Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Specs

(2018 - 2018) - Technical Specifications for 2018

Key Specs

Diesel

121.7 cu-in
1995 cm³

Inline 4

104 HP
105 PS / 77 kW

265 lb-ft
360 Nm

Compare with another car

More pictures

Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Body, Model and Production details

Generation :	Transit Custom 1 - 2018 Facelift

Body :	Bus

Num. of Doors :	4 doors


Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	Ford EcoBlue YLFS

Fuel type :	Diesel

Fuel System :	Common Rail

Lubrication :	See oil information Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Oil Specifications - Engine oil All Weather: 0W30 OEM: WSS-M2C950-A API/ACEA: ACEA C2 Engine oil capacity (with filter): 8.3 L

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	121.7 cu-in / 1995 cm³

Bore x Stroke :	3.31 x 3.54 inches 84.01 x 90.03 mm

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	16.5

Horsepower :	104 HP / 105 PS / 77 kW @ 3500 rpm

Maximum torque :	265 lb-ft / 360 Nm @ 1375 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	33 MPG 7.1 L/100 km 40 MPG UK

Fuel Consumption - Economy - Open road NEDC :	41 MPG 5.8 L/100 km 49 MPG UK

Fuel Consumption - Economy - Combined NEDC :	37 MPG 6.3 L/100 km 45 MPG UK

Range :	690 miles / 1111 km

Fuel Tank Capacity :	18.5 gallons 70 L 15.4 UK gallons

AdBlue Tank :	5.5 gallons 21 L 4.6 UK gallons

CO2 emissions :	162 g/km (Ford)

Emission standard :	euro 6b

Catalytic converter :	Particle Filter (with SCR cat.)

Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Size, Dimensions, Aerodynamics and Weight

Wheelbase :	115.47 inches / 293.3 cm

Length :	195.79 inches / 497.3 cm

Width :	78.19 inches / 198.6 cm

Width with mirrors :	89.45 inches / 227.2 cm

Height :	77.64 inches / 197.2 cm

Front Axle :	68.35 inches / 173.6 cm

Rear Axle :	67.72 inches / 172.0 cm

Cargo box inside length :	27.05 inches / 68.7 cm

Cargo box inside height :	54.41 inches / 138.2 cm

Cargo width :	69.88 inches / 177.5 cm

Max. width at wheelhouse :	53.15 inches / 135.0 cm

Rear door width :	55.28 inches / 140.4 cm

Rear door height :	51.06 inches / 129.7 cm

Side door width :	36.61 inches / 93.0 cm

Side door height :	50.87 inches / 129.2 cm

Max. Towing Capacity Weight :	3086 lbs / 1400 kg

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	4877 lbs / 2212 kg

Weight/Power Output Ratio :	21.1 kg/hp


Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Interior size, Dimensions

Num. of Seats :	9 seats

Trunk / Boot capacity :	45.9 cu-ft / 1300 L

Trunk / Boot Second Row :	109.5 cu-ft / 3100 L


Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	215/65 R16

Rear Tyres - Rims dimensions :	215/65 R16

Front Wheels Width :	6.5"

Rear Wheels Width :	6.5"

Turning circle :	40 feet / 12.2 m

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Beam axle. Coil springs.

What engine is in Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP ?
The Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP has a Inline 4, Diesel engine with 1995 cm³ / 121.7 cu-in capacity.

How many horsepower (hp) does a 2018 Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP have?
The 2018 Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP has 105 PS / 104 bhp / 77 kW.

How much does a Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP weighs?
The Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP weighs 2212 Kg / 4877 lbs.

Is Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP All Wheel Drive (AWD)?
No, the Ford Transit Custom 2018 Kombi L1 320 2.0 TDCi 105HP is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
