Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Spec

(2009 - 2011) - Technical Specifications for Years 2009, 2010, 2011
Show more ImagesShow more ImagesCompare with another carCompare with another car
With a fuel consumption of 6.4 litres/100km - 44 mpg UK - 37 mpg US (Average), 0 to 100 km/h (62mph) in 10.5 seconds, a maximum top speed of 114 mph (184 km/h), a curb weight of 3693 lbs (1675 kgs), the Tiguan R-Line 2.0 TDI 140HP 4Motion DSG has a turbocharged In-line 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 140 PS (138 bhp - 103 kW) at 4200 rpm and a maximum torque of 320 Nm (236 lb.ft) at 1750-2500 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 7 speed Automatic gearbox.
About chassis details responsible for road holding, handling behaviour and ride confort, the Tiguan has McPherson struts. Coil springs. front suspension and Coil springs. rear suspension. Stock tire sizes are 255 / 40 on 19 inch rims at the front, and 255 / 40 on 19 inch rims at the rear. For stopping power, the Tiguan R-Line 2.0 TDI 140HP 4Motion DSG braking system includes Vented Discs at the front and Discs at the rear.
The Tiguan model is a TT car manufactured by Volkswagen, with 5 doors and 5 seats, sold new from year 2009 to 2011, and available after that as a used car.

Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Engine Technical Data Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Engine Technical Data
Engine type - Number of cylinders : I 4
Engine Code : -
Fuel type : Diesel
Fuel System : Direct Injection.
Engine Alignment : Transverse
Engine Position : Front
Engine size - Displacement - Engine capacity : 1968 cm3 or 120.1 cu-in
Bore x Stroke : 81.0 x 95.5 mm
3.19 x 3.74 inches
Number of valves : 16 Valves
Aspiration : Turbo (TGV) + Intercooler
Compression Ratio : 17
Maximum power - Output - Horsepower : 140 PS or 138 bhp or 103 kW @ 4200 rpm
Maximum torque : 320 Nm or 236 lb.ft @ 1750-2500 rpm
Drive wheels - Traction - Drivetrain : AWD
Transmission Gearbox - Number of speeds :
7 speed Automatic Transmission relations
Transmission Relations
1st Gear Ratio: 7.5
2nd Gear Ratio: 12.6
3rd Gear Ratio: 20.1
4th Gear Ratio: 28.3
5th Gear Ratio: 36.8
6th Gear Ratio: 46.3
7th Gear Ratio: 55.5
Reverse Gear Ratio: 9.5
Final Drive Ratio: -
Clutch Type : Dual single-disc dry clutch

Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Fuel Consumption (Economy), Emissions and Range Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Fuel Consumption (Economy), Emissions and Range
Fuel Consumption - Economy - Combined: 6.4 L/100km
44 mpg UK / 37 mpg US
Fuel Consumption - Economy - Extra Urban: 5.7 L/100km
50 mpg UK / 41 mpg US
Fuel Consumption - Economy - City: 7.8 L/100km
36 mpg UK / 30 mpg US
Range : 1000 Km or 622 miles
Fuel Tank Capacity : 64 L
14.1 UK gallons
16.9 US gallons
CO2 emissions : 169 g/Km (Volkswagen)

Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Performance Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Performance
Top Speed : 184 km/h or 114 Mph
Acceleration 0 to 100 km/h (0 to 62 mph) : 10.5 s

Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Size, Dimensions, Aerodynamics and Weight Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Size, Dimensions, Aerodynamics and Weight
Body : TT
Num. of Doors : 5
Wheelbase : 260.4 cm or 102.52 inches
Length : 442.7 cm or 174.29 inches
Width : 180.9 cm or 71.22 inches
Height : 168.6 cm or 66.38 inches
Front Axle : 157 cm or 61.81 inches
Rear Axle : 157 cm or 61.81 inches
Num. of Seats : 5
Aerodynamic drag coefficient - Cx : 0.37
Front Brakes - Disc dimensions : Vented Discs (312 mm)
Rear Brakes - Dics dimensions : Discs (286 mm)
Front Tyres - Rims dimensions : 255/40 R19
Rear Tyres - Rims dimensions : 255/40 R19
Front Wheels Width : 9,0"
Rear Wheels Width : 9,0"
Curb Weight : 1675 kg OR 3693 lbs
Weight-Power Output Ratio : 12 kg/hp
Trunk / Boot capacity : 395 L
Steering : Rack and pinion Electric
Front Suspension : McPherson struts. Coil springs.
Rear Suspension : Coil springs.

Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG Service Light Reset
not available yet
How much horsepower does a 2009 Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG have?
The 2009 Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG has 140 PS / 138 bhp / 103 kW horsepower.

How much does a Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG weighs?
The Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG weighs 1675 Kg / 3693 lbs.

What is the top speed of a Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG?
The Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG top speed is 184 Km/h / 114 mph.

Is Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG All Wheel Drive (AWD)?
Yes, the Volkswagen Tiguan R-Line 2.0 TDI 140HP 4Motion DSG is All Wheel Drive (AWD).
