Lancia Flaminia 3C 2800 Zagato Specs

(1963 - ) Years Technical Specifications
With a maximum top speed of 131 mph (210 km/h), a curb weight of 2822 lbs (1280 kgs), the Flaminia 3C 2800 Zagato has a naturally-aspirated V 6 cylinder engine, Petrol motor, with the engine code 826.200.
This engine produces a maximum power of 150 PS (148 bhp - 110 kW) at 5400 rpm and a maximum torque of 224.0 Nm (165 lb.ft) at 5400 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 4 speed Manual gearbox.
About chassis details responsible for road holding, handling behaviour and ride confort, the Flaminia has Coil springs. front suspension and Semi-elliptic leaf springs. De Dion axle. rear suspension. For stopping power, the Flaminia 3C 2800 Zagato braking system includes Discs at the front and Discs at the rear.
The Flaminia model is a Coupé car manufactured by Lancia, with 2 doors and - seats, sold new from year 1963.

Lancia Flaminia 3C 2800 Zagato Engine Technical Data Lancia Flaminia 3C 2800 Zagato Engine Technical Data

Engine type - Number of cylinders : V 6
Engine Code : 826.200
Fuel type :
Petrol
Fuel System : 3 Weber carbs
Coolant : Water
Engine Alignment : Longitudinal
Engine size - Displacement - Engine capacity : 2775 cm3 or 169.3 cu-in
Bore x Stroke : 85.00 x 81.50 mm
3.35 x 3.19 inches
Number of valves : 12 Valves
Aspiration : N/A
Compression Ratio : 9.00
Maximum power - Output - Horsepower : 150 PS or 148 bhp or 110 kW @ 5400 rpm
Maximum torque : 224.0 Nm or 165 lb.ft @ 5400 rpm
Drive wheels - Traction - Drivetrain : RWD
Transmission Gearbox - Number of speeds :

Lancia Flaminia 3C 2800 Zagato Fuel Consumption (Economy), Emissions and Range Lancia Flaminia 3C 2800 Zagato Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: - L/100km
Fuel Consumption - Economy - Extra Urban: - L/100km
Fuel Consumption - Economy - City: - L/100km
Fuel Tank Capacity : 56.8 L
12.3 UK gallons
14.8 US gallons
CO2 emissions : - g/Km

Lancia Flaminia 3C 2800 Zagato Performance Lancia Flaminia 3C 2800 Zagato Performance

Top Speed : 210 km/h or 131 Mph
Acceleration 0 to 100 km/h (0 to 62 mph) : - s

Lancia Flaminia 3C 2800 Zagato Size, Dimensions, Aerodynamics and Weight Lancia Flaminia 3C 2800 Zagato Size, Dimensions, Aerodynamics and Weight

Body : Coupé
Num. of Doors : 2
Wheelbase : 252 cm or 99.21 inches
Length : 442 cm or 174.02 inches
Width : 165 cm or 64.96 inches
Height : 128 cm or 50.39 inches
Front Axle : 1368 cm or 538.58 inches
Rear Axle : 1370 cm or 539.37 inches
Aerodynamic drag coefficient - Cx : -
Front Brakes - Disc dimensions : Discs (- mm)
Rear Brakes - Dics dimensions : Discs (- mm)
Front Tyres - Rims dimensions : -/- R-
Rear Tyres - Rims dimensions : -/- R-
Curb Weight : 1280 kg OR 2822 lbs
Weight-Power Output Ratio : 8.6 kg/hp
Trunk / Boot capacity : - L
Steering : Endless screw. -
Front Suspension : Coil springs.
Rear Suspension : Semi-elliptic leaf springs. De Dion axle.
