Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Specs

(2009 - ) Technical Specifications
Mercedes Benz R Class (W251) image
With a fuel consumption of 8.7 litres/100km - 32 mpg UK - 27 mpg US (Average), 0 to 100 km/h (62mph) in 8.9 seconds, a maximum top speed of 134 mph (216 km/h), a curb weight of 5148 lbs (2335 kgs), the R Class (W251) 350 CDI BlueTEC 4M L has a turbocharged V 6 cylinder engine, Diesel motor.
This engine produces a maximum power of 224 PS (221 bhp - 165 kW) at 3800 rpm and a maximum torque of 510 Nm (376 lb.ft) at 1600-2800 rpm. The power is transmitted to the road by the all wheel drive (AWD) with a 7 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the R Class (W251) has Independent. Coil springs. Anti-roll bar. front suspension and Independent. Coil springs. Anti-roll bar. rear suspension. Stock tire sizes are 255 / 55 on 18 inch rims at the front, and 255 / 55 on 18 inch rims at the rear. For stopping power, the R Class (W251) 350 CDI BlueTEC 4M L braking system includes Vented Discs at the front and Discs at the rear.
The R Class (W251) model is a car manufactured by Mercedes Benz, sold new from year 2009.

Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Body, Model and Production details Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Body, Model and Production details

Body : -
Num. of Doors : 5 doors

Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Engine Technical Data Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Engine Technical Data

Engine type - Number of cylinders : V 6
Engine Code : -
Fuel type : Diesel
Fuel System : Common Rail
Engine Alignment : Longitudinal
Engine size - Displacement - Engine capacity : 182.3 cu-in / 2987 cm3
Bore x Stroke : 3.27 x 3.62 inches
83 x 92 mm
Number of valves : 28 Valves
Aspiration : Turbo (TGV) + Intercooler
Compression Ratio : 17.7
Maximum power - Output - Horsepower : 221 HP / 224 PS / 165 kW
@ 3800 rpm
Maximum torque : 376 lb-ft / 510 Nm
@ 1600-2800 rpm
Drive wheels - Traction - Drivetrain : AWD
Transmission Gearbox - Number of speeds :

Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Fuel Consumption (Economy), Emissions and Range Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 27 MPG
8.7 L/100 Km
32 MPG UK
Fuel Consumption - Economy - Open road: 34 MPG
7 L/100 Km
40 MPG UK
Fuel Consumption - Economy - City: 20 MPG
11.7 L/100 Km
24 MPG UK
Range : 571 miles / 919 Km
Fuel Tank Capacity : 21.1 gallons
80 L
17.6 UK gallons
CO2 emissions : 229 g/Km (Mercedes Benz)

Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Performance Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Performance

Top Speed : 134 Mph / 216 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 8.9 s

Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Size, Dimensions, Aerodynamics and Weight Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Size, Dimensions, Aerodynamics and Weight

Wheelbase : 126.57 inches / 321.5 cm
Length : 203.03 inches / 515.7 cm
Width : - inches / 192.2 cm
Height : 65.39 inches / 166.1 cm
Aerodynamic drag coefficient - Cx : 0.32
Curb Weight : 5148 lbs / 2335 Kg
Weight-Power Output Ratio : 10.4 kg/hp

Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Interior size, Dimensions Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Interior size, Dimensions

Trunk / Boot capacity : from 21.8 cu-ft / 616 L

Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Brakes, Tires, Steering and Suspension Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(- inches / - mm)
Rear Brakes - Dics dimensions : Discs
(- inches / - mm)
Front Tyres - Rims dimensions : 255/55 R18
Rear Tyres - Rims dimensions : 255/55 R18
Front Suspension : Independent. Coil springs. Anti-roll bar.
Rear Suspension : Independent. Coil springs. Anti-roll bar.
If you found an error in these specifications submit your correction here
What engine is in Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L?
The Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L has a V 6, Diesel engine with 2987 cm3 / 182.3 cu-in capacity.

How many horsepower (hp) does a 2009 Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L have?
The 2009 Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L has 224 PS / 221 bhp / 165 kW.

How much does a Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L weighs?
The Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L weighs 2335 Kg / 5148 lbs.

What is the top speed of a Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L?
The Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L top speed is 216 Km/h / 134 mph.

Is Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L All Wheel Drive (AWD)?
Yes, the Mercedes Benz R Class (W251) 350 CDI BlueTEC 4M L is All Wheel Drive (AWD).
