Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Specs

(2005 - 2010) - Technical Specifications for Years 2005, 2006, 2007, 2008, 2009, 2010
Volkswagen Jetta 5 image
With a fuel consumption of 4.8 litres/100km - 59 mpg UK - 49 mpg US (Average), 0 to 100 km/h (62mph) in 12 seconds, a maximum top speed of 116 mph (187 km/h), a curb weight of 3221 lbs (1461 kgs), the Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 105 PS (104 bhp - 77 kW) at 4400 rpm and a maximum torque of 250 Nm (184 lb.ft) at 1500-2500 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 7 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Jetta 5 has Independent. McPherson struts. Coil springs. Anti-roll bar. front suspension and Independent. Coil springs. Anti-roll bar. rear suspension. Stock tire sizes are 205 / 55 on 16 inch rims at the front, and 205 / 55 on 16 inch rims at the rear. For stopping power, the Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF braking system includes Vented Discs at the front and Discs at the rear.
The Jetta 5 model is a car manufactured by Volkswagen, sold new from year 2005 until 2010, and available after that as a used car.

Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Engine Technical Data Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Diesel
Engine Alignment : Transverse
Engine size - Displacement - Engine capacity : 1598 cm3 or 97.5 cu-in
Bore x Stroke : 79.5 x 80.5 mm
3.11 x 3.15 inches
Number of valves : 16 Valves
Aspiration : Turbo (TGV) + Intercooler
Compression Ratio : 16.5
Maximum power - Output - Horsepower : 105 PS or 104 bhp or 77 kW @ 4400 rpm
Maximum torque : 250 Nm or 184 lb.ft @ 1500-2500 rpm
Drive wheels - Traction - Drivetrain : FWD
Transmission Gearbox - Number of speeds :

Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Fuel Consumption (Economy), Emissions and Range Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 4.8 L/100km
59 mpg UK / 49 mpg US
Fuel Consumption - Economy - Open road: 4.3 L/100km
66 mpg UK / 55 mpg US
Fuel Consumption - Economy - City: 5.7 L/100km
50 mpg UK / 41 mpg US
Range : 1145 Km or 712 miles
Fuel Tank Capacity : 55 L
12.1 UK gallons
14.5 US gallons
CO2 emissions : 125 g/Km (Volkswagen)

Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Performance Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Performance

Top Speed : 187 km/h or 116 Mph
Acceleration 0 to 100 km/h (0 to 62 mph) : 12 s

Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Size, Dimensions, Aerodynamics and Weight Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF Size, Dimensions, Aerodynamics and Weight

Num. of Doors : 4
Wheelbase : 257.8 cm or 101.5 inches
Length : 455.4 cm or 179.29 inches
Width : 178.1 cm or 70.12 inches
Height : 145.9 cm or 57.44 inches
Aerodynamic drag coefficient - Cx : 0.31
Front Brakes - Disc dimensions : Vented Discs (280 mm)
Rear Brakes - Dics dimensions : Discs (260 mm)
Front Tyres - Rims dimensions : 205/55 R16
Rear Tyres - Rims dimensions : 205/55 R16
Curb Weight : 1461 kg OR 3221 lbs
Weight-Power Output Ratio : 13.9 kg/hp
Trunk / Boot capacity : 527--- L
Front Suspension : Independent. McPherson struts. Coil springs. Anti-roll bar.
Rear Suspension : Independent. Coil springs. Anti-roll bar.
What engine is in Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF?
The Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF has a Inline 4, Diesel engine with 1598 cm3 / 97.5 cu-in capacity.

How many horsepower (hp) does a 2005 Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF have?
The 2005 Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF has 105 PS / 104 bhp / 77 kW.

How much does a Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF weighs?
The Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF weighs 1461 Kg / 3221 lbs.

What is the top speed of a Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF?
The Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF top speed is 187 Km/h / 116 mph.

Is Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF All Wheel Drive (AWD)?
No, the Volkswagen Jetta 5 Highline 1.6 TDI CR 105HP DSG 7 Speeds DPF is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
