Lexus TX 500h AWD Specs

(2023 - ) - Technical Specifications for Years 2023, 2024, 2025, 2026
Lexus TX image

Key Specs

Petrol
146 cu-in
2393 cm3
Inline 4
366 HP
371 PS / 273 kW
406 lb-ft
551 Nm
112 Mph
180 km/h

Lexus TX 500h AWD Body, Model and Production details Lexus TX 500h AWD Body, Model and Production details

Body : SUV / TT
Num. of Doors : 5 doors

Lexus TX 500h AWD Engine Technical Data Lexus TX 500h AWD Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : Toyota T24A-FTS
Fuel type : Petrol
Fuel System : Hybrid Electric Vehicle. direct injection engine + electric
Engine Alignment : Transverse
Engine Position : Front
Engine displacement : 146 cu-in / 2393 cm3
Bore x Stroke : 3.44 x 3.92 inches
87.5 x 99.5 mm
Number of valves : 16 Valves
Aspiration : Turbo
Compression Ratio : 11.0
Horsepower : 366 HP / 371 PS / 273 kW
@ 6000 rpm
Maximum torque : 406 lb-ft / 551 Nm
@ 2000-3000 rpm
Drive wheels - Traction - Drivetrain : AWD
Transmission Gearbox - Number of speeds :
6 speed Automatic Transmission Gearbox - Number of speeds
Transmission Relations
1st Gear Ratio:
2nd Gear Ratio:
3rd Gear Ratio:
4th Gear Ratio:
5th Gear Ratio:
6th Gear Ratio:
Reverse Gear Ratio: 3.20
Final Drive Ratio: 3.74

Lexus TX 500h AWD Fuel Consumption (Economy), Emissions and Range Lexus TX 500h AWD Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - EPA Highway (2008 - ): 28 MPG
34 MPG UK
8.4 L/100 km
Fuel Consumption - Economy - EPA City (2008 - ): 27 MPG
32 MPG UK
8.7 L/100 km
Fuel Consumption - Economy - EPA Combined (2008 - ): 27 MPG
32 MPG UK
8.7 L/100 km
Range (EPA): 557 miles / 897 km
Fuel Tank Capacity : 20.6 gallons
78 L
17.2 UK gallons
Catalytic converter : Yes, with Lamda-Sensor

Lexus TX 500h AWD Performance Lexus TX 500h AWD Performance

Top Speed : 112 Mph / 180 km/h
Acceleration 0 to 60 mph (0 to 96 Km/h) : 6.1 s
Acceleration 0 to 100 km/h (0 to 62 mph) : 6.4 s

Lexus TX 500h AWD Size, Dimensions, Aerodynamics and Weight Lexus TX 500h AWD Size, Dimensions, Aerodynamics and Weight

Wheelbase : 116.14 inches / 295.0 cm
Length : 203.54 inches / 517.0 cm
Width : 78.35 inches / 199.0 cm
Height : 70.08 inches / 178.0 cm
Front Axle : 67.44 inches / 171.3 cm
Rear Axle : 67.76 inches / 172.1 cm
Ground clearance : 7.99 inches / 20.3 cm
Approach angle (deg) : 17.1°
Departure angle (deg) : 22.3°
Max. Towing Capacity Weight : 5000 lbs / 2268 kg
Aerodynamic drag coefficient - Cx : 0.34
Curb Weight : 4949 lbs / 2245 kg
Weight/Power Output Ratio : 6.1 kg/hp

Lexus TX 500h AWD Interior size, Dimensions Lexus TX 500h AWD Interior size, Dimensions

Front legroom : 41.69 inches / 105.9 cm
Rear seat legroom : 39.49 inches / 100.3 cm
Third row legroom : 33.5 inches / 85.1 cm
Front shoulder room : 60.04 inches / 152.5 cm
Rear shoulder room : 59.09 inches / 150.1 cm
Third row shoulder room : 57.48 inches / 146.0 cm
Front head room : 41.46 inches / 105.3 cm
Rear head room : 40.16 inches / 102.0 cm
Third row head room : 37.2 inches / 94.5 cm
Front hip room : 56.54 inches / 143.6 cm
Rear hip room : 56.81 inches / 144.3 cm
Trunk / Boot capacity : 20.2 cu-ft / 572 L
Trunk / Boot First Row : 97 cu-ft / 2747 L
Trunk / Boot Second Row : 57.4 cu-ft / 1625 L

Lexus TX 500h AWD Brakes, Tires, Steering and Suspension Lexus TX 500h AWD Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(15.71 inches / 399 mm)
Rear Brakes - Disc dimensions : Vented Discs
(13.31 inches / 338 mm)
Front Tyres - Rims dimensions : 255/45 R22
Rear Tyres - Rims dimensions : 255/45 R22
Front Suspension : Independent. MacPherson. Coil Springs. Anti-roll bar.
Rear Suspension : Independent Double wishbone. Coil Springs. Anti-roll bar.
If you found an error in these specifications submit your correction here

How fast is a Lexus TX 500h AWD?
The Lexus TX 500h AWD can reach 0 to 100 km/h (0 to 62 mph) in 6.4 seconds and 0 to 96 km/h (0 to 60 mph) in 6.1 seconds, having a top speed of 180 km/h / 112 mph.

How many horsepower (hp) does a 2023 Lexus TX 500h AWD have?
The 2023 Lexus TX 500h AWD has 371 PS / 366 bhp / 273 kW.

How much does a Lexus TX 500h AWD weighs?
The Lexus TX 500h AWD weighs 2245 Kg / 4949 lbs.

What is the Lexus TX 500h AWD gas mileage?
The Lexus TX 500h AWD gas mileage is .

What engine is in Lexus TX 500h AWD?
The Lexus TX 500h AWD has a Inline 4, Petrol engine with 2393 cm3 / 146 cu-in capacity.

What are the dimensions of the Lexus TX 500h AWD?
The Lexus TX 500h AWD is 203.54 inches / 517.0 cm long, 78.35 inches / 199.0 cm wide, and 70.08 inches / 178.0 cm tall, with a wheelbase of 116.14 inches / 295.0 cm.

How much cargo space does a Lexus TX 500h AWD have?
The Lexus TX 500h AWD offers 20.2 cu-ft / 572 L of trunk space, which expands to 97 cu-ft / 2747 L when the rear seats are folded.
