E Class (W211) Versions


Mercedes Benz E Class (W211) 500 4Matic Specs

(2004 - 2006) - Technical Specifications for Years 2004, 2005, 2006
Mercedes Benz E Class (W211) image
With a fuel consumption of 11.9 litres/100km - 24 mpg UK - 20 mpg US (Average), 0 to 100 km/h (62mph) in 6.3 seconds, a maximum top speed of 155 mph (250 km/h), a curb weight of 3759 lbs (1705 kgs), the E Class (W211) 500 4Matic has a naturally-aspirated V 8 cylinder engine, Petrol motor, with the engine code 113.969.
This engine produces a maximum power of 306 PS (302 bhp - 225 kW) at 5600 rpm and a maximum torque of 460 Nm (339 lb.ft) at 2700 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 5 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the E Class (W211) has Independent4-link. Multilink with Activer Air Suspension Unit front suspension and Multilink with Air Suspension Unit rear suspension. Stock tire sizes are 245 / 45 on 17 inch rims at the front, and 245 / 45 on 17 inch rims at the rear. For stopping power, the E Class (W211) 500 4Matic braking system includes Vented Discs at the front and Discs at the rear.
The E Class (W211) model is a Sedan car manufactured by Mercedes Benz, with 4 doors and 5 seats, sold new from year 2004 until 2006, and available after that as a used car.

Mercedes Benz E Class (W211) 500 4Matic Body, Model and Production details Mercedes Benz E Class (W211) 500 4Matic Body, Model and Production details

Generation : W211
Body : Sedan
Num. of Doors : 4 doors

Mercedes Benz E Class (W211) 500 4Matic Engine Technical Data Mercedes Benz E Class (W211) 500 4Matic Engine Technical Data

Engine type - Number of cylinders : V 8
Engine Code : 113.969
Fuel type : Petrol
Fuel System : MPI - Bosch Motronic ME 2.8
Engine Alignment : Longitudinal
Engine size - Displacement - Engine capacity : 303 cu-in / 4966 cm3
Bore x Stroke : 3.82 x 3.31 inches
97.0 x 84.0 mm
Number of valves : 24 Valves
Aspiration : N/A
Compression Ratio : 10.0
Maximum power - Output - Horsepower : 302 HP / 306 PS / 225 kW
@ 5600 rpm
Maximum torque : 339 lb-ft / 460 Nm
@ 2700 rpm
Drive wheels - Traction - Drivetrain : AWD
Transmission Gearbox - Number of speeds :

Mercedes Benz E Class (W211) 500 4Matic Fuel Consumption (Economy), Emissions and Range Mercedes Benz E Class (W211) 500 4Matic Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 20 MPG
11.9 L/100 Km
24 MPG UK
Fuel Consumption - Economy - Open road: 27 MPG
8.8 L/100 Km
32 MPG UK
Fuel Consumption - Economy - City: 13 MPG
17.7 L/100 Km
16 MPG UK
Range : 418 miles / 672 Km
Fuel Tank Capacity : 21.1 gallons
80 L
17.6 UK gallons
CO2 emissions : 285 g/Km (Mercedes Benz)

Mercedes Benz E Class (W211) 500 4Matic Performance Mercedes Benz E Class (W211) 500 4Matic Performance

Top Speed : 155 Mph / 250 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 6.3 s

Mercedes Benz E Class (W211) 500 4Matic Size, Dimensions, Aerodynamics and Weight Mercedes Benz E Class (W211) 500 4Matic Size, Dimensions, Aerodynamics and Weight

Wheelbase : 112.36 inches / 285.4 cm
Length : 189.69 inches / 481.8 cm
Width : 71.73 inches / 182.2 cm
Height : 57.17 inches / 145.2 cm
Aerodynamic drag coefficient - Cx : -
Curb Weight : 3759 lbs / 1705 Kg
Weight-Power Output Ratio : 5.6 kg/hp

Mercedes Benz E Class (W211) 500 4Matic Interior size, Dimensions Mercedes Benz E Class (W211) 500 4Matic Interior size, Dimensions

Num. of Seats : 5 seats
Trunk / Boot capacity : 18.7 cu-ft / 530 L

Mercedes Benz E Class (W211) 500 4Matic Brakes, Tires, Steering and Suspension Mercedes Benz E Class (W211) 500 4Matic Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(- inches / - mm)
Rear Brakes - Dics dimensions : Discs
(- inches / - mm)
Front Tyres - Rims dimensions : 245/45 R17
Rear Tyres - Rims dimensions : 245/45 R17
Turning circle : 37.4 feet / 11.4 m
Steering wheel lock-to-lock : 2.6 turns
Front Suspension : Independent4-link. Multilink with Activer Air Suspension Unit
Rear Suspension : Multilink with Air Suspension Unit
If you found an error in these specifications submit your correction here
What engine is in Mercedes Benz E Class (W211) 500 4Matic?
The Mercedes Benz E Class (W211) 500 4Matic has a V 8, Petrol engine with 4966 cm3 / 303 cu-in capacity.

How many horsepower (hp) does a 2004 Mercedes Benz E Class (W211) 500 4Matic have?
The 2004 Mercedes Benz E Class (W211) 500 4Matic has 306 PS / 302 bhp / 225 kW.

How much does a Mercedes Benz E Class (W211) 500 4Matic weighs?
The Mercedes Benz E Class (W211) 500 4Matic weighs 1705 Kg / 3759 lbs.

What is the top speed of a Mercedes Benz E Class (W211) 500 4Matic?
The Mercedes Benz E Class (W211) 500 4Matic top speed is 250 Km/h / 155 mph.

Is Mercedes Benz E Class (W211) 500 4Matic All Wheel Drive (AWD)?
Yes, the Mercedes Benz E Class (W211) 500 4Matic is All Wheel Drive (AWD).
