Mercedes Benz W140 Class S 350 SD Turbo Specs

(1993 - 1993) - Technical Specifications for
With a fuel consumption of 9.7 litres/100km - 29 mpg UK - 24 mpg US (Average), 0 to 100 km/h (62mph) in 12.9 seconds, a maximum top speed of 115 mph (185 km/h), a curb weight of 4277 lbs (1940 kgs), the W140 Class S 350 SD Turbo has a naturally-aspirated In-line 6 cylinder engine, Diesel motor, with the engine code 603.971.
This engine produces a maximum power of 150 PS (148 bhp - 110 kW) at 4000 rpm and a maximum torque of 310 Nm (228 lb.ft) at 2000 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 4 speed Automatic gearbox.
About chassis details responsible for road holding, handling behaviour and ride confort, the W140 Class S has independent. double wishbones. coil springs. anti-roll bar front suspension and multilink. coil springs. anti-roll bar rear suspension. Stock tire sizes are 225 / 60 on 16 inch rims at the front, and 225 / 60 on 16 inch rims at the rear. For stopping power, the W140 Class S 350 SD Turbo braking system includes Vented Discs at the front and Discs at the rear.
The W140 Class S model is a car manufactured by Mercedes Benz, sold new from year 1993 to 1993, and available after that as a used car.

Mercedes Benz W140 Class S 350 SD Turbo Engine Technical Data Mercedes Benz W140 Class S 350 SD Turbo Engine Technical Data

Engine type - Number of cylinders : I 6
Engine Code : 603.971
Fuel type :
Diesel
Fuel System : Bosch
Engine Alignment : Longitudinal
Engine size - Displacement - Engine capacity : 3449 cm3 or 210.5 cu-in
Bore x Stroke : 89.0 x 92.4 mm
3.5 x 3.62 inches
Number of valves : 12 Valves
Aspiration : N/A
Compression Ratio : 22.0
Maximum power - Output - Horsepower : 150 PS or 148 bhp or 110 kW @ 4000 rpm
Maximum torque : 310 Nm or 228 lb.ft @ 2000 rpm
Drive wheels - Traction - Drivetrain : RWD
Transmission Gearbox - Number of speeds :

Mercedes Benz W140 Class S 350 SD Turbo Fuel Consumption (Economy), Emissions and RangeMercedes Benz W140 Class S 350 SD Turbo Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 9.7 L/100km
29 mpg UK / 24 mpg US
Fuel Consumption - Economy - Extra Urban: - L/100km
Fuel Consumption - Economy - City: - L/100km
Fuel Tank Capacity : 100 L
22 UK gallons
26.4 US gallons
Range : 1030 Km or 640 miles
CO2 emissions : 226 g/Km (estimate)

Mercedes Benz W140 Class S 350 SD Turbo Performance Mercedes Benz W140 Class S 350 SD Turbo Performance

Top Speed : 185 km/h or 115 Mph
Acceleration 0 to 100 km/h (0 to 62 mph) : 12.9 s

Mercedes Benz W140 Class S 350 SD Turbo Size, Dimensions, Aerodynamics and Weight Mercedes Benz W140 Class S 350 SD Turbo Size, Dimensions, Aerodynamics and Weight

Num. of Doors : 4
Wheelbase : 304 cm or 119.69 inches
Length : 511 cm or 201.18 inches
Width : 189 cm or 74.41 inches
Height : 148 cm or 58.27 inches
Aerodynamic drag coefficient - Cx : -
Front Brakes - Disc dimensions : Vented Discs (- mm)
Rear Brakes - Dics dimensions : Discs (- mm)
Front Tyres - Rims dimensions : 225/60 R16
Rear Tyres - Rims dimensions : 225/60 R16
Curb Weight : 1940 kg OR 4277 lbs
Weight-Power Output Ratio : 12.9 kg/hp
Trunk / Boot capacity : 525 L
Front Suspension : independent. double wishbones. coil springs. anti-roll bar
Rear Suspension : multilink. coil springs. anti-roll bar

Mercedes Benz W140 Class S 350 SD Turbo Service Light Reset

not available yet
