Volvo XC60 Summum D5 AWD Body, Model and Production details
|
|
| Generation : | 1st Generation |
| Body : | TT |
| Num. of Doors : | 5 doors |
Volvo XC60 Summum D5 AWD Engine Technical Data
|
|
| Engine type - Number of cylinders : | Inline 5 |
| Engine Code : | - |
| Fuel type : | Diesel |
| Fuel System : | Direct Injection. |
| Engine Alignment : | Transverse |
| Engine Position : | Front |
| Engine displacement : | 146.5 cu-in / 2401 cm3 |
| Bore x Stroke : |
3.19 x 3.67 inches 81.0 x 93.2 mm |
| Number of valves : | 20 Valves |
| Aspiration : | Turbo (TGV) + Intercooler |
| Compression Ratio : | 17 |
| Horsepower : |
212 HP / 215 PS / 158 kW @ 4000 rpm |
| Maximum torque : |
309 lb-ft / 420 Nm @ 1500-3250 rpm |
| Drive wheels - Traction - Drivetrain : | AWD |
| Transmission Gearbox - Number of speeds : |
6 speed Manual
Transmission Relations
1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: 6th Gear Ratio: |
Volvo XC60 Summum D5 AWD Fuel Consumption (Economy), Emissions and Range
|
|
| Fuel Consumption - Economy - City NEDC : |
36 MPG 6.5 L/100 km 43 MPG UK |
| Fuel Consumption - Economy - Open road NEDC : |
46 MPG 5.1 L/100 km 55 MPG UK |
| Fuel Consumption - Economy - Combined NEDC : |
42 MPG 5.6 L/100 km 50 MPG UK |
| Range : | 777 miles / 1250 km |
| Fuel Tank Capacity : |
18.5 gallons 70 L 15.4 UK gallons |
| CO2 emissions : | 149 g/km (Volvo) |
| Emission standard : | Euro V |
Volvo XC60 Summum D5 AWD Safety Ratings |
|
| Euro NCAP |
Volvo XC60 Summum D5 AWD
Euro NCAP Safety Rating
Adult: Pedestrian: Child: Safety Assist: 94 % 48 % 79 % 86 %
Tested on: 2 / 2009
|
Volvo XC60 Summum D5 AWD Performance
|
|
| Top Speed : | 131 Mph / 210 km/h |
| Acceleration 0 to 100 km/h (0 to 62 mph) : | 8.1 s |
Volvo XC60 Summum D5 AWD Size, Dimensions, Aerodynamics and Weight
|
|
| Wheelbase : | 109.21 inches / 277.4 cm |
| Length : | 182.17 inches / 462.7 cm |
| Width : | 74.45 inches / 189.1 cm |
| Height : | 67.44 inches / 171.3 cm |
| Front Axle : | 64.25 inches / 163.2 cm |
| Rear Axle : | 62.44 inches / 158.6 cm |
| Ground clearance : | 9.06 inches / 23.0 cm |
| Approach angle (deg) : | 22.0° |
| Breakover (Rampover) angle (deg) : | 22.0° |
| Departure angle (deg) : | 27.0° |
| Aerodynamic drag coefficient - Cx : | 0.35 |
Volvo XC60 Summum D5 AWD Interior size, Dimensions
|
|
| Num. of Seats : | 5 seats |
| Seat distribution : | 2+3 |
| Trunk / Boot capacity : | 17.5 cu-ft / 495 L |
| Trunk / Boot First Row : | 51.4 cu-ft / 1455 L |
Volvo XC60 Summum D5 AWD Brakes, Tires, Steering and Suspension
|
|||
| Front Brakes - Disc dimensions : |
Vented Discs (12.91 inches / 328 mm) |
||
| Rear Brakes - Disc dimensions : |
Vented Discs (11.89 inches / 302 mm) |
||
| Front Tyres - Rims dimensions : | 235/60 R18 | ||
| Rear Tyres - Rims dimensions : | 235/60 R18 | ||
| Front Wheels Width : | 7.5" | ||
| Rear Wheels Width : | 7.5" | ||
| Steering : | Rack and pinion | ||
| Steering wheel lock-to-lock : | 2.9 turns | ||
| Steering ratio : | 16.0 | ||
| Front Suspension : | MacPherson struts. Coil springs. | ||
| Rear Suspension : | Coil Springs. | ||
