Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Specs

(2015 - 2018) - Technical Specifications for Years 2015, 2016, 2017, 2018

Compare with another car

More pictures

Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Body, Model and Production details

Generation :	C Max 2

Body :	-

Num. of Doors :	5 doors


Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine size - Displacement - Engine capacity :	91.5 cu-in / 1499 cm3

Bore x Stroke :	2.89 x 3.48 inches 73.5 x 88.3 mm

Number of valves :	8 Valves

Aspiration :	Turbo + Intercooler

Compression Ratio :	16.0

Maximum power - Output - Horsepower :	104 HP / 105 PS / 77 kW @ 3600 rpm

Maximum torque :	199 lb-ft / 270 Nm @ 1750-2500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual Transmission Relations 1st Gear Ratio: 9.3 2nd Gear Ratio: 16.9 3rd Gear Ratio: 27.4 4th Gear Ratio: 37.6 5th Gear Ratio: 46.8 6th Gear Ratio: 55.5 Reverse Gear Ratio: 9.0


Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	57 MPG 4.1 L/100 Km 69 MPG UK

Fuel Consumption - Economy - Open road:	64 MPG 3.7 L/100 Km 76 MPG UK

Fuel Consumption - Economy - City:	50 MPG 4.7 L/100 Km 60 MPG UK

Range :	803 miles / 1292 Km

Fuel Tank Capacity :	14 gallons 53 L 11.7 UK gallons

CO2 emissions :	99 g/Km (Ford)

Emission standard :	Euro VI

Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Performance

Top Speed :	106 Mph / 170 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	13.4 s


Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Size, Dimensions, Aerodynamics and Weight

Wheelbase :	104.25 inches / 264.8 cm

Length :	172.4 inches / 437.9 cm

Width :	71.97 inches / 182.8 cm

Height :	63.39 inches / 161.0 cm

Front Axle :	61.3 inches / 155.7 cm

Rear Axle :	61.77 inches / 156.9 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	- lbs / - Kg


Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	16.6 cu-ft / 471 L

Trunk / Boot First Row :	60.8 cu-ft / 1723 L


Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (10.94 inches / 278 mm)

Rear Brakes - Dics dimensions :	Discs (11.02 inches / 280 mm)

Front Tyres - Rims dimensions :	205/55 R16

Rear Tyres - Rims dimensions :	205/55 R16

Front Wheels Width :	6,5"

Rear Wheels Width :	6,5"

Steering :	Rack and pinion Electric

Steering wheel lock-to-lock :	2.7 turns

Steering ratio :	14.7

Front Suspension :	McPherson struts. Coil springs.

Rear Suspension :	Coil springs.

What engine is in Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP?
The Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP has a Inline 4, Diesel engine with 1499 cm3 / 91.5 cu-in capacity.

How many horsepower (hp) does a 2015 Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP have?
The 2015 Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP has 105 PS / 104 bhp / 77 kW.

What is the top speed of a Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP?
The Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP top speed is 170 Km/h / 106 mph.

Is Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP All Wheel Drive (AWD)?
No, the Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

How fast is a Ford C MAX II 2015 1.5 TDCI ECONETIC Auto Start-Stop 105HP?
The {carro} can reach 0 to 100 km/h (0 to 62 mph) in 13.4 seconds and a top speed of 106 mph.
