BMW E87 1 Series 5 door 120i Specs

(2004 - 2007) - Technical Specifications for Years 2004, 2005, 2006, 2007
BMW E87 1 Series 5 door image
With a fuel consumption of 7.4 litres/100km - 38 mpg UK - 32 mpg US (Average), 0 to 100 km/h (62mph) in 8.4 seconds, a maximum top speed of 135 mph (217 km/h), a curb weight of 2723 lbs (1235 kgs), the E87 1 Series 5 door 120i has a naturally-aspirated Inline 4 cylinder engine, Petrol motor.
This engine produces a maximum power of 150 PS (148 bhp - 110 kW) at 6200 rpm and a maximum torque of 200 Nm (147 lb.ft) at 3600 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 6 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the E87 1 Series 5 door has Independent. Double Wishbones. coil springs. anti-roll bar front suspension and Multilink. Coil springs. anti-roll bar rear suspension. Stock tire sizes are 195 / 55 on 16 inch rims at the front, and 195 / 55 on 16 inch rims at the rear. For stopping power, the E87 1 Series 5 door 120i braking system includes Vented Discs at the front and Discs at the rear.
The E87 1 Series 5 door model is a car manufactured by BMW, with 5 doors and 5 seats, sold new from year 2004 until 2007, and available after that as a used car.

BMW E87 1 Series 5 door 120i Body, Model and Production details BMW E87 1 Series 5 door 120i Body, Model and Production details

Generation : E8x
Body : -
Num. of Doors : 5 doors

BMW E87 1 Series 5 door 120i Engine Technical Data BMW E87 1 Series 5 door 120i Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Petrol
Fuel System : MPI
Engine Alignment : Longitudinal
Engine size - Displacement - Engine capacity : 121.7 cu-in / 1995 cm3
Bore x Stroke : 3.31 x 3.54 inches
84.0 x 90.0 mm
Number of valves : 16 Valves
Aspiration : N/A
Compression Ratio : 10.5
Maximum power - Output - Horsepower : 148 HP / 150 PS / 110 kW
@ 6200 rpm
Maximum torque : 147 lb-ft / 200 Nm
@ 3600 rpm
Drive wheels - Traction - Drivetrain : RWD
Transmission Gearbox - Number of speeds :

BMW E87 1 Series 5 door 120i Fuel Consumption (Economy), Emissions and Range BMW E87 1 Series 5 door 120i Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 32 MPG
7.4 L/100 Km
38 MPG UK
Fuel Consumption - Economy - Open road: 42 MPG
5.6 L/100 Km
50 MPG UK
Fuel Consumption - Economy - City: 22 MPG
10.7 L/100 Km
26 MPG UK
Range : 445 miles / 716 Km
Fuel Tank Capacity : 14 gallons
53 L
11.7 UK gallons
CO2 emissions : 178 g/Km (BMW)

BMW E87 1 Series 5 door 120i Safety Ratings

Euro NCAP

BMW E87 1 Series 5 door 120i Performance BMW E87 1 Series 5 door 120i Performance

Top Speed : 135 Mph / 217 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 8.4 s

BMW E87 1 Series 5 door 120i Size, Dimensions, Aerodynamics and Weight BMW E87 1 Series 5 door 120i Size, Dimensions, Aerodynamics and Weight

Wheelbase : 104.72 inches / 266.0 cm
Length : 166.54 inches / 423.0 cm
Width : 68.9 inches / 175.0 cm
Height : 56.3 inches / 143.0 cm
Aerodynamic drag coefficient - Cx : -
Curb Weight : 2723 lbs / 1235 Kg
Weight-Power Output Ratio : 8.2 kg/hp

BMW E87 1 Series 5 door 120i Interior size, Dimensions BMW E87 1 Series 5 door 120i Interior size, Dimensions

Num. of Seats : 5 seats
Trunk / Boot capacity : from 11.7 cu-ft / 330 L

BMW E87 1 Series 5 door 120i Brakes, Tires, Steering and Suspension BMW E87 1 Series 5 door 120i Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(11.5 inches / 292 mm)
Rear Brakes - Dics dimensions : Discs
(11.65 inches / 296 mm)
Front Tyres - Rims dimensions : 195/55 R16
Rear Tyres - Rims dimensions : 195/55 R16
Front Suspension : Independent. Double Wishbones. coil springs. anti-roll bar
Rear Suspension : Multilink. Coil springs. anti-roll bar
If you found an error in these specifications submit your correction here
What engine is in BMW E87 1 Series 5 door 120i?
The BMW E87 1 Series 5 door 120i has a Inline 4, Petrol engine with 1995 cm3 / 121.7 cu-in capacity.

How many horsepower (hp) does a 2004 BMW E87 1 Series 5 door 120i have?
The 2004 BMW E87 1 Series 5 door 120i has 150 PS / 148 bhp / 110 kW.

How much does a BMW E87 1 Series 5 door 120i weighs?
The BMW E87 1 Series 5 door 120i weighs 1235 Kg / 2723 lbs.

What is the top speed of a BMW E87 1 Series 5 door 120i?
The BMW E87 1 Series 5 door 120i top speed is 217 Km/h / 135 mph.

Is BMW E87 1 Series 5 door 120i All Wheel Drive (AWD)?
No, the BMW E87 1 Series 5 door 120i is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
