Citroen C4 Picasso HDi 110 SX Specs

(2010 - ) Technical Specifications
Citroen C4 Picasso image
With a fuel consumption of 5.3 litres/100km - 53 mpg UK - 44 mpg US (Average), 0 to 100 km/h (62mph) in 12.5 seconds, a maximum top speed of 112 mph (180 km/h), a curb weight of 3448 lbs (1564 kgs), the C4 Picasso HDi 110 SX has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 109 PS (108 bhp - 80 kW) at 4000 rpm and a maximum torque of 240 Nm (177 lb.ft) at 1750 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 5 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the C4 Picasso has Independent. McPherson struts. Coil springs. Anti-roll bar. front suspension and Semi-Independent. Coil springs. Torsion bar. rear suspension. Stock tire sizes are 215 / 55 on 16 inch rims at the front, and 215 / 55 on 16 inch rims at the rear. For stopping power, the C4 Picasso HDi 110 SX braking system includes Vented Discs at the front and Discs at the rear.
The C4 Picasso model is a car manufactured by Citroen, with 5 doors and 5 seats, sold new from year 2010.

Citroen C4 Picasso HDi 110 SX Body, Model and Production details Citroen C4 Picasso HDi 110 SX Body, Model and Production details

Generation : C4 Picasso 1
Body : -
Num. of Doors : 5 doors

Citroen C4 Picasso HDi 110 SX Engine Technical Data Citroen C4 Picasso HDi 110 SX Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Diesel
Engine Alignment : Transverse
Engine size - Displacement - Engine capacity : 95.2 cu-in / 1560 cm3
Bore x Stroke : 2.95 x 3.48 inches
75 x 88.3 mm
Number of valves : 16 Valves
Aspiration : Turbo (TGV) + Intercooler
Compression Ratio : 18
Maximum power - Output - Horsepower : 108 HP / 109 PS / 80 kW
@ 4000 rpm
Maximum torque : 177 lb-ft / 240 Nm
@ 1750 rpm
Drive wheels - Traction - Drivetrain : FWD
Transmission Gearbox - Number of speeds :

Citroen C4 Picasso HDi 110 SX Fuel Consumption (Economy), Emissions and Range Citroen C4 Picasso HDi 110 SX Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 44 MPG
5.3 L/100 Km
53 MPG UK
Fuel Consumption - Economy - Open road: 52 MPG
4.5 L/100 Km
63 MPG UK
Fuel Consumption - Economy - City: 35 MPG
6.7 L/100 Km
42 MPG UK
Range : 704 miles / 1132 Km
Fuel Tank Capacity : 15.9 gallons
60 L
13.2 UK gallons
CO2 emissions : 140 g/Km (Citroen)

Citroen C4 Picasso HDi 110 SX Safety Ratings

Euro NCAP

Citroen C4 Picasso HDi 110 SX Performance Citroen C4 Picasso HDi 110 SX Performance

Top Speed : 112 Mph / 180 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 12.5 s
Acceleration 0 to 1000m : 34.1 s

Citroen C4 Picasso HDi 110 SX Size, Dimensions, Aerodynamics and Weight Citroen C4 Picasso HDi 110 SX Size, Dimensions, Aerodynamics and Weight

Wheelbase : 107.4 inches / 272.8 cm
Length : 175.98 inches / 447.0 cm
Width : - inches / 183.0 cm
Height : 66.14 inches / 168.0 cm
Aerodynamic drag coefficient - Cx : 0.31
Curb Weight : 3448 lbs / 1564 Kg
Weight-Power Output Ratio : 14.3 kg/hp

Citroen C4 Picasso HDi 110 SX Interior size, Dimensions Citroen C4 Picasso HDi 110 SX Interior size, Dimensions

Num. of Seats : 5 seats
Trunk / Boot capacity :

Citroen C4 Picasso HDi 110 SX Brakes, Tires, Steering and Suspension Citroen C4 Picasso HDi 110 SX Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(11.14 inches / 283 mm)
Rear Brakes - Dics dimensions : Discs
(10.55 inches / 268 mm)
Front Tyres - Rims dimensions : 215/55 R16
Rear Tyres - Rims dimensions : 215/55 R16
Front Suspension : Independent. McPherson struts. Coil springs. Anti-roll bar.
Rear Suspension : Semi-Independent. Coil springs. Torsion bar.
If you found an error in these specifications submit your correction here
What engine is in Citroen C4 Picasso HDi 110 SX?
The Citroen C4 Picasso HDi 110 SX has a Inline 4, Diesel engine with 1560 cm3 / 95.2 cu-in capacity.

How many horsepower (hp) does a 2010 Citroen C4 Picasso HDi 110 SX have?
The 2010 Citroen C4 Picasso HDi 110 SX has 109 PS / 108 bhp / 80 kW.

How much does a Citroen C4 Picasso HDi 110 SX weighs?
The Citroen C4 Picasso HDi 110 SX weighs 1564 Kg / 3448 lbs.

What is the top speed of a Citroen C4 Picasso HDi 110 SX?
The Citroen C4 Picasso HDi 110 SX top speed is 180 Km/h / 112 mph.

Is Citroen C4 Picasso HDi 110 SX All Wheel Drive (AWD)?
No, the Citroen C4 Picasso HDi 110 SX is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
