Citroen C5 II Business HDi 140 FAP Specs

(2010 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 5.7 litres/100km - 50 mpg UK - 41 mpg US (Average), 0 to 100 km/h (62mph) in 10.6 seconds, a maximum top speed of 127 mph (204 km/h), a curb weight of 3710 lbs (1683 kgs), the C5 II Business HDi 140 FAP has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 140 PS (138 bhp - 103 kW) at 4000 rpm and a maximum torque of 320 Nm (236 lb.ft) at 2000 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 6 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the C5 II has Independent. Coil springs. Anti-roll bar. front suspension and Independent. Coil springs. Anti-roll bar. rear suspension. Stock tire sizes are 225 / 60 on 16 inch rims at the front, and 225 / 60 on 16 inch rims at the rear. For stopping power, the C5 II Business HDi 140 FAP braking system includes Vented Discs at the front and Discs at the rear.
The C5 II model is a car manufactured by Citroen, with 5 doors and 5 seats, sold new from year 2010.

Citroen C5 II Business HDi 140 FAP Body, Model and Production details

Generation :	C5 2

Body :	-

Num. of Doors :	5 doors


Citroen C5 II Business HDi 140 FAP Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Engine Alignment :	Transverse

Engine size - Displacement - Engine capacity :	121.9 cu-in / 1997 cm3

Bore x Stroke :	3.35 x 3.46 inches 85 x 88 mm

Number of valves :	16 Valves

Aspiration :	Turbo (TGV) + Intercooler

Maximum power - Output - Horsepower :	138 HP / 140 PS / 103 kW @ 4000 rpm

Maximum torque :	236 lb-ft / 320 Nm @ 2000 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Citroen C5 II Business HDi 140 FAP Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	41 MPG 5.7 L/100 Km 50 MPG UK

Fuel Consumption - Economy - Open road:	50 MPG 4.7 L/100 Km 60 MPG UK

Fuel Consumption - Economy - City:	32 MPG 7.4 L/100 Km 38 MPG UK

Range :	774 miles / 1245 Km

Fuel Tank Capacity :	18.8 gallons 71 L 15.6 UK gallons

CO2 emissions :	149 g/Km (Citroen)

Citroen C5 II Business HDi 140 FAP Safety Ratings

Euro NCAP	Citroen C5 II Business HDi 140 FAP Euro NCAP Safety Rating Adult: Pedestrian: Child: Safety Assist: 81 % 32 % 77 % 83 % Tested on: 2 / 2009

Citroen C5 II Business HDi 140 FAP Performance

Top Speed :	127 Mph / 204 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	10.6 s

Acceleration 0 to 1000m :	32.3 s


Citroen C5 II Business HDi 140 FAP Size, Dimensions, Aerodynamics and Weight

Wheelbase :	110.83 inches / 281.5 cm

Length :	188.15 inches / 477.9 cm

Width :	- inches / 186.0 cm

Height :	57.4 inches / 145.8 cm

Aerodynamic drag coefficient - Cx :	0.31

Curb Weight :	3710 lbs / 1683 Kg

Weight-Power Output Ratio :	12 kg/hp


Citroen C5 II Business HDi 140 FAP Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :


Citroen C5 II Business HDi 140 FAP Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	225/60 R16

Rear Tyres - Rims dimensions :	225/60 R16

Front Suspension :	Independent. Coil springs. Anti-roll bar.

Rear Suspension :	Independent. Coil springs. Anti-roll bar.

What engine is in Citroen C5 II Business HDi 140 FAP?
The Citroen C5 II Business HDi 140 FAP has a Inline 4, Diesel engine with 1997 cm3 / 121.9 cu-in capacity.

How many horsepower (hp) does a 2010 Citroen C5 II Business HDi 140 FAP have?
The 2010 Citroen C5 II Business HDi 140 FAP has 140 PS / 138 bhp / 103 kW.

How much does a Citroen C5 II Business HDi 140 FAP weighs?
The Citroen C5 II Business HDi 140 FAP weighs 1683 Kg / 3710 lbs.

What is the top speed of a Citroen C5 II Business HDi 140 FAP?
The Citroen C5 II Business HDi 140 FAP top speed is 204 Km/h / 127 mph.

Is Citroen C5 II Business HDi 140 FAP All Wheel Drive (AWD)?
No, the Citroen C5 II Business HDi 140 FAP is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
