BMW F11 5 Series Touring 525d Aut Specs

(2012 - ) Technical Specifications
BMW F11 5 Series Touring image
With a fuel consumption of 5.1 litres/100km - 55 mpg UK - 46 mpg US (Average), 0 to 100 km/h (62mph) in 7.2 seconds, a maximum top speed of 145 mph (233 km/h), a curb weight of 4023 lbs (1825 kgs), the F11 5 Series Touring 525d Aut has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 218 PS (215 bhp - 160 kW) at 4400 rpm and a maximum torque of 450 Nm (331 lb.ft) at 1500-2500 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 8 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the F11 5 Series Touring has Coil springs. front suspension and Pneumatic. rear suspension. Stock tire sizes are 225 / 55 on 17 inch rims at the front, and 225 / 55 on 17 inch rims at the rear. For stopping power, the F11 5 Series Touring 525d Aut braking system includes Vented Discs at the front and Vented Discs at the rear.
The F11 5 Series Touring model is a Estate car manufactured by BMW, with 5 doors and 5 seats, sold new from year 2012.

BMW F11 5 Series Touring 525d Aut Body, Model and Production details BMW F11 5 Series Touring 525d Aut Body, Model and Production details

Generation : F10
Body : Estate
Num. of Doors : 5 doors

BMW F11 5 Series Touring 525d Aut Engine Technical Data BMW F11 5 Series Touring 525d Aut Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Diesel
Fuel System : Direct Injection.
Engine Alignment : Longitudinal
Engine Position : Front
Engine size - Displacement - Engine capacity : 121.7 cu-in / 1995 cm3
Bore x Stroke : 3.31 x 3.54 inches
84.0 x 90.0 mm
Number of valves : 16 Valves
Aspiration : Turbo (TGV) + Intercooler
Compression Ratio : 16.5
Maximum power - Output - Horsepower : 215 HP / 218 PS / 160 kW
@ 4400 rpm
Maximum torque : 331 lb-ft / 450 Nm
@ 1500-2500 rpm
Drive wheels - Traction - Drivetrain : RWD
Transmission Gearbox - Number of speeds :

BMW F11 5 Series Touring 525d Aut Fuel Consumption (Economy), Emissions and Range BMW F11 5 Series Touring 525d Aut Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 46 MPG
5.1 L/100 Km
55 MPG UK
Fuel Consumption - Economy - Open road: 51 MPG
4.6 L/100 Km
61 MPG UK
Fuel Consumption - Economy - City: 39 MPG
6 L/100 Km
47 MPG UK
Range : 853 miles / 1372 Km
Fuel Tank Capacity : 18.5 gallons
70 L
15.4 UK gallons
CO2 emissions : 135 g/Km (BMW)
Emission standard : Euro V

BMW F11 5 Series Touring 525d Aut Safety Ratings

Euro NCAP

BMW F11 5 Series Touring 525d Aut Performance BMW F11 5 Series Touring 525d Aut Performance

Top Speed : 145 Mph / 233 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 7.2 s
Acceleration 0 to 1000m : 27.9 s

BMW F11 5 Series Touring 525d Aut Size, Dimensions, Aerodynamics and Weight BMW F11 5 Series Touring 525d Aut Size, Dimensions, Aerodynamics and Weight

Wheelbase : 116.85 inches / 296.8 cm
Length : 193.19 inches / 490.7 cm
Width : 73.23 inches / 186.0 cm
Height : 57.56 inches / 146.2 cm
Front Axle : 62.99 inches / 160.0 cm
Rear Axle : 64.02 inches / 162.6 cm
Aerodynamic drag coefficient - Cx : 0.31
Curb Weight : 4023 lbs / 1825 Kg
Weight-Power Output Ratio : 8.4 kg/hp

BMW F11 5 Series Touring 525d Aut Interior size, Dimensions BMW F11 5 Series Touring 525d Aut Interior size, Dimensions

Num. of Seats : 5 seats
Seat distribution : 2+3
Trunk / Boot capacity : 19.8 cu-ft / 560 L
Trunk / Boot First Row : 59 cu-ft / 1670 L
Trunk / Boot Second Row : 19.8 cu-ft / 560 L

BMW F11 5 Series Touring 525d Aut Brakes, Tires, Steering and Suspension BMW F11 5 Series Touring 525d Aut Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(13.7 inches / 348 mm)
Rear Brakes - Dics dimensions : Vented Discs
(12.99 inches / 330 mm)
Front Tyres - Rims dimensions : 225/55 R17
Rear Tyres - Rims dimensions : 225/55 R17
Front Wheels Width : 8,0"
Rear Wheels Width : 8,0"
Steering : Rack and pinion Electric
Steering ratio : 17.1
Front Suspension : Coil springs.
Rear Suspension : Pneumatic.
If you found an error in these specifications submit your correction here
What engine is in BMW F11 5 Series Touring 525d Aut?
The BMW F11 5 Series Touring 525d Aut has a Inline 4, Diesel engine with 1995 cm3 / 121.7 cu-in capacity.

How many horsepower (hp) does a 2012 BMW F11 5 Series Touring 525d Aut have?
The 2012 BMW F11 5 Series Touring 525d Aut has 218 PS / 215 bhp / 160 kW.

How much does a BMW F11 5 Series Touring 525d Aut weighs?
The BMW F11 5 Series Touring 525d Aut weighs 1825 Kg / 4023 lbs.

What is the top speed of a BMW F11 5 Series Touring 525d Aut?
The BMW F11 5 Series Touring 525d Aut top speed is 233 Km/h / 145 mph.

Is BMW F11 5 Series Touring 525d Aut All Wheel Drive (AWD)?
No, the BMW F11 5 Series Touring 525d Aut is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
