Citroen Grand C4 Picasso 2.0 HDi Specs

(2006 - ) Technical Specifications
Citroen Grand C4 Picasso image
With a fuel consumption of 6.1 litres/100km - 46 mpg UK - 39 mpg US (Average), 0 to 100 km/h (62mph) in 13.7 seconds, a maximum top speed of 121 mph (195 km/h), a curb weight of 3516 lbs (1595 kgs), the Grand C4 Picasso 2.0 HDi has a turbocharged Inline 4 cylinder engine, Diesel motor.
This engine produces a maximum power of 138 PS (136 bhp - 101 kW) at 4000 rpm and a maximum torque of 270 Nm (199 lb.ft) at 2000 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 6 speed Automatic gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Grand C4 Picasso has Independent. McPherson. coil springs. anti-roll bar front suspension and Torsion Axle. anti-roll bar rear suspension. Stock tire sizes are 215 / 55 on 16 inch rims at the front, and 215 / 55 on 16 inch rims at the rear. For stopping power, the Grand C4 Picasso 2.0 HDi braking system includes Vented Discs at the front and Discs at the rear.
The Grand C4 Picasso model is a car manufactured by Citroen, sold new from year 2006.

Citroen Grand C4 Picasso 2.0 HDi Body, Model and Production details Citroen Grand C4 Picasso 2.0 HDi Body, Model and Production details

Generation : C4 Picasso 1
Body : -
Num. of Doors : 5 doors

Citroen Grand C4 Picasso 2.0 HDi Engine Technical Data Citroen Grand C4 Picasso 2.0 HDi Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : -
Fuel type : Diesel
Fuel System : Common Rail
Engine Alignment : Transverse
Engine size - Displacement - Engine capacity : 121.9 cu-in / 1997 cm3
Bore x Stroke : 3.35 x 3.46 inches
85.0 x 88.0 mm
Number of valves : 16 Valves
Aspiration : Turbo + Intercooler
Compression Ratio : 17.6
Maximum power - Output - Horsepower : 136 HP / 138 PS / 101 kW
@ 4000 rpm
Maximum torque : 199 lb-ft / 270 Nm
@ 2000 rpm
Drive wheels - Traction - Drivetrain : FWD
Transmission Gearbox - Number of speeds :

Citroen Grand C4 Picasso 2.0 HDi Fuel Consumption (Economy), Emissions and Range Citroen Grand C4 Picasso 2.0 HDi Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined: 39 MPG
6.1 L/100 Km
46 MPG UK
Fuel Consumption - Economy - Open road: 46 MPG
5.1 L/100 Km
55 MPG UK
Fuel Consumption - Economy - City: 30 MPG
7.9 L/100 Km
36 MPG UK
Range : 611 miles / 983 Km
Fuel Tank Capacity : 15.9 gallons
60 L
13.2 UK gallons
CO2 emissions : 159 g/Km (Citroen)

Citroen Grand C4 Picasso 2.0 HDi Safety Ratings

Euro NCAP

Citroen Grand C4 Picasso 2.0 HDi Performance Citroen Grand C4 Picasso 2.0 HDi Performance

Top Speed : 121 Mph / 195 Km/h
Acceleration 0 to 100 km/h (0 to 62 mph) : 13.7 s

Citroen Grand C4 Picasso 2.0 HDi Size, Dimensions, Aerodynamics and Weight Citroen Grand C4 Picasso 2.0 HDi Size, Dimensions, Aerodynamics and Weight

Wheelbase : 107.48 inches / 273.0 cm
Length : 180.31 inches / 458.0 cm
Width : 72.05 inches / 183.0 cm
Height : 65.35 inches / 166.0 cm
Aerodynamic drag coefficient - Cx : -
Curb Weight : 3516 lbs / 1595 Kg
Weight-Power Output Ratio : 11.6 kg/hp

Citroen Grand C4 Picasso 2.0 HDi Interior size, Dimensions Citroen Grand C4 Picasso 2.0 HDi Interior size, Dimensions

Trunk / Boot capacity : from 10.9 cu-ft / 310 L

Citroen Grand C4 Picasso 2.0 HDi Brakes, Tires, Steering and Suspension Citroen Grand C4 Picasso 2.0 HDi Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(- inches / - mm)
Rear Brakes - Dics dimensions : Discs
(- inches / - mm)
Front Tyres - Rims dimensions : 215/55 R16
Rear Tyres - Rims dimensions : 215/55 R16
Front Suspension : Independent. McPherson. coil springs. anti-roll bar
Rear Suspension : Torsion Axle. anti-roll bar
If you found an error in these specifications submit your correction here
What engine is in Citroen Grand C4 Picasso 2.0 HDi?
The Citroen Grand C4 Picasso 2.0 HDi has a Inline 4, Diesel engine with 1997 cm3 / 121.9 cu-in capacity.

How many horsepower (hp) does a 2006 Citroen Grand C4 Picasso 2.0 HDi have?
The 2006 Citroen Grand C4 Picasso 2.0 HDi has 138 PS / 136 bhp / 101 kW.

How much does a Citroen Grand C4 Picasso 2.0 HDi weighs?
The Citroen Grand C4 Picasso 2.0 HDi weighs 1595 Kg / 3516 lbs.

What is the top speed of a Citroen Grand C4 Picasso 2.0 HDi?
The Citroen Grand C4 Picasso 2.0 HDi top speed is 195 Km/h / 121 mph.

Is Citroen Grand C4 Picasso 2.0 HDi All Wheel Drive (AWD)?
No, the Citroen Grand C4 Picasso 2.0 HDi is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
