Transit Custom Van L1 2024 Versions

Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Specs

(2023 - ) - Technical Specifications for Years 2023, 2024, 2025

Diesel

122 cu-in
2000 cm³

Inline 4

134 HP
136 PS / 100 kW

265 lb-ft
360 Nm

Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Body, Model and Production details

Generation :	Transit Custom 2 - 2024 New Model

Body :	Van

Num. of Doors :	4 doors


Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	BJFA

Fuel type :	Diesel

Fuel System :	Common Rail

Lubrication :	See oil information Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Oil Specifications - Engine oil All Weather: 5W30 OEM: WSS-M2C913-D API/ACEA: ACEA A5/B5 Engine oil capacity (with filter): 9.3 L

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	122 cu-in / 2000 cm³

Bore x Stroke :	3.31 x 3.54 inches 84.0 x 90.0 mm

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	15.8

Horsepower :	134 HP / 136 PS / 100 kW @ 3250-3500 rpm

Maximum torque :	265 lb-ft / 360 Nm @ 1500-2500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	14.5 gallons 55 L 12.1 UK gallons

Emission standard :	Euro 6d - WLTP

Catalytic converter :	Particle Filter (with SCR cat.)

Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Size, Dimensions, Aerodynamics and Weight

Wheelbase :	122.05 inches / 310.0 cm

Length :	198.82 inches / 505.0 cm

Width :	78.7 inches / 199.9 cm

Width with mirrors :	89.57 inches / 227.5 cm

Height :	- inches / - cm

Front Axle :	67.91 inches / 172.5 cm

Rear Axle :	67.56 inches / 171.6 cm

Cargo box inside length :	102.44 inches / 260.2 cm

Cargo box inside height :	56.18 inches / 142.7 cm

Cargo width :	69.96 inches / 177.7 cm

Max. width at wheelhouse :	54.8 inches / 139.2 cm

Loading height :	22.48 inches / 57.1 cm

Rear door width :	55.12 inches / 140.0 cm

Rear door height :	51.81 inches / 131.6 cm

Side door width :	40.55 inches / 103.0 cm

Side door height :	51.22 inches / 130.1 cm

Aerodynamic drag coefficient - Cx :	-


Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Interior size, Dimensions

Num. of Seats :	3 seats

Seat distribution :	3

Trunk / Boot capacity :	204.8 cu-ft / 5800 L


Ford Transit Custom Van L1 2024 280 2.0 EcoBlue 136HP Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (12.13 inches / 308 mm)

Rear Brakes - Disc dimensions :	Discs (11.97 inches / 304 mm)

Front Tyres - Rims dimensions :	215/65 R16

Rear Tyres - Rims dimensions :	215/65 R16

Front Suspension :	MacPherson struts. Coil springs. Anti-roll bar.

Rear Suspension :	Independent. Coil Springs. Anti-roll bar.
