Lancia Flaminia 3C 2800 Zagato Specs

(1963 - ) Technical Specifications

Compare with another car

More pictures

With a maximum top speed of 131 mph (210 km/h), a curb weight of 2822 lbs (1280 kgs), the Flaminia 3C 2800 Zagato has a naturally-aspirated V 6 cylinder engine, Petrol motor, with the engine code 826.200.
This engine produces a maximum power of 150 PS (148 bhp - 110 kW) at 5400 rpm and a maximum torque of 224.0 Nm (165 lb.ft) at 5400 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 4 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Flaminia has Coil springs. front suspension and Semi-elliptic leaf springs. De Dion axle. rear suspension. For stopping power, the Flaminia 3C 2800 Zagato braking system includes Discs at the front and Discs at the rear.
The Flaminia model is a Coupé car manufactured by Lancia, sold new from year 1963.

Lancia Flaminia 3C 2800 Zagato Body, Model and Production details

Body :	Coupé

Num. of Doors :	2 doors


Lancia Flaminia 3C 2800 Zagato Engine Technical Data

Engine type - Number of cylinders :	V 6

Engine Code :	826.200

Fuel type :	Petrol

Fuel System :	3 Weber carbs

Engine Alignment :	Longitudinal

Engine size - Displacement - Engine capacity :	169.3 cu-in / 2775 cm3

Bore x Stroke :	3.35 x 3.21 inches 85.00 x 81.50 mm

Number of valves :	12 Valves

Aspiration :	N/A

Compression Ratio :	9.00

Maximum power - Output - Horsepower :	148 HP / 150 PS / 110 kW @ 5400 rpm

Maximum torque :	165 lb-ft / 224.0 Nm @ 5400 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	4 speed Manual


Lancia Flaminia 3C 2800 Zagato Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	14.8 gallons 56.8 L 12.3 UK gallons

Catalytic converter :	No

Lancia Flaminia 3C 2800 Zagato Performance

Top Speed :	131 Mph / 210 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s

Lancia Flaminia 3C 2800 Zagato Size, Dimensions, Aerodynamics and Weight

Wheelbase :	99.21 inches / 252 cm

Length :	174.02 inches / 442 cm

Width :	64.96 inches / 165 cm

Height :	50.39 inches / 128 cm

Front Axle :	53.86 inches / 136.8 cm

Rear Axle :	53.94 inches / 137.0 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2822 lbs / 1280 Kg

Weight-Power Output Ratio :	8.5 kg/hp

Trunk / Boot capacity :


Lancia Flaminia 3C 2800 Zagato Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	-/- R-

Rear Tyres - Rims dimensions :	-/- R-

Steering :	Endless screw. -

Front Suspension :	Coil springs.

Rear Suspension :	Semi-elliptic leaf springs. De Dion axle.

What engine is in Lancia Flaminia 3C 2800 Zagato?
The Lancia Flaminia 3C 2800 Zagato has a V 6, Petrol engine with 2775 cm3 / 169.3 cu-in capacity.

How many horsepower (hp) does a 1963 Lancia Flaminia 3C 2800 Zagato have?
The 1963 Lancia Flaminia 3C 2800 Zagato has 150 PS / 148 bhp / 110 kW.

How much does a Lancia Flaminia 3C 2800 Zagato weighs?
The Lancia Flaminia 3C 2800 Zagato weighs 1280 Kg / 2822 lbs.

What is the top speed of a Lancia Flaminia 3C 2800 Zagato?
The Lancia Flaminia 3C 2800 Zagato top speed is 210 Km/h / 131 mph.

Is Lancia Flaminia 3C 2800 Zagato All Wheel Drive (AWD)?
No, the Lancia Flaminia 3C 2800 Zagato is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
