Seat Altea 2.0 FSI Specs

(2004 - ) Years Technical Specifications

Show more Images

Compare with another car

With a fuel consumption of 8.3 litres/100km - 34 mpg UK - 28 mpg US (Average), 0 to 100 km/h (62mph) in 9.6 seconds, a maximum top speed of 128 mph (206 km/h), a curb weight of 3031 lbs (1375 kgs), the Altea 2.0 FSI has a naturally-aspirated In-line 4 cylinder engine, Petrol motor.
This engine produces a maximum power of 150 PS (148 bhp - 110 kW) at 6000 rpm and a maximum torque of 200 Nm (147 lb.ft) at 3500 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 6 speed Manual gearbox.
About chassis details responsible for road holding, handling behaviour and ride confort, the Altea Stock tire sizes are 205 / 55 on 16 inch rims at the front, and 205 / 55 on 16 inch rims at the rear. For stopping power, the Altea 2.0 FSI braking system includes Vented Discs at the front and Discs at the rear.
The Altea model is a car manufactured by Seat, sold new from year 2004.

Seat Altea 2.0 FSI Engine Technical Data

Engine type - Number of cylinders :	I 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Fuel Stratified Injection

Engine Alignment :	Transverse

Engine size - Displacement - Engine capacity :	1984 cm3 or 121.1 cu-in

Bore x Stroke :	82.5 x 92.8 mm 3.23 x 3.62 inches

Number of valves :	16 Valves

Aspiration :	N/A

Compression Ratio :	11.5

Maximum power - Output - Horsepower :	150 PS or 148 bhp or 110 kW @ 6000 rpm

Maximum torque :	200 Nm or 147 lb.ft @ 3500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: 6th Gear Ratio: Reverse Gear Ratio: Final Drive Ratio:


Seat Altea 2.0 FSI Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	8.3 L/100km 34 mpg UK / 28 mpg US

Fuel Consumption - Economy - Extra Urban:	6.6 L/100km 43 mpg UK / 36 mpg US

Fuel Consumption - Economy - City:	11.4 L/100km 25 mpg UK / 21 mpg US

Fuel Tank Capacity :	55 L 12.1 UK gallons 14.5 US gallons

Range :	662 Km or 411 miles

CO2 emissions :	200 g/Km (Seat)

Seat Altea 2.0 FSI Performance

Top Speed :	206 km/h or 128 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	9.6 s

Acceleration 0 to 1000m :	30.8 s

Seat Altea 2.0 FSI Size, Dimensions, Aerodynamics and Weight

Num. of Doors :	5

Wheelbase :	257.8 cm or 101.5 inches

Length :	428 cm or 168.5 inches

Width :	176.8 cm or 69.61 inches

Height :	156.8 cm or 61.73 inches

Aerodynamic drag coefficient - Cx :	0.32

Front Brakes - Disc dimensions :	Vented Discs (- mm)

Rear Brakes - Dics dimensions :	Discs (- mm)

Front Tyres - Rims dimensions :	205/55 R16

Rear Tyres - Rims dimensions :	205/55 R16

Curb Weight :	1375 kg OR 3031 lbs

Weight-Power Output Ratio :	9.17 kg/hp

Trunk / Boot capacity :	409 L
