Make

Spider Series 1 Versions

- Duetto 1600 (1966)- Duetto 1750 Veloce (1967)

Alfa Romeo Spider Series 1 Duetto 1600 Specs

(1966 - 1967) - Technical Specifications for Years 1966, 1967

Key Specs

Petrol

95.8 cu-in
1570 cm³

Inline 4

108 HP
109 PS / 80 kW

102 lb-ft
139 Nm

115 Mph
185 km/h

Compare with another car

More pictures

Alfa Romeo Spider Series 1 Duetto 1600 Body, Model and Production details

Generation :	Series 1

Body :	Cabrio

Num. of Doors :	2 doors


Alfa Romeo Spider Series 1 Duetto 1600 Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	2 Weber 40 DCOE 27 carburettors

Engine Alignment :	Longitudinal

Engine displacement :	95.8 cu-in / 1570 cm³

Bore x Stroke :	3.07 x 3.23 inches 78.00 x 82.00 mm

Number of valves :	8 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.00

Horsepower :	108 HP / 109 PS / 80 kW @ 6000 rpm

Maximum torque :	102 lb-ft / 139 Nm @ 6000 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	5 speed Manual Transmission Relations Final Drive Ratio: 4.56


Alfa Romeo Spider Series 1 Duetto 1600 Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	12.2 gallons 46 L 10.1 UK gallons

Catalytic converter :	No

Alfa Romeo Spider Series 1 Duetto 1600 Performance

Top Speed :	115 Mph / 185 km/h

Acceleration 0 to 60 mph (0 to 96 Km/h) :	11.30 s

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Alfa Romeo Spider Series 1 Duetto 1600 Size, Dimensions, Aerodynamics and Weight

Wheelbase :	88.58 inches / 225 cm

Length :	167.52 inches / 425.5 cm

Width :	64.02 inches / 162.6 cm

Height :	50.98 inches / 129.5 cm

Front Axle :	51.61 inches / 131.1 cm

Rear Axle :	50 inches / 127.0 cm

Ground clearance :	5.51 inches / 14.0 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2196 lbs / 996 kg

Weight/Power Output Ratio :	9.1 kg/hp


Alfa Romeo Spider Series 1 Duetto 1600 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	-/- R-

Rear Tyres - Rims dimensions :	-/- R-

Steering :	Recirculating ball. -

Steering wheel lock-to-lock :	3.500 turns

Front Suspension :	Coil springs.

Rear Suspension :	Coil Springs. Radius arms. De-Dion axle.

What engine is in Alfa Romeo Spider Series 1 Duetto 1600?
The Alfa Romeo Spider Series 1 Duetto 1600 has a Inline 4, Petrol engine with 1570 cm³ / 95.8 cu-in capacity.

How many horsepower (hp) does a 1966 Alfa Romeo Spider Series 1 Duetto 1600 have?
The 1966 Alfa Romeo Spider Series 1 Duetto 1600 has 109 PS / 108 bhp / 80 kW.

How much does a Alfa Romeo Spider Series 1 Duetto 1600 weighs?
The Alfa Romeo Spider Series 1 Duetto 1600 weighs 996 Kg / 2196 lbs.

What is the top speed of a Alfa Romeo Spider Series 1 Duetto 1600?
The Alfa Romeo Spider Series 1 Duetto 1600 top speed is 185 Km/h / 115 mph.

Is Alfa Romeo Spider Series 1 Duetto 1600 All Wheel Drive (AWD)?
No, the Alfa Romeo Spider Series 1 Duetto 1600 is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).

How fast is a Alfa Romeo Spider Series 1 Duetto 1600?
The Alfa Romeo Spider Series 1 Duetto 1600 can reach 0 to 60 mph in 11.30 seconds and has a top speed of 115 mph.
