Mercedes Benz G Class (W463) 350 BlueTEC L Specs

(2008 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 11.2 litres/100km - 25 mpg UK - 21 mpg US (Average), 0 to 100 km/h (62mph) in 9.1 seconds, a maximum top speed of 109 mph (175 km/h), a curb weight of 5512 lbs (2500 kgs), the G Class (W463) 350 BlueTEC L has a turbocharged V 6 cylinder engine, Diesel motor.
This engine produces a maximum power of 211 PS (208 bhp - 155 kW) at 3400 rpm and a maximum torque of 540 Nm (398 lb.ft) at 1600-2400 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 7 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the G Class (W463) has Coil springs. Beam axle. front suspension and Coil springs. Beam axle. rear suspension. Stock tire sizes are 265 / 70 on 16 inch rims at the front, and 265 / 70 on 16 inch rims at the rear. For stopping power, the G Class (W463) 350 BlueTEC L braking system includes Discs at the front and Discs at the rear.
The G Class (W463) model is a TT car manufactured by Mercedes Benz, with 5 doors and 5 seats, sold new from year 2008.

Mercedes Benz G Class (W463) 350 BlueTEC L Body, Model and Production details

Generation :	W463

Body :	TT

Num. of Doors :	5 doors


Mercedes Benz G Class (W463) 350 BlueTEC L Engine Technical Data

Engine type - Number of cylinders :	V 6

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine size - Displacement - Engine capacity :	182.3 cu-in / 2987 cm3

Bore x Stroke :	3.27 x 3.62 inches 83.0 x 92.0 mm

Number of valves :	24 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	17

Maximum power - Output - Horsepower :	208 HP / 211 PS / 155 kW @ 3400 rpm

Maximum torque :	398 lb-ft / 540 Nm @ 1600-2400 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	7 speed Automatic


Mercedes Benz G Class (W463) 350 BlueTEC L Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	21 MPG 11.2 L/100 Km 25 MPG UK

Fuel Consumption - Economy - Open road:	24 MPG 9.8 L/100 Km 29 MPG UK

Fuel Consumption - Economy - City:	17 MPG 13.6 L/100 Km 21 MPG UK

Range :	533 miles / 857 Km

Fuel Tank Capacity :	25.4 gallons 96 L 21.1 UK gallons

CO2 emissions :	295 g/Km (Mercedes Benz)

Mercedes Benz G Class (W463) 350 BlueTEC L Performance

Top Speed :	109 Mph / 175 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	9.1 s


Mercedes Benz G Class (W463) 350 BlueTEC L Size, Dimensions, Aerodynamics and Weight

Wheelbase :	112.2 inches / 285.0 cm

Length :	183.54 inches / 466.2 cm

Width :	69.29 inches / 176.0 cm

Height :	76.02 inches / 193.1 cm

Front Axle :	58.07 inches / 147.5 cm

Rear Axle :	58.07 inches / 147.5 cm

Ground clearance :	8.07 inches / 20.5 cm

Approach angle (deg) :	34.0°

Departure angle (deg) :	29.0°

Aerodynamic drag coefficient - Cx :	0.54

Curb Weight :	5512 lbs / 2500 Kg

Weight-Power Output Ratio :	11.8 kg/hp


Mercedes Benz G Class (W463) 350 BlueTEC L Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	17 cu-ft / 480 L

Trunk / Boot First Row :	79.5 cu-ft / 2250 L

Trunk / Boot Second Row :	17 cu-ft / 480 L


Mercedes Benz G Class (W463) 350 BlueTEC L Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	265/70 R16

Rear Tyres - Rims dimensions :	265/70 R16

Front Wheels Width :	7,5"

Rear Wheels Width :	7,5"

Steering :	Recirculating ball

Front Suspension :	Coil springs. Beam axle.

Rear Suspension :	Coil springs. Beam axle.

What engine is in Mercedes Benz G Class (W463) 350 BlueTEC L?
The Mercedes Benz G Class (W463) 350 BlueTEC L has a V 6, Diesel engine with 2987 cm3 / 182.3 cu-in capacity.

How many horsepower (hp) does a 2008 Mercedes Benz G Class (W463) 350 BlueTEC L have?
The 2008 Mercedes Benz G Class (W463) 350 BlueTEC L has 211 PS / 208 bhp / 155 kW.

How much does a Mercedes Benz G Class (W463) 350 BlueTEC L weighs?
The Mercedes Benz G Class (W463) 350 BlueTEC L weighs 2500 Kg / 5512 lbs.

What is the top speed of a Mercedes Benz G Class (W463) 350 BlueTEC L?
The Mercedes Benz G Class (W463) 350 BlueTEC L top speed is 175 Km/h / 109 mph.

Is Mercedes Benz G Class (W463) 350 BlueTEC L All Wheel Drive (AWD)?
Yes, the Mercedes Benz G Class (W463) 350 BlueTEC L is All Wheel Drive (AWD).
