BMW F11 5 Series Touring 525d Aut Specs

(2012 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 5.1 litres/100km - 55 mpg UK - 46 mpg US (Average), 0 to 100 km/h (62mph) in 7.2 seconds, a maximum top speed of 145 mph (233 km/h), a curb weight of 4023 lbs (1825 kgs), the F11 5 Series Touring 525d Aut has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 218 PS (215 bhp - 160 kW) at 4400 rpm and a maximum torque of 450 Nm (331 lb.ft) at 1500-2500 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 8 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the F11 5 Series Touring has Coil springs. front suspension and Pneumatic. rear suspension. Stock tire sizes are 225 / 55 on 17 inch rims at the front, and 225 / 55 on 17 inch rims at the rear. For stopping power, the F11 5 Series Touring 525d Aut braking system includes Vented Discs at the front and Vented Discs at the rear.
The F11 5 Series Touring model is a Estate car manufactured by BMW, with 5 doors and 5 seats, sold new from year 2012.

BMW F11 5 Series Touring 525d Aut Body, Model and Production details

Generation :	F10

Body :	Estate

Num. of Doors :	5 doors


BMW F11 5 Series Touring 525d Aut Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine size - Displacement - Engine capacity :	121.7 cu-in / 1995 cm3

Bore x Stroke :	3.31 x 3.54 inches 84.0 x 90.0 mm

Number of valves :	16 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	16.5

Maximum power - Output - Horsepower :	215 HP / 218 PS / 160 kW @ 4400 rpm

Maximum torque :	331 lb-ft / 450 Nm @ 1500-2500 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	8 speed Automatic Transmission Relations 1st Gear Ratio: 9.0 2nd Gear Ratio: 13.5 3rd Gear Ratio: 20.2 4th Gear Ratio: 25.5 5th Gear Ratio: 33.0 6th Gear Ratio: 42.4 7th Gear Ratio: 50.6 8th Gear Ratio: 63.6 Reverse Gear Ratio: 12.9


BMW F11 5 Series Touring 525d Aut Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	46 MPG 5.1 L/100 Km 55 MPG UK

Fuel Consumption - Economy - Open road:	51 MPG 4.6 L/100 Km 61 MPG UK

Fuel Consumption - Economy - City:	39 MPG 6 L/100 Km 47 MPG UK

Range :	853 miles / 1372 Km

Fuel Tank Capacity :	18.5 gallons 70 L 15.4 UK gallons

CO2 emissions :	135 g/Km (BMW)

Emission standard :	Euro V

BMW F11 5 Series Touring 525d Aut Safety Ratings

Euro NCAP	BMW F11 5 Series Touring 525d Aut Euro NCAP Safety Rating Adult: Pedestrian: Child: Safety Assist: 95 % 78 % 83 % 100 % Tested on: 5 / 2010

BMW F11 5 Series Touring 525d Aut Performance

Top Speed :	145 Mph / 233 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	7.2 s

Acceleration 0 to 1000m :	27.9 s


BMW F11 5 Series Touring 525d Aut Size, Dimensions, Aerodynamics and Weight

Wheelbase :	116.85 inches / 296.8 cm

Length :	193.19 inches / 490.7 cm

Width :	73.23 inches / 186.0 cm

Height :	57.56 inches / 146.2 cm

Front Axle :	62.99 inches / 160.0 cm

Rear Axle :	64.02 inches / 162.6 cm

Aerodynamic drag coefficient - Cx :	0.31

Curb Weight :	4023 lbs / 1825 Kg

Weight-Power Output Ratio :	8.4 kg/hp


BMW F11 5 Series Touring 525d Aut Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	19.8 cu-ft / 560 L

Trunk / Boot First Row :	59 cu-ft / 1670 L

Trunk / Boot Second Row :	19.8 cu-ft / 560 L


BMW F11 5 Series Touring 525d Aut Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (13.7 inches / 348 mm)

Rear Brakes - Dics dimensions :	Vented Discs (12.99 inches / 330 mm)

Front Tyres - Rims dimensions :	225/55 R17

Rear Tyres - Rims dimensions :	225/55 R17

Front Wheels Width :	8,0"

Rear Wheels Width :	8,0"

Steering :	Rack and pinion Electric

Steering ratio :	17.1

Front Suspension :	Coil springs.

Rear Suspension :	Pneumatic.

What engine is in BMW F11 5 Series Touring 525d Aut?
The BMW F11 5 Series Touring 525d Aut has a Inline 4, Diesel engine with 1995 cm3 / 121.7 cu-in capacity.

How many horsepower (hp) does a 2012 BMW F11 5 Series Touring 525d Aut have?
The 2012 BMW F11 5 Series Touring 525d Aut has 218 PS / 215 bhp / 160 kW.

How much does a BMW F11 5 Series Touring 525d Aut weighs?
The BMW F11 5 Series Touring 525d Aut weighs 1825 Kg / 4023 lbs.

What is the top speed of a BMW F11 5 Series Touring 525d Aut?
The BMW F11 5 Series Touring 525d Aut top speed is 233 Km/h / 145 mph.

Is BMW F11 5 Series Touring 525d Aut All Wheel Drive (AWD)?
No, the BMW F11 5 Series Touring 525d Aut is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
