MG TF 160 Specs

(2002 - 2005) - Technical Specifications for Years 2002, 2003, 2004, 2005
MG TF image
With a fuel consumption of 7.5 litres/100km - 38 mpg UK - 31 mpg US (Average), 0 to 100 km/h (62mph) in 7.6 seconds, a maximum top speed of 137 mph (220 km/h), a curb weight of 2458 lbs (1115 kgs), the TF 160 has a naturally-aspirated Inline 4 cylinder engine, Petrol motor.
This engine produces a maximum power of 160 PS (158 bhp - 118 kW) at 6900 rpm and a maximum torque of 165 Nm (121 lb.ft) at 5000 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 5 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the TF has Independent. Double Wishbones. coil springs. anti-roll bar front suspension and Multilink. Coil springs. anti-roll bar rear suspension. Stock tire sizes are 215 / 40 on 16 inch rims at the front, and 215 / 40 on 16 inch rims at the rear. For stopping power, the TF 160 braking system includes Vented Discs at the front and Discs at the rear.
The TF model is a car manufactured by MG, with 2 doors and 2 seats, sold new from year 2002 until 2005, and available after that as a used car.

MG TF 160 Body, Model and Production details MG TF 160 Body, Model and Production details

Body : -
Num. of Doors : 2 doors

MG TF 160 Engine Technical Data MG TF 160 Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Petrol
Fuel System : MPI
Engine Alignment : Longitudinal
Engine size - Displacement - Engine capacity : 109.6 cu-in / 1796 cm3
Bore x Stroke : 3.15 x 3.52 inches
80.0 x 89.3 mm
Number of valves : 16 Valves
Aspiration : N/A
Compression Ratio : 10.5
Maximum power - Output - Horsepower : 158 HP / 160 PS / 118 kW
@ 6900 rpm
Maximum torque : 121 lb-ft / 165 Nm
@ 5000 rpm
Drive wheels - Traction - Drivetrain : RWD
Transmission Gearbox - Number of speeds :

MG TF 160 Fuel Consumption (Economy), Emissions and Range MG TF 160 Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 31 MPG
7.5 L/100 Km
38 MPG UK
Fuel Consumption - Economy - Open road: 41 MPG
5.7 L/100 Km
50 MPG UK
Fuel Consumption - Economy - City: 22 MPG
10.6 L/100 Km
27 MPG UK
Range : 414 miles / 666 Km
Fuel Tank Capacity : 13.2 gallons
50 L
11 UK gallons
CO2 emissions : 179 g/Km (MG)

MG TF 160 Performance MG TF 160 Performance

Top Speed : 137 Mph / 220 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 7.6 s

MG TF 160 Size, Dimensions, Aerodynamics and Weight MG TF 160 Size, Dimensions, Aerodynamics and Weight

Wheelbase : 93.7 inches / 238.0 cm
Length : 155.12 inches / 394.0 cm
Width : 64.17 inches / 163.0 cm
Height : 49.61 inches / 126.0 cm
Aerodynamic drag coefficient - Cx : -
Curb Weight : 2458 lbs / 1115 Kg
Weight-Power Output Ratio : 7 kg/hp

MG TF 160 Interior size, Dimensions MG TF 160 Interior size, Dimensions

Num. of Seats : 2 seats
Trunk / Boot capacity : 7.4 cu-ft / 210 L

MG TF 160 Brakes, Tires, Steering and Suspension MG TF 160 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(11.97 inches / 304 mm)
Rear Brakes - Dics dimensions : Discs
(9.45 inches / 240 mm)
Front Tyres - Rims dimensions : 215/40 R16
Rear Tyres - Rims dimensions : 215/40 R16
Front Suspension : Independent. Double Wishbones. coil springs. anti-roll bar
Rear Suspension : Multilink. Coil springs. anti-roll bar
If you found an error in these specifications submit your correction here
What engine is in MG TF 160?
The MG TF 160 has a Inline 4, Petrol engine with 1796 cm3 / 109.6 cu-in capacity.

How many horsepower (hp) does a 2002 MG TF 160 have?
The 2002 MG TF 160 has 160 PS / 158 bhp / 118 kW.

How much does a MG TF 160 weighs?
The MG TF 160 weighs 1115 Kg / 2458 lbs.

What is the top speed of a MG TF 160?
The MG TF 160 top speed is 220 Km/h / 137 mph.

Is MG TF 160 All Wheel Drive (AWD)?
No, the MG TF 160 is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
