Citroen Grand C4 Picasso 2017 PureTech 130 S&S Specs

(2016 - 2018) - Technical Specifications for Years 2016, 2017, 2018

Compare with another car

More pictures

With a fuel consumption of 5 litres/100km - 56 mpg UK - 47 mpg US (Average), 0 to 100 km/h (62mph) in 10.8 seconds, a maximum top speed of 125 mph (201 km/h), a curb weight of 3025 lbs (1372 kgs), the Grand C4 Picasso 2017 PureTech 130 S&S has a turbocharged Inline 3 cylinder engine, Petrol motor, with the engine code PSA EB2DTS.
This engine produces a maximum power of 131 PS (129 bhp - 96 kW) at 5500 rpm and a maximum torque of 230 Nm (169 lb.ft) at 1750 rpm. The power is transmitted to the road by the front wheel drive (FWD) with a 6 speed Manual gearbox.
On the topic of chassis details responsible for road holding, handling behavior and ride comfort, the Grand C4 Picasso 2017 has McPherson struts. Coil springs. front suspension and Coil springs. Torsion bar. rear suspension. Stock tire sizes are 205 / 60 on 16 inch rims at the front, and 205 / 60 on 16 inch rims at the rear. For stopping power, the Grand C4 Picasso 2017 PureTech 130 S&S braking system includes Vented Discs at the front and Discs at the rear.
The Grand C4 Picasso 2017 model is a car manufactured by Citroen, with 5 doors and 7 seats, sold new from year 2016 until 2018, and available after that as a used car.

Citroen Grand C4 Picasso 2017 PureTech 130 S&S Body, Model and Production details

Generation :	C4 Picasso 2

Body :	-

Num. of Doors :	5 doors

Num. of Seats :	7 seats


Citroen Grand C4 Picasso 2017 PureTech 130 S&S Engine Technical Data

Engine type - Number of cylinders :	Inline 3

Engine Code :	PSA EB2DTS

Fuel type :	Petrol

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine size - Displacement - Engine capacity :	73.2 cu-in / 1199 cm3

Bore x Stroke :	2.95 x 3.56 inches 75.0 x 90.5 mm

Number of valves :	12 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	11.0

Maximum power - Output - Horsepower :	129 HP / 131 PS / 96 kW @ 5500 rpm

Maximum torque :	169 lb-ft / 230 Nm @ 1750 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual

Clutch Type :	Dry single disc clutch


Citroen Grand C4 Picasso 2017 PureTech 130 S&S Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	47 MPG 5 L/100 Km 56 MPG UK

Fuel Consumption - Economy - Open road:	55 MPG 4.3 L/100 Km 66 MPG UK

Fuel Consumption - Economy - City:	39 MPG 6.1 L/100 Km 46 MPG UK

Range :	709 miles / 1140 Km

Fuel Tank Capacity :	15.1 gallons 57 L 12.5 UK gallons

CO2 emissions :	115 g/Km (Citroen)

Emission standard :	Euro VI

Citroen Grand C4 Picasso 2017 PureTech 130 S&S Performance

Top Speed :	125 Mph / 201 Km/h

Acceleration 0 to 100 km/h (0 to 62 mph) :	10.8 s

Acceleration 0 to 1000m :	32.2 s

Citroen Grand C4 Picasso 2017 PureTech 130 S&S Size, Dimensions, Aerodynamics and Weight

Seat distribution :	2+3+2

Wheelbase :	111.81 inches / 284.0 cm

Length :	181.18 inches / 460.2 cm

Width :	71.89 inches / 182.6 cm

Height :	64.49 inches / 163.8 cm

Front Axle :	62.48 inches / 158.7 cm

Rear Axle :	62.6 inches / 159.0 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	3025 lbs / 1372 Kg

Weight-Power Output Ratio :	10.5 kg/hp

Trunk / Boot capacity :	6 cu-ft / 170 L

Trunk / Boot First Row :	65.1 cu-ft / 1843 L

Trunk / Boot Second Row :	22.7 cu-ft / 643 L

Trunk / Boot Third Row :	6 cu-ft / 170 L


Citroen Grand C4 Picasso 2017 PureTech 130 S&S Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- inches / - mm)

Rear Brakes - Dics dimensions :	Discs (- inches / - mm)

Front Tyres - Rims dimensions :	205/60 R16

Rear Tyres - Rims dimensions :	205/60 R16

Steering :	Rack and pinion Electric

Front Suspension :	McPherson struts. Coil springs.

Rear Suspension :	Coil springs. Torsion bar.

What engine is in Citroen Grand C4 Picasso 2017 PureTech 130 S&S?
The Citroen Grand C4 Picasso 2017 PureTech 130 S&S has a Inline 3, Petrol engine with 1199 cm3 / 73.2 cu-in capacity.

How many horsepower (hp) does a 2016 Citroen Grand C4 Picasso 2017 PureTech 130 S&S have?
The 2016 Citroen Grand C4 Picasso 2017 PureTech 130 S&S has 131 PS / 129 bhp / 96 kW.

How much does a Citroen Grand C4 Picasso 2017 PureTech 130 S&S weighs?
The Citroen Grand C4 Picasso 2017 PureTech 130 S&S weighs 1372 Kg / 3025 lbs.

What is the top speed of a Citroen Grand C4 Picasso 2017 PureTech 130 S&S?
The Citroen Grand C4 Picasso 2017 PureTech 130 S&S top speed is 201 Km/h / 125 mph.

Is Citroen Grand C4 Picasso 2017 PureTech 130 S&S All Wheel Drive (AWD)?
No, the Citroen Grand C4 Picasso 2017 PureTech 130 S&S is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
