Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Specs

(2010 - ) Technical Specifications
★★★★★ ★★★★★ Own this car? Rate it!
×
Own this car? Rate it!
Comfort ★★★★★
Economy ★★★★★
Reliability ★★★★★
Performance ★★★★★
Handling ★★★★★
Cost of maintenance ★★★★★
Recommend to a friend? ★★★★★
Alfa Romeo Spider (Type 939) image

Key Specs

Diesel
119.4 cu-in
1956 cm3
Inline 4
168 HP
170 PS / 125 kW
265 lb-ft
360 Nm
135 Mph
218 km/h

Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Body, Model and Production details Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Body, Model and Production details

Generation : Spider (Tipo 939)
Body : -
Num. of Doors : 2 doors

Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Engine Technical Data Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Diesel
Engine Alignment : Transverse
Engine displacement : 119.4 cu-in / 1956 cm3
Bore x Stroke : 3.27 x 3.56 inches
83 x 90.4 mm
Number of valves : 16 Valves
Aspiration : Turbo (TGV) + Intercooler
Compression Ratio : 16.5
Horsepower : 168 HP / 170 PS / 125 kW
@ 4000 rpm
Maximum torque : 265 lb-ft / 360 Nm
@ 1750 rpm
Drive wheels - Traction - Drivetrain : FWD
Transmission Gearbox - Number of speeds :
6 speed Manual

Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Fuel Consumption (Economy), Emissions and Range Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC : 33 MPG
7.1 L/100 km
40 MPG UK
Fuel Consumption - Economy - Open road NEDC : 53 MPG
4.4 L/100 km
64 MPG UK
Fuel Consumption - Economy - Combined NEDC : 44 MPG
5.4 L/100 km
52 MPG UK
Range : 805 miles / 1296 km
Fuel Tank Capacity : 18.5 gallons
70 L
15.4 UK gallons
CO2 emissions : 142 g/km (Alfa Romeo)

Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Performance Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Performance

Top Speed : 135 Mph / 218 km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 9 s

Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Size, Dimensions, Aerodynamics and Weight Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Size, Dimensions, Aerodynamics and Weight

Wheelbase : 99.53 inches / 252.8 cm
Length : 172.95 inches / 439.3 cm
Width : 72.05 inches / 183.0 cm
Height : 51.89 inches / 131.8 cm
Aerodynamic drag coefficient - Cx : -
Curb Weight : 3560 lbs / 1615 kg
Weight/Power Output Ratio : 9.5 kg/hp

Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Interior size, Dimensions Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Interior size, Dimensions

Num. of Seats : 2 seats
Trunk / Boot capacity : -

Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Brakes, Tires, Steering and Suspension Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(12.99 inches / 330 mm)
Rear Brakes - Disc dimensions : Vented Discs
(11.5 inches / 292 mm)
Front Tyres - Rims dimensions : 225/50 R17
Rear Tyres - Rims dimensions : 225/50 R17
Front Suspension : Independent. Coil springs. Anti-roll bar.
Rear Suspension : Independent. Coil Springs. Anti-roll bar.
If you found an error in these specifications submit your correction here

How fast is a Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP?
The Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP can reach 0 to 100 km/h (0 to 62 mph) in 9 seconds and has a top speed of 218 km/h / 135 mph.

How many horsepower (hp) does a 2010 Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP have?
The 2010 Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP has 170 PS / 168 bhp / 125 kW.

How much does a Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP weighs?
The Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP weighs 1615 Kg / 3560 lbs.

What is the Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP gas mileage?
The Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP gas mileage is City NEDC 33 MPG / 7.1 L/100 km / 40 MPG UK / Open road NEDC 53 MPG / 4.4 L/100 km / 64 MPG UK / Combined NEDC 44 MPG / 5.4 L/100 km / 52 MPG UK.

What engine is in Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP?
The Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP has a Inline 4, Diesel engine with 1956 cm3 / 119.4 cu-in capacity.

What are the dimensions of the Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP?
The Alfa Romeo Spider (Type 939) 2.0 JTDm 170HP is 172.95 inches / 439.3 cm long, 72.05 inches / 183.0 cm wide, and 51.89 inches / 131.8 cm tall, with a wheelbase of 99.53 inches / 252.8 cm.
