Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Specs

(2016 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 5.8 litres/100km - 49 mpg UK - 41 mpg US (Average), 0 to 100 km/h (62mph) in 7.7 seconds, a maximum top speed of 139 mph (224 km/h), a curb weight of 3025 lbs (1372 kgs), the Leon 3 ST 2017 1.8 TSI 180HP DSG-7 has a turbocharged Inline 4 cylinder engine, Petrol motor.
This engine produces a maximum power of 179 PS (177 bhp - 132 kW) at 5100-6200 rpm and a maximum torque of 250 Nm (184 lb.ft) at 1250-5000 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 7 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Leon 3 ST 2017 has McPherson struts. Coil springs. front suspension and Coil springs. rear suspension. Stock tire sizes are 225 / 45 on 17 inch rims at the front, and 225 / 45 on 17 inch rims at the rear. For stopping power, the Leon 3 ST 2017 1.8 TSI 180HP DSG-7 braking system includes Vented Discs at the front and Discs at the rear.
The Leon 3 ST 2017 model is a Estate car manufactured by Seat, with 5 doors and 5 seats, sold new from year 2016.

Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Body, Model and Production details

Generation :	Leon 3 2017

Body :	Estate

Num. of Doors :	5 doors


Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine size - Displacement - Engine capacity :	109.7 cu-in / 1798 cm3

Bore x Stroke :	3.25 x 3.31 inches 82.5 x 84.2 mm

Number of valves :	16 Valves

Aspiration :	Turbo + Intercooler

Compression Ratio :	9.6

Maximum power - Output - Horsepower :	177 HP / 179 PS / 132 kW @ 5100-6200 rpm

Maximum torque :	184 lb-ft / 250 Nm @ 1250-5000 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	7 speed Automatic Transmission Relations 1st Gear Ratio: 6.9 2nd Gear Ratio: 11.5 3rd Gear Ratio: 17.0 4th Gear Ratio: 23.2 5th Gear Ratio: 30.5 6th Gear Ratio: 37.7 7th Gear Ratio: 45.1 Reverse Gear Ratio: 6.6

Clutch Type :	Dual single-disc dry clutch


Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	41 MPG 5.8 L/100 Km 49 MPG UK

Range :	536 miles / 862 Km

Fuel Tank Capacity :	13.2 gallons 50 L 11 UK gallons

CO2 emissions :	134 g/Km (Seat)

Emission standard :	Euro VI

Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Performance

Top Speed :	139 Mph / 224 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	7.7 s

Acceleration 0 to 1000m :	29.1 s


Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Size, Dimensions, Aerodynamics and Weight

Wheelbase :	103.78 inches / 263.6 cm

Length :	179.09 inches / 454.9 cm

Width :	71.5 inches / 181.6 cm

Height :	57.24 inches / 145.4 cm

Front Axle :	60.55 inches / 153.8 cm

Rear Axle :	59.37 inches / 150.8 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3025 lbs / 1372 Kg

Weight-Power Output Ratio :	7.7 kg/hp


Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	20.7 cu-ft / 587 L

Trunk / Boot Second Row :	20.7 cu-ft / 587 L


Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (12.28 inches / 312 mm)

Rear Brakes - Dics dimensions :	Discs (10.71 inches / 272 mm)

Front Tyres - Rims dimensions :	225/45 R17

Rear Tyres - Rims dimensions :	225/45 R17

Front Wheels Width :	7,5"

Rear Wheels Width :	7,5"

Steering :	Rack and pinion Electric

Front Suspension :	McPherson struts. Coil springs.

Rear Suspension :	Coil springs.

What engine is in Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7?
The Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 has a Inline 4, Petrol engine with 1798 cm3 / 109.7 cu-in capacity.

How many horsepower (hp) does a 2016 Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 have?
The 2016 Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 has 179 PS / 177 bhp / 132 kW.

How much does a Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 weighs?
The Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 weighs 1372 Kg / 3025 lbs.

What is the top speed of a Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7?
The Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 top speed is 224 Km/h / 139 mph.

Is Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 All Wheel Drive (AWD)?
No, the Seat Leon 3 ST 2017 1.8 TSI 180HP DSG-7 is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
