Ford Scorpio II 2.3i 16v Specs

(1996 - 1997) - Technical Specifications for Years 1996, 1997
Ford Scorpio II image
With a fuel consumption of 9.6 litres/100km - 29 mpg UK - 25 mpg US (Average), 0 to 100 km/h (62mph) in 9.8 seconds, a maximum top speed of 131 mph (210 km/h), a curb weight of 3197 lbs (1450 kgs), the Scorpio II 2.3i 16v has a naturally-aspirated Inline 4 cylinder engine, Petrol motor.
This engine produces a maximum power of 147 PS (145 bhp - 108 kW) at 5600 rpm and a maximum torque of 202 Nm (148 lb.ft) at 4500 rpm. The power is transmitted to the road by the rear wheel drive (RWD) with a 5 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Scorpio II has Independent. McPherson. coil springs. anti-roll bar front suspension and Independent transverse arms. coil springs. Anti roll bar rear suspension. Stock tire sizes are 195 / 65 on 15 inch rims at the front, and 195 / 65 on 15 inch rims at the rear. For stopping power, the Scorpio II 2.3i 16v braking system includes Vented Discs at the front and Discs at the rear.
The Scorpio II model is a car manufactured by Ford, with 5 doors and 5 seats, sold new from year 1996 until 1997, and available after that as a used car.

Ford Scorpio II 2.3i 16v Body, Model and Production details Ford Scorpio II 2.3i 16v Body, Model and Production details

Generation : Scorpio 2
Body : -
Num. of Doors : 5 doors

Ford Scorpio II 2.3i 16v Engine Technical Data Ford Scorpio II 2.3i 16v Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Petrol
Fuel System : MPI
Engine Alignment : Longitudinal
Engine size - Displacement - Engine capacity : 140 cu-in / 2295 cm3
Bore x Stroke : 3.58 x 3.58 inches
91.0 x 91.0 mm
Number of valves : 16 Valves
Aspiration : N/A
Compression Ratio : 10.0
Maximum power - Output - Horsepower : 145 HP / 147 PS / 108 kW
@ 5600 rpm
Maximum torque : 148 lb-ft / 202 Nm
@ 4500 rpm
Drive wheels - Traction - Drivetrain : RWD
Transmission Gearbox - Number of speeds :

Ford Scorpio II 2.3i 16v Fuel Consumption (Economy), Emissions and Range Ford Scorpio II 2.3i 16v Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 25 MPG
9.6 L/100 Km
29 MPG UK
Fuel Consumption - Economy - Open road: 31 MPG
7.7 L/100 Km
37 MPG UK
Fuel Consumption - Economy - City: 18 MPG
12.9 L/100 Km
22 MPG UK
Range : 453 miles / 729 Km
Fuel Tank Capacity : 18.5 gallons
70 L
15.4 UK gallons
CO2 emissions : 229 g/Km (estimate)

Ford Scorpio II 2.3i 16v Performance Ford Scorpio II 2.3i 16v Performance

Top Speed : 131 Mph / 210 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 9.8 s

Ford Scorpio II 2.3i 16v Size, Dimensions, Aerodynamics and Weight Ford Scorpio II 2.3i 16v Size, Dimensions, Aerodynamics and Weight

Wheelbase : 109.06 inches / 277.0 cm
Length : 189.76 inches / 482.0 cm
Width : 74.02 inches / 188.0 cm
Height : 54.72 inches / 139.0 cm
Aerodynamic drag coefficient - Cx : -
Curb Weight : 3197 lbs / 1450 Kg
Weight-Power Output Ratio : 9.9 kg/hp

Ford Scorpio II 2.3i 16v Interior size, Dimensions Ford Scorpio II 2.3i 16v Interior size, Dimensions

Num. of Seats : 5 seats
Trunk / Boot capacity : 16.4 cu-ft / 465 L

Ford Scorpio II 2.3i 16v Brakes, Tires, Steering and Suspension Ford Scorpio II 2.3i 16v Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(- inches / - mm)
Rear Brakes - Dics dimensions : Discs
(- inches / - mm)
Front Tyres - Rims dimensions : 195/65 R15
Rear Tyres - Rims dimensions : 195/65 R15
Front Suspension : Independent. McPherson. coil springs. anti-roll bar
Rear Suspension : Independent transverse arms. coil springs. Anti roll bar
If you found an error in these specifications submit your correction here
What engine is in Ford Scorpio II 2.3i 16v?
The Ford Scorpio II 2.3i 16v has a Inline 4, Petrol engine with 2295 cm3 / 140 cu-in capacity.

How many horsepower (hp) does a 1996 Ford Scorpio II 2.3i 16v have?
The 1996 Ford Scorpio II 2.3i 16v has 147 PS / 145 bhp / 108 kW.

How much does a Ford Scorpio II 2.3i 16v weighs?
The Ford Scorpio II 2.3i 16v weighs 1450 Kg / 3197 lbs.

What is the top speed of a Ford Scorpio II 2.3i 16v?
The Ford Scorpio II 2.3i 16v top speed is 210 Km/h / 131 mph.

Is Ford Scorpio II 2.3i 16v All Wheel Drive (AWD)?
No, the Ford Scorpio II 2.3i 16v is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
