Volkswagen Jetta 5 1.6 FSI Specs

(2005 - 2010) - Technical Specifications for Years 2005, 2006, 2007, 2008, 2009, 2010
With a fuel consumption of 6.9 litres/100km - 41 mpg UK - 34 mpg US (Average), 0 to 100 km/h (62mph) in 11.1 seconds, a maximum top speed of 121 mph (194 km/h), a curb weight of 2802 lbs (1271 kgs), the Jetta 5 1.6 FSI has a naturally-aspirated In-line 4 cylinder engine, Petrol motor.
This engine produces a maximum power of 116 PS (114 bhp - 85 kW) at 6000 rpm and a maximum torque of 155 Nm (114 lb.ft) at 4000 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 6 speed Manual gearbox.
About chassis details responsible for road holding, handling behaviour and ride confort, the Jetta 5 Stock tire sizes are 205 / 55 on 16 inch rims at the front, and 205 / 55 on 16 inch rims at the rear. For stopping power, the Jetta 5 1.6 FSI braking system includes Vented Discs at the front and Discs at the rear.
The Jetta 5 model is a car manufactured by Volkswagen, sold new from year 2005 to 2010, and available after that as a used car.

Volkswagen Jetta 5 1.6 FSI Engine Technical Data Volkswagen Jetta 5 1.6 FSI Engine Technical Data

Engine type - Number of cylinders : I 4
Engine Code : -
Fuel type :
Petrol
Fuel System : Fuel Stratified Injection
Engine Alignment : Transverse
Engine size - Displacement - Engine capacity : 1598 cm3 or 97.5 cu-in
Bore x Stroke : 76.5 x 86.9 mm
2.99 x 3.39 inches
Number of valves : 16 Valves
Aspiration : N/A
Compression Ratio : 12.0
Maximum power - Output - Horsepower : 116 PS or 114 bhp or 85 kW @ 6000 rpm
Maximum torque : 155 Nm or 114 lb.ft @ 4000 rpm
Drive wheels - Traction - Drivetrain : FWD
Transmission Gearbox - Number of speeds :

Volkswagen Jetta 5 1.6 FSI Fuel Consumption (Economy), Emissions and Range Volkswagen Jetta 5 1.6 FSI Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 6.9 L/100km
41 mpg UK / 34 mpg US
Fuel Consumption - Economy - Extra Urban: 5.6 L/100km
50 mpg UK / 42 mpg US
Fuel Consumption - Economy - City: 9.0 L/100km
31 mpg UK / 26 mpg US
Fuel Tank Capacity : 55 L
12.1 UK gallons
14.5 US gallons
Range : 797 Km or 495 miles
CO2 emissions : 166 g/Km (Volkswagen)

Volkswagen Jetta 5 1.6 FSI Performance Volkswagen Jetta 5 1.6 FSI Performance

Top Speed : 194 km/h or 121 Mph
Acceleration 0 to 100 km/h (0 to 62 mph) : 11.1 s
Acceleration 0 to 1000m : 32.2 s

Volkswagen Jetta 5 1.6 FSI Size, Dimensions, Aerodynamics and Weight Volkswagen Jetta 5 1.6 FSI Size, Dimensions, Aerodynamics and Weight

Num. of Doors : 4
Wheelbase : 257.8 cm or 101.5 inches
Length : 455.4 cm or 179.29 inches
Width : 178.1 cm or 70.12 inches
Height : 145.9 cm or 57.44 inches
Aerodynamic drag coefficient - Cx : 0.31
Front Brakes - Disc dimensions : Vented Discs (280 mm)
Rear Brakes - Dics dimensions : Discs (260 mm)
Front Tyres - Rims dimensions : 205/55 R16
Rear Tyres - Rims dimensions : 205/55 R16
Curb Weight : 1271 kg OR 2802 lbs
Weight-Power Output Ratio : 10.96 kg/hp
Trunk / Boot capacity : 527 L

Volkswagen Jetta 5 1.6 FSI Service Light Reset

not available yet
