BMW F11 5 Series Touring 525d Specs

(2010 - ) Technical Specifications

Compare with another car

More pictures

With a fuel consumption of 6.3 litres/100km - 45 mpg UK - 37 mpg US (Average), 0 to 100 km/h (62mph) in 7.3 seconds, a maximum top speed of 144 mph (232 km/h), a curb weight of 4057 lbs (1840 kgs), the F11 5 Series Touring 525d has a turbocharged Inline 6 cylinder engine, Diesel motor.
This engine produces a maximum power of 204 PS (201 bhp - 150 kW) at 4000 rpm and a maximum torque of 450 Nm (331 lb.ft) at 1750-2500 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 6 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the F11 5 Series Touring has Independent. Coil springs. Anti-roll bar. front suspension and Independent. Coil springs. Anti-roll bar. rear suspension. Stock tire sizes are 225 / 55 on 17 inch rims at the front, and 225 / 55 on 17 inch rims at the rear. For stopping power, the F11 5 Series Touring 525d braking system includes Vented Discs at the front and Vented Discs at the rear.
The F11 5 Series Touring model is a car manufactured by BMW, with 5 doors and 5 seats, sold new from year 2010.

BMW F11 5 Series Touring 525d Body, Model and Production details

Generation :	F10

Body :	-

Num. of Doors :	5 doors


BMW F11 5 Series Touring 525d Engine Technical Data

Engine type - Number of cylinders :	Inline 6

Engine Code :	-

Fuel type :	Diesel

Engine Alignment :	Longitudinal

Engine size - Displacement - Engine capacity :	182.6 cu-in / 2993 cm3

Bore x Stroke :	3.31 x 3.54 inches 84 x 90 mm

Number of valves :	24 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	16.5

Maximum power - Output - Horsepower :	201 HP / 204 PS / 150 kW @ 4000 rpm

Maximum torque :	331 lb-ft / 450 Nm @ 1750-2500 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	6 speed Manual


BMW F11 5 Series Touring 525d Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	37 MPG 6.3 L/100 Km 45 MPG UK

Fuel Consumption - Economy - Open road:	44 MPG 5.3 L/100 Km 53 MPG UK

Fuel Consumption - Economy - City:	29 MPG 8 L/100 Km 35 MPG UK

Range :	690 miles / 1111 Km

Fuel Tank Capacity :	18.5 gallons 70 L 15.4 UK gallons

CO2 emissions :	164 g/Km (BMW)

BMW F11 5 Series Touring 525d Safety Ratings

Euro NCAP	BMW F11 5 Series Touring 525d Euro NCAP Safety Rating Adult: Pedestrian: Child: Safety Assist: 95 % 78 % 83 % 100 % Tested on: 5 / 2010

BMW F11 5 Series Touring 525d Performance

Top Speed :	144 Mph / 232 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	7.3 s

Acceleration 0 to 1000m :	27.9 s


BMW F11 5 Series Touring 525d Size, Dimensions, Aerodynamics and Weight

Wheelbase :	116.85 inches / 296.8 cm

Length :	193.19 inches / 490.7 cm

Width :	- inches / 186.0 cm

Height :	57.56 inches / 146.2 cm

Aerodynamic drag coefficient - Cx :	0.31

Curb Weight :	4057 lbs / 1840 Kg

Weight-Power Output Ratio :	9 kg/hp


BMW F11 5 Series Touring 525d Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :


BMW F11 5 Series Touring 525d Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (13.7 inches / 348 mm)

Rear Brakes - Dics dimensions :	Vented Discs (12.99 inches / 330 mm)

Front Tyres - Rims dimensions :	225/55 R17

Rear Tyres - Rims dimensions :	225/55 R17

Front Suspension :	Independent. Coil springs. Anti-roll bar.

Rear Suspension :	Independent. Coil springs. Anti-roll bar.

What engine is in BMW F11 5 Series Touring 525d?
The BMW F11 5 Series Touring 525d has a Inline 6, Diesel engine with 2993 cm3 / 182.6 cu-in capacity.

How many horsepower (hp) does a 2010 BMW F11 5 Series Touring 525d have?
The 2010 BMW F11 5 Series Touring 525d has 204 PS / 201 bhp / 150 kW.

How much does a BMW F11 5 Series Touring 525d weighs?
The BMW F11 5 Series Touring 525d weighs 1840 Kg / 4057 lbs.

What is the top speed of a BMW F11 5 Series Touring 525d?
The BMW F11 5 Series Touring 525d top speed is 232 Km/h / 144 mph.

Is BMW F11 5 Series Touring 525d All Wheel Drive (AWD)?
No, the BMW F11 5 Series Touring 525d is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
