Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Specs

(1965 - 1966) - Technical Specifications for Years 1965, 1966

Petrol

426.9 cu-in
6996 cm³

V 8

391 HP
396 PS / 291 kW

469 lb-ft
637 Nm

Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Body, Model and Production details

Generation :	Bel Air 6th Generation - 1966 Facelift

Body :	Sedan

Num. of Doors :	4 doors


Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Engine Technical Data

Engine type - Number of cylinders :	V 8

Engine Code :	GM Big-Block V8 427

Fuel type :	Petrol

Fuel System :	Carburetor

Lubrication :	See oil information Engine oil capacity (with filter): 3.8 L
Engine Cooling - Capacity :	24.3 quarts / 23 L

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	426.9 cu-in / 6996 cm³

Bore x Stroke :	4.25 x 3.76 inches 108.0 x 95.5 mm

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	10.3

Horsepower :	391 HP / 396 PS / 291 kW @ 5200 rpm

Maximum torque :	469 lb-ft / 637 Nm @ 3600 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	3 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: Reverse Gear Ratio: 2.41 Final Drive Ratio: 3.31


Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	20.1 gallons 76 L 16.7 UK gallons

Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Performance

Top Speed :	- Mph / - km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Size, Dimensions, Aerodynamics and Weight

Wheelbase :	119.02 inches / 302.3 cm

Length :	213.19 inches / 541.5 cm

Width :	79.61 inches / 202.2 cm

Height :	55.39 inches / 140.7 cm

Front Axle :	62.52 inches / 158.8 cm

Rear Axle :	62.4 inches / 158.5 cm

Ground clearance :	5.71 inches / 14.5 cm

Loading height :	24.8 inches / 63.0 cm

Departure angle (deg) :	12.0°

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3977 lbs / 1804 kg

Weight/Power Output Ratio :	4.6 kg/hp


Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Interior size, Dimensions

Num. of Seats :	6 seats

Seat distribution :	3+3

Front legroom :	42.2 inches / 107.2 cm

Rear seat legroom :	39.49 inches / 100.3 cm

Front shoulder room :	62.28 inches / 158.2 cm

Rear shoulder room :	61.3 inches / 155.7 cm

Front head room :	39.21 inches / 99.6 cm

Rear head room :	37.8 inches / 96.0 cm

Front hip room :	63.9 inches / 162.3 cm

Rear hip room :	62.91 inches / 159.8 cm

Trunk / Boot capacity :	28.7 cu-ft / 813 L


Chevrolet Bel Air 6th Gen 4 Door Sedan 1966 427 V8 Turbo-Jet 390HP Special 3-speed Manual Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Drums (10.98 inches / 279 mm)

Rear Brakes - Disc dimensions :	Drums (10.98 inches / 279 mm)

Front Tyres - Rims dimensions :	7.75/- R14

Rear Tyres - Rims dimensions :	7.75/- R14

Turning circle :	44.1 feet / 13.44 m

Front Suspension :	Independent. Wishbone. Coil Springs.

Rear Suspension :	Rigid Axle. Coil Springs.
