Browse Car Specifications...

80 (B3/B4) Versions

Audi 80 (B3/B4) 1.8 Specs

(1989 - 1991) - Technical Specifications for Years 1989, 1990, 1991

Petrol

108.7 cu-in
1781 cm³

Inline 4

89 HP
90 PS / 66 kW

104 lb-ft
142 Nm

113 Mph
182 km/h

31 MPG
7.6 L/100 km
37 MPG UK

Audi 80 (B3/B4) 1.8 Body, Model and Production details

Generation :	Type B3 / B4

Body :	-

Num. of Doors :	4 doors


Audi 80 (B3/B4) 1.8 Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Singlepoint Injection - SPI

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	108.7 cu-in / 1781 cm³

Bore x Stroke :	3.19 x 3.4 inches 81.0 x 86.4 mm

Number of valves :	8 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.0

Horsepower :	89 HP / 90 PS / 66 kW @ 5500 rpm

Maximum torque :	104 lb-ft / 142 Nm @ 3300 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	5 speed Manual


Audi 80 (B3/B4) 1.8 Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	31 MPG 7.6 L/100 km 37 MPG UK

Range :	556 miles / 894 km

Fuel Tank Capacity :	18 gallons 68 L 15 UK gallons


Audi 80 (B3/B4) 1.8 Size, Dimensions, Aerodynamics and Weight

Wheelbase :	100.39 inches / 255.0 cm

Length :	172.83 inches / 439.0 cm

Width :	66.93 inches / 170.0 cm

Height :	55.12 inches / 140.0 cm

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2251 lbs / 1021 kg

Weight/Power Output Ratio :	11.3 kg/hp


Audi 80 (B3/B4) 1.8 Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	16 cu-ft / 453 L


Audi 80 (B3/B4) 1.8 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (- inches / - mm)

Rear Brakes - Disc dimensions :	Drums (- inches / - mm)

Front Tyres - Rims dimensions :	175/70 R14

Rear Tyres - Rims dimensions :	175/70 R14

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Torsion crank axle. panhard rod. Coil Springs. Anti-roll bar
