Make

CTS II US Spec Versions

- 2.8 V6 (2007)- 2.8 V6 Automatic (2007)- 3.6 V6 (2007)- 3.6 V6 Automatic (2007)- 3.6 V6 AWD Automatic (2007)- 3.6 V6 HF (2007)- 3.6 V6 HF Automatic (2007)- 3.6 V6 HF AWD Automatic (2007)- AWD (2009)- CTS (2009)- CTS-V (2008)- CTS-V Automatic (2008)- CTS-V Coupe (2010)- CTS-V Coupe Automatic (2010)- CTS-V Sport Wagon (2010)- CTS-V Sport Wagon Automatic (2010)- Sport Wagon (2009)- Sport Wagon 3.6 (2009)- Sport Wagon 3.6 AWD (2009)- Sport Wagon AWD (2009)

Cadillac CTS II US Spec Sport Wagon AWD Specs

(2009 - ) Technical Specifications

Key Specs

Petrol

182.9 cu-in
2997 cm³

V 6

270 HP
274 PS / 202 kW

222 lb-ft
302 Nm

Compare with another car

More pictures

Cadillac CTS II US Spec Sport Wagon AWD Body, Model and Production details

Generation :	CTS 2 US Spec

Body :	Estate

Num. of Doors :	5 doors


Cadillac CTS II US Spec Sport Wagon AWD Engine Technical Data

Engine type - Number of cylinders :	V 6

Engine Code :	-

Fuel type :	Petrol

Fuel System :	direct petrol injection

Engine Alignment :	Longitudinal

Engine displacement :	182.9 cu-in / 2997 cm³

Bore x Stroke :	3.5 x 3.16 inches 89.00 x 80.30 mm

Number of valves :	24 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	11.70

Horsepower :	270 HP / 274 PS / 202 kW @ 7000 rpm

Maximum torque :	222 lb-ft / 302 Nm @ 7000 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	6 speed Automatic Transmission Relations Final Drive Ratio: 3.23


Cadillac CTS II US Spec Sport Wagon AWD Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	18 gallons 68 L 15 UK gallons

Catalytic converter :	Y

Cadillac CTS II US Spec Sport Wagon AWD Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Cadillac CTS II US Spec Sport Wagon AWD Size, Dimensions, Aerodynamics and Weight

Wheelbase :	113.39 inches / 288 cm

Length :	191.3 inches / 485.9 cm

Width :	72.6 inches / 184.4 cm

Height :	59.09 inches / 150.1 cm

Front Axle :	61.81 inches / 157.0 cm

Rear Axle :	62.01 inches / 157.5 cm

Aerodynamic drag coefficient - Cx :	-


Cadillac CTS II US Spec Sport Wagon AWD Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (12.4 inches / 315 mm)

Rear Brakes - Disc dimensions :	Vented Discs (12.4 inches / 315 mm)

Front Tyres - Rims dimensions :	235/55 R17

Rear Tyres - Rims dimensions :	235/55 R18

Front Wheels Width :	8"

Rear Wheels Width :	8"

Steering :	Rack and pinion. PAS -

Steering wheel lock-to-lock :	3.000 turns

What engine is in Cadillac CTS II US Spec Sport Wagon AWD?
The Cadillac CTS II US Spec Sport Wagon AWD has a V 6, Petrol engine with 2997 cm³ / 182.9 cu-in capacity.

How many horsepower (hp) does a 2009 Cadillac CTS II US Spec Sport Wagon AWD have?
The 2009 Cadillac CTS II US Spec Sport Wagon AWD has 274 PS / 270 bhp / 202 kW.

Is Cadillac CTS II US Spec Sport Wagon AWD All Wheel Drive (AWD)?
Yes, the Cadillac CTS II US Spec Sport Wagon AWD is All Wheel Drive (AWD).
