Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Specs

(2000 - 2005) - Technical Specifications for Years 2000, 2001, 2002, 2003, 2004, 2005

Compare with another car

More pictures

With a fuel consumption of 11.1 litres/100km - 25 mpg UK - 21 mpg US (Average), 0 to 100 km/h (62mph) in 10.1 seconds, a maximum top speed of 141 mph (227 km/h), a curb weight of 3662 lbs (1661 kgs), the Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic has a naturally-aspirated V 6 cylinder engine, Petrol motor.
This engine produces a maximum power of 193 PS (190 bhp - 142 kW) at 6000 rpm and a maximum torque of 280 Nm (206 lb.ft) at 3200 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 5 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Passat B5.5 Variant has McPherson struts. Coil springs. front suspension and Coil springs. rear suspension. Stock tire sizes are 205 / 55 on 16 inch rims at the front, and 205 / 55 on 16 inch rims at the rear. For stopping power, the Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic braking system includes Vented Discs at the front and Vented Discs at the rear.
The Passat B5.5 Variant model is a Estate car manufactured by Volkswagen, with 5 doors and 5 seats, sold new from year 2000 until 2005, and available after that as a used car.

Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Body, Model and Production details

Generation :	Passat B5.5

Body :	Estate

Num. of Doors :	5 doors


Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Engine Technical Data

Engine type - Number of cylinders :	V 6

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Indirect Injection.

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine size - Displacement - Engine capacity :	169.1 cu-in / 2771 cm3

Bore x Stroke :	3.25 x 3.4 inches 82.5 x 86.4 mm

Number of valves :	30 Valves

Aspiration :	N/A

Compression Ratio :	11

Maximum power - Output - Horsepower :	190 HP / 193 PS / 142 kW @ 6000 rpm

Maximum torque :	206 lb-ft / 280 Nm @ 3200 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	5 speed Automatic Transmission Relations 1st Gear Ratio: 10.2 2nd Gear Ratio: 18.7 3rd Gear Ratio: 26.5 4th Gear Ratio: 37.4 5th Gear Ratio: 50.6

Clutch Type :	Torque Converter


Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	21 MPG 11.1 L/100 Km 25 MPG UK

Fuel Consumption - Economy - Open road:	29 MPG 8 L/100 Km 35 MPG UK

Fuel Consumption - Economy - City:	14 MPG 16.5 L/100 Km 17 MPG UK

Range :	347 miles / 558 Km

Fuel Tank Capacity :	16.4 gallons 62 L 13.6 UK gallons

CO2 emissions :	265 g/Km (estimate)

Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Performance

Top Speed :	141 Mph / 227 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	10.1 s


Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Size, Dimensions, Aerodynamics and Weight

Wheelbase :	106.38 inches / 270.2 cm

Length :	184.33 inches / 468.2 cm

Width :	68.74 inches / 174.6 cm

Height :	58.19 inches / 147.8 cm

Front Axle :	59.65 inches / 151.5 cm

Rear Axle :	59.65 inches / 151.5 cm

Aerodynamic drag coefficient - Cx :	0.32

Curb Weight :	3662 lbs / 1661 Kg

Weight-Power Output Ratio :	8.6 kg/hp


Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	15.9 cu-ft / 450 L

Trunk / Boot First Row :	54.6 cu-ft / 1545 L

Trunk / Boot Second Row :	15.9 cu-ft / 450 L


Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (12.28 inches / 312 mm)

Rear Brakes - Dics dimensions :	Vented Discs (10.08 inches / 256 mm)

Front Tyres - Rims dimensions :	205/55 R16

Rear Tyres - Rims dimensions :	205/55 R16

Front Wheels Width :	7,0"

Rear Wheels Width :	7,0"

Steering :	Rack and pinion

Front Suspension :	McPherson struts. Coil springs.

Rear Suspension :	Coil springs.

What engine is in Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic?
The Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic has a V 6, Petrol engine with 2771 cm3 / 169.1 cu-in capacity.

How many horsepower (hp) does a 2000 Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic have?
The 2000 Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic has 193 PS / 190 bhp / 142 kW.

How much does a Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic weighs?
The Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic weighs 1661 Kg / 3662 lbs.

What is the top speed of a Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic?
The Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic top speed is 227 Km/h / 141 mph.

Is Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic All Wheel Drive (AWD)?
Yes, the Volkswagen Passat B5.5 Variant Highline 2.8 V6 193HP 4Motion Tiptronic is All Wheel Drive (AWD).
