Ssangyong Korando II 2.9TD SoftTop Specs

(2002 - 2006) - Technical Specifications for Years 2002, 2003, 2004, 2005, 2006

Compare with another car

More pictures

With a fuel consumption of 8.3 litres/100km - 34 mpg UK - 28 mpg US (Average), 0 to 100 km/h (62mph) in 16.9 seconds, a maximum top speed of 97 mph (156 km/h), a curb weight of 3979 lbs (1805 kgs), the Korando II 2.9TD SoftTop has a turbocharged Inline 5 cylinder engine, Diesel motor.
This engine produces a maximum power of 120 PS (118 bhp - 88 kW) at 4100 rpm and a maximum torque of 256 Nm (188 lb.ft) at 2100 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 5 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Korando II has Independent. McPherson. coil springs front suspension and Coil springs rear suspension. Stock tire sizes are 235 / 75 on 15 inch rims at the front, and 235 / 75 on 15 inch rims at the rear. For stopping power, the Korando II 2.9TD SoftTop braking system includes Vented Discs at the front and Discs at the rear.
The Korando II model is a car manufactured by Ssangyong, sold new from year 2002 until 2006, and available after that as a used car.

Ssangyong Korando II 2.9TD SoftTop Body, Model and Production details

Body :	-


Ssangyong Korando II 2.9TD SoftTop Engine Technical Data

Engine type - Number of cylinders :	Inline 5

Engine Code :	-

Fuel type :	Diesel

Engine Alignment :	Longitudinal

Engine size - Displacement - Engine capacity :	175.4 cu-in / 2874 cm3

Bore x Stroke :	3.5 x 3.64 inches 89.0 x 92.4 mm

Number of valves :	10 Valves

Aspiration :	Turbo

Compression Ratio :	22.0

Maximum power - Output - Horsepower :	118 HP / 120 PS / 88 kW @ 4100 rpm

Maximum torque :	188 lb-ft / 256 Nm @ 2100 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	5 speed Manual


Ssangyong Korando II 2.9TD SoftTop Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	28 MPG 8.3 L/100 Km 34 MPG UK

Fuel Consumption - Economy - Open road:	36 MPG 6.5 L/100 Km 43 MPG UK

Fuel Consumption - Economy - City:	21 MPG 11.4 L/100 Km 25 MPG UK

Range :	524 miles / 843 Km

Fuel Tank Capacity :	18.5 gallons 70 L 15.4 UK gallons

CO2 emissions :	220 g/Km (Ssangyong)

Ssangyong Korando II 2.9TD SoftTop Performance

Top Speed :	97 Mph / 156 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	16.9 s


Ssangyong Korando II 2.9TD SoftTop Size, Dimensions, Aerodynamics and Weight

Wheelbase :	97.64 inches / 248.0 cm

Length :	170.47 inches / 433.0 cm

Width :	72.44 inches / 184.0 cm

Height :	72.44 inches / 184.0 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3979 lbs / 1805 Kg

Weight-Power Output Ratio :	15 kg/hp


Ssangyong Korando II 2.9TD SoftTop Interior size, Dimensions

Trunk / Boot capacity :	from 12.4 cu-ft / 350 L


Ssangyong Korando II 2.9TD SoftTop Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	235/75 R15

Rear Tyres - Rims dimensions :	235/75 R15

Front Suspension :	Independent. McPherson. coil springs

Rear Suspension :	Coil springs

What engine is in Ssangyong Korando II 2.9TD SoftTop?
The Ssangyong Korando II 2.9TD SoftTop has a Inline 5, Diesel engine with 2874 cm3 / 175.4 cu-in capacity.

How many horsepower (hp) does a 2002 Ssangyong Korando II 2.9TD SoftTop have?
The 2002 Ssangyong Korando II 2.9TD SoftTop has 120 PS / 118 bhp / 88 kW.

How much does a Ssangyong Korando II 2.9TD SoftTop weighs?
The Ssangyong Korando II 2.9TD SoftTop weighs 1805 Kg / 3979 lbs.

What is the top speed of a Ssangyong Korando II 2.9TD SoftTop?
The Ssangyong Korando II 2.9TD SoftTop top speed is 156 Km/h / 97 mph.

Is Ssangyong Korando II 2.9TD SoftTop All Wheel Drive (AWD)?
Yes, the Ssangyong Korando II 2.9TD SoftTop is All Wheel Drive (AWD).
