TDCi 90 have?
The 2005 Ford Fusion 1.6 TDCi 90 has 90 PS / 89 bhp / 66 kW horsepower.

How much does a Ford Fusion 1.6 TDCi 90 weighs?
The Ford Fusion 1.6 TDCi 90 weighs 1162 Kg / 2562 lbs.

What is the top speed of a Ford Fusion 1.6 TDCi 90?
The Ford Fusion 1.6 TDCi 90 top speed is 176 Km/h / 109 mph.

Is Ford Fusion 1.6 TDCi 90 All Wheel Drive (AWD)?
No, the Ford Fusion 1.6 TDCi 90 is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
