Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Specs

(2015 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 10.4 litres/100km - 27 mpg UK - 23 mpg US (Average), 0 to 100 km/h (62mph) in 3.9 seconds, a maximum top speed of 155 mph (250 km/h), a curb weight of 4817 lbs (2185 kgs), the S Class Cabriolet 63 AMG 4MATIC has a turbocharged V 8 cylinder engine, Petrol motor.
This engine produces a maximum power of 585 PS (577 bhp - 430 kW) at 5500 rpm and a maximum torque of 900 Nm (663 lb.ft) at 2250-3750 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 7 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the S Class Cabriolet has Pneumatic. front suspension and Pneumatic. rear suspension. Stock tire sizes are 255 / 45 on 19 inch rims at the front, and 285 / 40 on 19 inch rims at the rear. For stopping power, the S Class Cabriolet 63 AMG 4MATIC braking system includes Vented Discs at the front and Vented Discs at the rear.
The S Class Cabriolet model is a Cabrio car manufactured by Mercedes Benz, with 2 doors and 4 seats, sold new from year 2015.

Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Body, Model and Production details

Generation :	W222

Body :	Cabrio

Num. of Doors :	2 doors


Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Engine Technical Data

Engine type - Number of cylinders :	V 8

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Direct Injection. Variable Intake

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine size - Displacement - Engine capacity :	333.3 cu-in / 5461 cm3

Bore x Stroke :	3.86 x 3.56 inches 98.0 x 90.5 mm

Number of valves :	32 Valves

Aspiration :	Turbo + Intercooler

Compression Ratio :	10.0

Maximum power - Output - Horsepower :	577 HP / 585 PS / 430 kW @ 5500 rpm

Maximum torque :	663 lb-ft / 900 Nm @ 2250-3750 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	7 speed Automatic


Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	23 MPG 10.4 L/100 Km 27 MPG UK

Range :	478 miles / 769 Km

Fuel Tank Capacity :	21.1 gallons 80 L 17.6 UK gallons

CO2 emissions :	244 g/Km (Mercedes Benz)

Emission standard :	Euro VI

Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Performance

Top Speed :	155 Mph / 250 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	3.9 s


Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Size, Dimensions, Aerodynamics and Weight

Wheelbase :	115.94 inches / 294.5 cm

Length :	198.58 inches / 504.4 cm

Width :	75.31 inches / 191.3 cm

Height :	- inches / - cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	4817 lbs / 2185 Kg

Weight-Power Output Ratio :	3.7 kg/hp


Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Interior size, Dimensions

Num. of Seats :	4 seats

Seat distribution :	2+2

Trunk / Boot capacity :


Mercedes Benz S Class Cabriolet 63 AMG 4MATIC Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Vented Discs (- inches / - mm)

Front Tyres - Rims dimensions :	255/45 R19

Rear Tyres - Rims dimensions :	285/40 R19

Front Wheels Width :	8,5"

Rear Wheels Width :	9,5"

Steering :	Rack and pinion Electric

Front Suspension :	Pneumatic.

Rear Suspension :	Pneumatic.

What engine is in Mercedes Benz S Class Cabriolet 63 AMG 4MATIC?
The Mercedes Benz S Class Cabriolet 63 AMG 4MATIC has a V 8, Petrol engine with 5461 cm3 / 333.3 cu-in capacity.

How many horsepower (hp) does a 2015 Mercedes Benz S Class Cabriolet 63 AMG 4MATIC have?
The 2015 Mercedes Benz S Class Cabriolet 63 AMG 4MATIC has 585 PS / 577 bhp / 430 kW.

How much does a Mercedes Benz S Class Cabriolet 63 AMG 4MATIC weighs?
The Mercedes Benz S Class Cabriolet 63 AMG 4MATIC weighs 2185 Kg / 4817 lbs.

What is the top speed of a Mercedes Benz S Class Cabriolet 63 AMG 4MATIC?
The Mercedes Benz S Class Cabriolet 63 AMG 4MATIC top speed is 250 Km/h / 155 mph.

Is Mercedes Benz S Class Cabriolet 63 AMG 4MATIC All Wheel Drive (AWD)?
Yes, the Mercedes Benz S Class Cabriolet 63 AMG 4MATIC is All Wheel Drive (AWD).
