Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Specs

(2010 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 6 litres/100km - 47 mpg UK - 39 mpg US (Average), 0 to 100 km/h (62mph) in 13.2 seconds, a maximum top speed of 104 mph (167 km/h), the Connect Kombi LWB Trend 1.8 TDCi 110cv has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 110 PS (109 bhp - 81 kW) at 3800 rpm and a maximum torque of 280 Nm (206 lb.ft) at 1700 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 5 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Connect has Independent. McPherson struts. Coil springs. Anti-roll bar. front suspension and Beam axle. Anti-roll bar. rear suspension. Stock tire sizes are 195 / 65 on 15 inch rims at the front, and 195 / 65 on 15 inch rims at the rear. For stopping power, the Connect Kombi LWB Trend 1.8 TDCi 110cv braking system includes Vented Discs at the front and Discs at the rear.
The Connect model is a car manufactured by Ford, with 4 doors and 5 seats, sold new from year 2010.

Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Body, Model and Production details

Body :	-

Num. of Doors :	4 doors


Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Engine Alignment :	Transverse

Engine size - Displacement - Engine capacity :	107 cu-in / 1753 cm3

Bore x Stroke :	3.25 x 3.23 inches 82.5 x 82 mm

Number of valves :	8 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	18.5

Maximum power - Output - Horsepower :	109 HP / 110 PS / 81 kW @ 3800 rpm

Maximum torque :	206 lb-ft / 280 Nm @ 1700 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	5 speed Manual


Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	39 MPG 6 L/100 Km 47 MPG UK

Fuel Consumption - Economy - Open road:	45 MPG 5.2 L/100 Km 54 MPG UK

Fuel Consumption - Economy - City:	31 MPG 7.6 L/100 Km 37 MPG UK

Range :	569 miles / 916 Km

Fuel Tank Capacity :	14.5 gallons 55 L 12.1 UK gallons

CO2 emissions :	159 g/Km (Ford)

Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Performance

Top Speed :	104 Mph / 167 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	13.2 s


Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Size, Dimensions, Aerodynamics and Weight

Wheelbase :	114.65 inches / 291.2 cm

Length :	178.15 inches / 452.5 cm

Width :	- inches / 179.5 cm

Height :	78.03 inches / 198.2 cm

Aerodynamic drag coefficient - Cx :	0.356

Curb Weight :	- lbs / - Kg


Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :


Ford Connect Kombi LWB Trend 1.8 TDCi 110cv Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	195/65 R15

Rear Tyres - Rims dimensions :	195/65 R15

Front Suspension :	Independent. McPherson struts. Coil springs. Anti-roll bar.

Rear Suspension :	Beam axle. Anti-roll bar.

What engine is in Ford Connect Kombi LWB Trend 1.8 TDCi 110cv?
The Ford Connect Kombi LWB Trend 1.8 TDCi 110cv has a Inline 4, Diesel engine with 1753 cm3 / 107 cu-in capacity.

How many horsepower (hp) does a 2010 Ford Connect Kombi LWB Trend 1.8 TDCi 110cv have?
The 2010 Ford Connect Kombi LWB Trend 1.8 TDCi 110cv has 110 PS / 109 bhp / 81 kW.

What is the top speed of a Ford Connect Kombi LWB Trend 1.8 TDCi 110cv?
The Ford Connect Kombi LWB Trend 1.8 TDCi 110cv top speed is 167 Km/h / 104 mph.

Is Ford Connect Kombi LWB Trend 1.8 TDCi 110cv All Wheel Drive (AWD)?
No, the Ford Connect Kombi LWB Trend 1.8 TDCi 110cv is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
