Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Specs

(2020 - ) - Technical Specifications for Years 2020, 2021, 2022, 2023

Compare with another car

More pictures

With a fuel consumption of 1.5 litres/100km - 188 mpg UK - 157 mpg US (Average), 0 to 100 km/h (62mph) in 7.7 seconds, a maximum top speed of 137 mph (220 km/h), a curb weight of 3657 lbs (1659 kgs), the Leon 4 Sportstourer 1.4 TSI e-Hybrid has a turbocharged Inline 4 cylinder engine, Hybrid / Petrol motor.
This engine produces a maximum power of 150 PS (148 bhp - 110 kW) at 5000 rpm and a maximum torque of 250 Nm (184 lb.ft) at 1550 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 6 speed Dualclutch Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Leon 4 Sportstourer has Independent McPherson. Coil Springs. Anti-roll bar. front suspension and Multilink. Coil Springs. rear suspension. Stock tire sizes are 225 / 45 on 17 inch rims at the front, and 225 / 45 on 17 inch rims at the rear. For stopping power, the Leon 4 Sportstourer 1.4 TSI e-Hybrid braking system includes Vented Discs at the front and Discs at the rear.
The Leon 4 Sportstourer model is a Estate car manufactured by Seat, with 5 doors and 5 seats, sold new from year 2020.

Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Body, Model and Production details

Generation :	Leon 4 (KL)

Body :	Estate

Num. of Doors :	5 doors


Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Plug-in Hybrid / Petrol

Fuel System :	Direct Injection

Engine Alignment :	Transverse

Engine Position :	Front

Engine size - Displacement - Engine capacity :	85.1 cu-in / 1395 cm3

Bore x Stroke :	2.93 x 3.15 inches 74.5 x 80.0 mm

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	10.0

Maximum power - Output - Horsepower :	148 HP / 150 PS / 110 kW @ 5000 rpm

Maximum torque :	184 lb-ft / 250 Nm @ 1550 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Dualclutch Automatic


Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Electric Engines Technical Data

Total System Power :	201 HP / 204 PS / 150 kW

Total System Torque :	258 lb-ft / 350 Nm

Total electric power :	114 HP / 116 PS / 85 kW

Number of electric engines:	1

Electric engine type:	Permanent magnet AC synchronous motor


Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	157 MPG 1.5 L/100 Km 188 MPG UK

Fuel Consumption - Economy - Combined WLTP:	214 MPG 1.1 L/100 Km 257 MPG UK

Range :	1657 miles / 2666 Km

Range (WLTP):	2260 miles / 3636 Km

Fuel Tank Capacity :	10.6 gallons 40 L 8.8 UK gallons

Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Battery Technical Data, Charging and Range

Range (NEDC):	44 miles / 70 Km

Range (WLTP):	37 miles / 60 Km

Battery Type :	Lithium-ion

Charging Time :	03:54 (H:m)

Battery capacity :	12.8 kWh

CO2 emissions :	34 g/Km (Seat)

CO2 emissions WLTP :	27 g/Km (Seat)

Catalytic converter :	Y

Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Performance

Top Speed :	137 Mph / 220 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	7.7 s


Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Size, Dimensions, Aerodynamics and Weight

Wheelbase :	105.75 inches / 268.6 cm

Length :	182.76 inches / 464.2 cm

Width :	70.83 inches / 179.9 cm

Height :	57.32 inches / 145.6 cm

Front Axle :	61.34 inches / 155.8 cm

Rear Axle :	59.61 inches / 151.4 cm

Max. Towing Capacity Weight :	3307 lbs / 1500 Kg

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3657 lbs / 1659 Kg

Weight-Power Output Ratio :	8.1 kg/hp


Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	from 16.6 cu-ft / 470 L


Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	225/45 R17

Rear Tyres - Rims dimensions :	225/45 R17

Turning circle :	34.4 feet / 10.5 m

Front Suspension :	Independent McPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Multilink. Coil Springs.

What engine is in Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid?
The Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid has a Inline 4, Hybrid / Petrol engine with 1395 cm3 / 85.1 cu-in capacity.
The Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid also have 1 electric engine(s) Permanent magnet AC synchronous motor.

How many horsepower (hp) does a 2020 Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid have?
The 2020 Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid has 204 PS / 201 bhp / 150 kW.

How much does a Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid weighs?
The Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid weighs 1659 Kg / 3657 lbs.

What is the top speed of a Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid?
The Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid top speed is 220 Km/h / 137 mph.

Is Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid All Wheel Drive (AWD)?
No, the Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

What is the Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid electric range?
The electric range of Seat Leon 4 Sportstourer 1.4 TSI e-Hybrid is 70 Km / 44 miles NEDC, 60 Km / 37 miles WLTP.
